ICE iS1100 45
OPERATOR
PARTS LIST
DIA
NO
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 7000214 Pedal 1
2 1421612 Washer,Plain,
φ
6X
φ
12X1.6 8
3 1123608 Nut,Lock,SS,M6 3
4 1521655 Socket Head, M6X55, SST 1
5 7000220 Roller 1
6 1021625 Screw, RHM, M6X25, SST 2
7 1021616 Washer, Lock, Ø6 5
8 7000221 Cover 1
9 1222690 Screw, RHM, M6X90, SST 1
10 1521612 Socket Head, M6X12, SST 4
11 7000211 Pedal Support 1
12 7000217 Spring 1
13 7000213 Spacer 1
14 7000508 Cable,Front Skirt Lift-up 1
15 7000219 Lever 1
16 7000507 Clips 1
17 7000162 Speed Control Pedal 1
18 1411816 Washer,Plain,
φ
8X
φ
16X1.6 3
19 1422821 Washer, Lock, Ø8 3
20 1521820 Socket Head, M8X20, SST 3
21 7000210 Front Skirt Rainsing Pedal Kit 1
22 7000161 Speed Control Pedal Kit 1
23 1621624 Washer,Plain,
φ
6X
φ
22X2 1
24 7000218 Stopper 1
