ICE iS1100 31
OPERATOR
PARTS LIST
DIA
NO
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1521260 Socket Head, M12X60, SST 1
2 7000069 Free Hub 1
3 7000070 Spring 1
4 7000185 Ball Bearing 1
5 7000068 Spacer 1
6 7000133 Support,Right Skirt 1
7 7000285 Gasket Adhesive 1
8 7000067 Plate 1
9 7000174 Knob,M10 1
10 7000179 Knob,M6 2
11 1123115 Nut,Lock,SS,M12 2
12 1123608 Nut,Lock,SS,M6 4
13 7000135 Plate,Side Skirt 2
14 7000134 Side Skirt 1
15 1521640 Screw, RHM, M6X40, SST 4
16 1422616 Washer, Lock, Ø6 10
17 7000053 Support,Main Brush Shaft 4
18 7000055 Shaft,Main Brush 1
19 7000324A Main Brush Motor 1
20 1655020 Key,5X5X20 1
21 7000064 Spacer 1
22 7000065 Pulley,HTD20 5M 15 6F 1
23 1621624 Washer,Plain,
φ
6.6X
φ
22X2 2
24 1021616 Screw, RHM, M6X16, SST 2
25 1421618 Washer,Plain,
φ
6.4X
φ
18X1.6 4
26 1021620 Screw, RHM, M6X20, SST 4
27 7000060 Flange 1
28 1222512 Screw, HH, M5X12, SST 4
29 7000190 Gas,Spring 1
30 7000186 Ball Bearing,6002 2RS 2
31 1655015 Key,5X5X15 1
32 7000062 Pulley,HTD60 5M 15 6W 1
33 7000192 Belt 1
34 7000512 Clips 1
35 7000513 Cable,Main Brush 1
36 7000177 Knob 1
37 7000178 Knob 1
38 1437032 Ring Retaining 1
39 7000061 Pin 1
