Ice i20NBT-OB Operator's & Parts Manual

38
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SCRUB HEAD LIFT GROUP (i20NB / i20NBT)
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8137006 NON-SLIP MAT 1
2 8137100 BRACKET, SCRUB HEAD LIFT 1
3 8133151 BUMPER 1
4 1123810 LOCK NUT M8 5
5 1021830 HEX BOLT M8×30 2
6 1421824 FLAT WASHER M8×
∮
24×2 6
7 8117007 NYLON WASHER
∮
12.9×
∮
24×2.5 4
8 8115404 BEARING, JOURNAL 7
9 8115405 SLEEVE, P/M 2
10 1021825 HEX BOLT M8×25 4
11 1422821 LOCK WASHER M8 4
12 1421816 FLAT WASHER M8×
∮
16×1.6 4
13 8117002 LEFT BRACKET 1
14 8117005 SPACER(i20NB) 1
15 8117003 RIGHT BRACKET 1
16 1022860 HEX BOLT M8 ×60 1
17 8117008 SPRING 1
18 8113109 BEARING, THRUST 2
19 1022845 HEX BOLT M8 ×45 1
20 8117004 ROLLER 1
21 1421612 FLAT WASHER M6×
∮
12×1.6 2
22 1422616 LOCK WASHER M6 2
23 1021616 HEX BOLT M6 ×16 2
24 8117009 SPRING 1
25 8117001 BRACKET, GUIDE 1
