iCharger Synchronous Balance Charger/Discharger 106B+
Unpack inspection
The following items are included in the package. Contact your supplier if any items are missing.
Standard items：
 One copy of the User‘s manual on CD
 One pair of output alligator clip leads
 One pair of input alligator clips (30A) and input leads with 4mm bullet connectors
 One temperature sensor lead (0 – 99℃(210
o
F))
 Four rubber feet
 One Mini-USB data line(1.2 meter)
Optional items:
See details in ―Optional parts‖ (P29)
External controls and connections
106B+
1. DC input 2. LCD screen 3. Function button 4. Cooling Fan 5. Temperature sensor port
6. Balance socket 7. Output port 8. USB port
