ICM Controls Simple Comfort SC3211L User Manual

Specifications subject to change without notice.
1-800-365-5525
www.icmcontrols.com
Specications
Electrical Rating:
• 24 VAC (18-30 VAC)
• 1 amp maximum per terminal
• 4 amp maximum total load
• Easy access terminal block
Temperature Control Ranges:
• 45°F to 90°F, Accuracy: ±1°F
System Configurations:
• 2-stage heat pump
Terminations:
• SC3211L: R, C, Y1, Y2, W2, O,
B, G, E, L
• Two-stage heat pump
• Manual changeover
Patent No. Design: 424,953
Patent No. Thermal Intrusion Barrier: 6,597,275
Patent Pending SimpleSet
TM
Target Programming
Programmable 7-Day, 5-2-Day & 5-1-1-Day
Two-Stage Heat Pump
Hardwired
Dimensions
1.12
"
5.50
"
3.25 "
1.68
"
3.75
"
Thermal
Intrusion
Barrier
LIS199
Exclusive,
patented insulation
technology
eliminates thermal
drift caused by
wall effect.
NEW
Thermal
Intrusion
Barrier
Need more wall coverage?
Order the ICM insulated wall
plate for a polished installation.
Eliminate the wall effect. ICM’s insulated wall plate
provides a fast, easy solution for hiding wall problems.
• Foam gasket prevents drafts through wall opening
• Rugged, flexible construction
• Hidden mounting screws for a sleek appearance
• Universal fit with all SimpleComfort
®
thermostats
• Order:
ACC-WP03 — 5.7”H x 7.5”W
SC5812 Thermostat shown with ACC-WP03 insulated wall plate.
Patent-pending technology lets you transfer
the program and configuration from one
thermostat to another in seconds.
NEW SimpleSet
TM
Target
Programming

ICM Controls Simple Comfort SC3211L Specifications

Power

voltage	24 VAC (18-30 VAC)
maximum current per terminal	1 amp
maximum total load	4 amps

Temperature Control

temperature control range	45°F to 90°F
accuracy	±1°F
system configurations	2-stage heat pump

Weight and Dimensions

wall plate height	5.7 inches
wall plate width	7.5 inches
height	5.50 inches
depth	1.12 inches
width	3.75 inches
