MANUAL for KG30 - KG50 SUpreMe
DRY ICE BLASTING EQUIPMENT FROM ICETECH | PAGE 11
10 The IceBlast machine is equipped with a Static
Ground Cable which is mounted on the front of the
IceBlast machine. Connect the Static Ground Cable
to the item being blast cleaned or to an electrically
conductive supporting structure of the material.
135 9
7
10
11
12
14
11 Activate the trigger on the blasting gun
forafewsecondstoallowairtoowthrough
the system. Checking for moisture in the
airstream, and proper operation of the dosing
disc, vibrator, and regulator
13 Adjust the dry ice consumption (kg/h / lbs/min.)
and the blasting pressure (bar/psi) – the value is
shown on the pressure gauge.
12 Fill dry ice pellets into the hopper (this can be done while the
machine is in operation).
Please note: It is recommended that you run the hopper empty before each
llingtoenabletheoperatortoseewhether“snow”orlumpsappearinthedryice.
These can prevent a continuous supply of dry ice to the dosing unit.
Never leave the machine with the lid open.
14 Start dry ice blasting.
Please note: Before activating the trigger on the blasting gun, the operator
must stand in a working posture that prevents loss of balance from blasting
gun recoil (at max. blasting pressure, with the largest nozzle diameter, the
recoil energy can reach as much as 10 kg / 22 lbs).
8 Check to make sure that the machine is in normal
operating position (the emergency stop button is
pulled out).
9 Turn the machine ON (press the green ON button).
13
8
9
