Ice i20NBT-OB Operator's & Parts Manual

32
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SCRUB HEAD GROUP (i20NB / i20NBT)
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1
8116200 BRUSH MOTOR, 24VDC 1.0HP, KIT 1
8116007 BRUSH MOTOR CARBON BRUSH 2
2 1656432 KEY 1
3 1221412 SCREW M4×12 1
4 1422513 LOCK WASHER M5 3
5 1421518 FLAT WASHER M5×
∮
18×2 1
6 8116100 WATER SUPPLY TUBE 1
7 8116006 SCRUB HEAD HOUSING 1
8 8116020 BUMPER, SCRUB HEAD 1
9 8116001 SPACER 2
10 8116008 HUB, DRIVE, 3 LUG 1
11 1221512 SCREW M5×12 2
12 1421510 FLAT WASHER M5×
∮
10×1 2
13 8116002 BRUSH CLAMP PLATE 1
14 8116003 SPRING CLIP 1
15 8116010 FLAT WASHER
∮
8.5×
∮
25.4×4.5 1
16 1422821 LOCK WASHER M8 2
17 1023815 HEX BOLT 5/16-18 ×1.5" UNC 1
18 1222635 SCREW, M6X35 6
19 8116030 STUD 6
20
9040019 19" PAD DRIVER 1
9040019K 19" PAD DRIVER (OPTION) 1
21
9000001 BIG MOUTH 1
9000003 CENTER-LOK 3 (OPTION) 1
22 1321325 SELF-TAPPING SCREW, ST4.8X25 3
23 8116040 SPACER 3
24
9050020 20" BRUSH, 0.7mm PP BRISTLE (OPTION) 1
9050020E 20" BRUSH, 0.5mm PP BRISTLE (OPTION) 1
25 1023010 HEX BOLT 3/8-16 ×1" UNC 4
26 1422026 LOCK WASHER M10 4
27 1421030 FLAT WASHER M10×
∮
30×2.5 4
28 8116202 PIN 1
29 8116205 SCREW M14 × 20 1
30 8111023 WARNING LABEL 1
31 1121913 HEX NUT M14 1
32 8116204 SRPING 1
33 8116210 KNOB M6 1
34 8116009 PROTECTIVE WHEEL 1
35 8115404 SLEEVE, P/M 1
36 1421824 FLAT WASHER M8×
∮
24×2.0 1
37 1021825 HEX BOLT M8×25 1
