Ice iS1100 - Page 8

6 ICE iS1100
OPERATOR
MACHINE COMPONENTS
(
Continues
)
46. Electrical component box
47. Electrical component cover
48. Machine connector
49. Main broom height adjusting knob
50. Vacuum Fan cover
51. Vacuum fan
40. Body rope
41.Lead batteries (WET) or AGM batteries
42. Battery connection diagram
43. Battery caps (for WET batteries only)
44. Battery connector
45. Battery container
40
44
41
43
42
41
50
51
49
47
45
46
48
41
