ICE iS1100 43
OPERATOR
PARTS LIST
DIA
NO
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 7000099 Plate Supporting 1
2 7000103 Bushing 1
3 7000107 Shaft 1
4 1421330 Washer,Plain,
φ
21X
φ
37X3 1
5 1436020 Ring Retaining 1
6 7000106 Bearing Retainer 1
7 1513825 Countersunk Hex Screw,M8X25 1
8 1021830 Screw, RHM, M8X30, SST 8
9 1422821 Washer, Lock, Ø8 17
10 1411816 Washer,Plain,
φ
8X
φ
16X1.6 14
11 7000098 Flange 1
12 7000187 Ball Bearing,6207 2RS 2
13 7000097 Flange 1
14 1521512 Socket Head, M5X12, SST 2
15 1021825 Screw, RHM, M8X25, SST 9
16 7000093 Crown 1
17 7000198 Front Wheel 1
18 1421330 Washer,Plain,
φ
21X
φ
37X3 1
19 1123020 Nut,Lock,SS,M20 1
20 7000104 Flange 1
21 7000087 Support,Front Wheel 1
22 7000105 Shaft,Front Wheel 1
23 1521025 Socket Head, M10X25, SST 4
24 1422026 Washer, Lock, Ø10 4
25 7000092 Plate 1
26 7000110 Chain 1
27 1021616 Screw, RHM, M6X16, SST 1
28 1422616 Washer, Lock, Ø6 1
29 1621624 Washer,Plain,
φ
6.6X
φ
22X2 1
30 7000109 Sprocket 1
31 1655015 Key,5X5X15 1
32 7000108 Steering Shaft 1
33 7000411 Joint 1
34 1521625 Socket Head, M6X25, SST 2
35 1022065 Screw, RHM, M10X65, SST 2
36 1121008 Nut,SS,M10 2
