Feb. 2010
3
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
R101 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 23.8/10.1
R103 7030005100 S.RES ERJ2GEJ 154 X (150K) B 16.2/21.1
R104 7030008290 S.RES ERJ2GEJ 183 X (18K) [EUR] B 18.6/25.7
7030008290 S.RES ERJ2GEJ 183 X (18K) [TPE]
7030005080 S.RES ERJ2GEJ 823 X (82K) [USA]
7030008290 S.RES ERJ2GEJ 183 X (18K) [KOR]
7030008290 S.RES ERJ2GEJ 183 X (18K) [SEA]
7030008290 S.RES ERJ2GEJ 183 X (18K) [THA]
7030008290 S.RES ERJ2GEJ 183 X (18K) [EXP]
7030008290 S.RES ERJ2GEJ 183 X (18K) [EUR-1]
7030008290 S.RES ERJ2GEJ 183 X (18K) [AUS]
7030008290 S.RES ERJ2GEJ 183 X (18K) [SEA-1]
7030008290 S.RES ERJ2GEJ 183 X (18K) [EXP-1]
7030008290 S.RES ERJ2GEJ 183 X (18K) [CHN]
7030008290 S.RES ERJ2GEJ 183 X (18K) [CHN-01]
7030008290 S.RES ERJ2GEJ 183 X (18K) [CHN-02]
7030008290 S.RES ERJ2GEJ 183 X (18K) [TPE-1]
7030008290 S.RES ERJ2GEJ 183 X (18K) [KOR-1]
7030008290 S.RES ERJ2GEJ 183 X (18K) [SEA-2]
7030008290 S.RES ERJ2GEJ 183 X (18K) [THA-1]
7030008290 S.RES ERJ2GEJ 183 X (18K) [EXP-2]
7030008290 S.RES ERJ2GEJ 183 X (18K) [AUS-1]
7030008290 S.RES ERJ2GEJ 183 X (18K) [SEA-3]
7030008290 S.RES ERJ2GEJ 183 X (18K) [EXP-3]
R105 7030005090 S.RES ERJ2GEJ 104 X (100K) B 19.7/25.7
R106 7030005050 S.RES ERJ2GEJ 103 X (10K) B 58.1/22.7
R107 7030005090 S.RES ERJ2GEJ 104 X (100K) B 59.9/23.7
R108 7030005050 S.RES ERJ2GEJ 103 X (10K) B 98.6/14
R109 7030005600 S.RES ERJ2GEJ 273 X (27K) [USA] only B 16.8/25.3
R112 7030008010 S.RES ERJ2GEJ 123 X (12K) B 97/10.6
R114 7030008010 S.RES ERJ2GEJ 123 X (12K) B 95.5/12.9
R128 7030005050 S.RES ERJ2GEJ 103 X (10K) B 58.1/23.7
R129 7030005090 S.RES ERJ2GEJ 104 X (100K) B 58.6/25.7
R133 7030005240 S.RES ERJ2GEJ 473 X (47K) B 90.4/11.8
R134 7030005050 S.RES ERJ2GEJ 103 X (10K) B 98.2/23.9
R135 7030005050 S.RES ERJ2GEJ 103 X (10K) B 91.4/11.8
R136 7030005090 S.RES ERJ2GEJ 104 X (100K) B 88.1/8.7
R137 7030005240 S.RES ERJ2GEJ 473 X (47K) B 88.8/9.6
R515 7030004980 S.RES ERJ2GEJ 101 X (100) B 12.5/29.9
R516 7030010040 S.RES ERJ2GEJ-JPW T 12.4/27.4
R517 7030005160 S.RES ERJ2GEJ 105 X (1M) B 8/28.3
R519 7030005010 S.RES ERJ2GEJ 681 X (680) B 21.1/14.3
R520 7030005240 S.RES ERJ2GEJ 473 X (47K) B 31.4/18.7
R521 7030005240 S.RES ERJ2GEJ 473 X (47K) B 34.2/16.8
R522 7030005100 S.RES ERJ2GEJ 154 X (150K) B 34.7/15.2
R523 7030005160 S.RES ERJ2GEJ 105 X (1M) B 33.7/13.8
R524 7030005050 S.RES ERJ2GEJ 103 X (10K) B 33.7/11.8
R525 7030004980 S.RES ERJ2GEJ 101 X (100) B 44.4/18.5
R526 7030005120 S.RES ERJ2GEJ 102 X (1K) B 41.5/29.8
R527 7030005050 S.RES ERJ2GEJ 103 X (10K) B 44.8/24.8
R530 7030005240 S.RES ERJ2GEJ 473 X (47K) B 28.2/16.1
R531 7030005240 S.RES ERJ2GEJ 473 X (47K) T 14.3/26.2
R532 7030005240 S.RES ERJ2GEJ 473 X (47K) T 14.3/25.2
R533 7030005240 S.RES ERJ2GEJ 473 X (47K) B 58/16.4
R534 7030005240 S.RES ERJ2GEJ 473 X (47K) B 26.1/17.7
R536 7030005050 S.RES ERJ2GEJ 103 X (10K) T 14.1/24.1
R537 7030008370 S.RES ERJ2GEJ 561 X (560) T 14.1/22.9
R538 7030005240 S.RES ERJ2GEJ 473 X (47K) T 108.8/21.7
R539 7030005240 S.RES ERJ2GEJ 473 X (47K) T 108.8/24.9
R541 7030005240 S.RES ERJ2GEJ 473 X (47K) B 59.4/16.5
R542 7030005240 S.RES ERJ2GEJ 473 X (47K) B 60.8/18
R543 7030005240 S.RES ERJ2GEJ 473 X (47K) B 52.1/27.3
R545 7410000770 S.ARR EXB-V4V 102JV (1K) T 68.5/11.7
R546 7030005090 S.RES ERJ2GEJ 104 X (100K) T 18.6/17.4
R548 7030000240 S.RES MCR10EZHJ 68 (680) T 63.2/20.1
R549 7030000240 S.RES MCR10EZHJ 68 (680) B 46.9/17.7
R550 7030010040 S.RES ERJ2GEJ-JPW B 48.6/17.3
R551 7030005050 S.RES ERJ2GEJ 103 X (10K) B 103/26.7
C1 4030017460 S.CER ECJ0EB1E102K B 48.3/10.7
C4 4030017460 S.CER ECJ0EB1E102K T 46.2/10.9
C5 4030017420 S.CER ECJ0EC1H470J T 59.2/7
C7 4030017460 S.CER ECJ0EB1E102K B 57.1/11.4
C8 4030016790 S.CER ECJ0EB1C103K T 21.7/13
C9 4030017460 S.CER ECJ0EB1E102K B 46.2/11
C10 4030017460 S.CER ECJ0EB1E102K B 38.8/29
C11 4030017460 S.CER ECJ0EB1E102K B 20.1/7.8
C13 4030017460 S.CER ECJ0EB1E102K B 70.2/2.9
C14 4030017460 S.CER ECJ0EB1E102K B 44.2/11.3
C15 4030017460 S.CER ECJ0EB1E102K B 54.5/10.7
C16 4030017460 S.CER ECJ0EB1E102K B 23.2/8.7
C19 4030016790 S.CER ECJ0EB1C103K B 47.4/15.6
C20 4030017460 S.CER ECJ0EB1E102K B 13/18
C23 4030017460 S.CER ECJ0EB1E102K T 12.8/17.9
C28 4030017460 S.CER ECJ0EB1E102K B 9.9/16.6
C30 4030017420 S.CER ECJ0EC1H470J B 49.3/10.7
C31 4030017420 S.CER ECJ0EC1H470J T 21/10.7
C32 4510008540 S.ELE EEE1CA100SR B 7.2/24.7
C33 4030013960 S.CER C1005 JB 1C 473K-T B 6.1/28.2
C34 4030017790 S.CER ECJ0EB1E682K B 69.6/4.2
C35 4030017040 S.CER ECJ0EB1A333K B 66/6.7
C36 4030016930 S.CER ECJ0EB1A104K B 7.6/30.1
C37 4030016790 S.CER ECJ0EB1C103K B 65.9/8.1
C38 4030018080 S.CER ECJ0EB1H182K B 70.1/5.6
C39 4030017460 S.CER ECJ0EB1E102K B 95/17.2
C40 4030017460 S.CER ECJ0EB1E102K B 32/3.8
C41 4030016930 S.CER ECJ0EB1A104K B 24.1/19.3
C42 4030016950 S.CER ECJ0EB1A473K B 14.8/21.5
C43 4030016950 S.CER ECJ0EB1A473K B 63.9/19.6
C44 4030018240 S.CER ECJ0EB1E562K B 14.5/22.5
C45 4030016790 S.CER ECJ0EB1C103K B 67.7/18.9
C46 4030016970 S.CER ECJ0EB1C223K B 73.7/3.7
C47 4030016930 S.CER ECJ0EB1A104K B 22.4/14
C48 4030017760 S.CER ECJ0EB1H222K B 74.7/3.7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
C49 4030016930 S.CER ECJ0EB1A104K B 100.5/14.3
C51 4030017030 S.CER ECJ0EB1A273K B 97/16.4
C52 4030017420 S.CER ECJ0EC1H470J T 82.9/21.3
C53 4030017500 S.CER ECJ0EC1H560J B 98.1/9.9
C54 4030016790 S.CER ECJ0EB1C103K B 24.5/16.9
C55 4030017600 S.CER ECJ0EC1H080C B 92.4/10.5
C56 4030017760 S.CER ECJ0EB1H222K B 23.5/16.3
C57 4030018110 S.CER ECJ0EB1H272K B 22.2/15.6
C59 4030017640 S.CER ECJ0EC1H150J B 96/11.6
C62 4030017460 S.CER ECJ0EB1E102K B 70.4/25.7
C64 4030016790 S.CER ECJ0EB1C103K B 74.4/8.4
C65 4030016790 S.CER ECJ0EB1C103K B 97.7/22.2
C66 4030016790 S.CER ECJ0EB1C103K T 34.7/16
C67 4510008540 S.ELE EEE1CA100SR B 101.4/5
C68 4030016930 S.CER ECJ0EB1A104K B 91.3/10
C69 4030016930 S.CER ECJ0EB1A104K B 32.4/30.2
C70 4030016790 S.CER ECJ0EB1C103K T 71.6/26.8
C71 4030016790 S.CER ECJ0EB1C103K B 25.7/28.2
C72 4030017040 S.CER ECJ0EB1A333K B 28.3/28.7
C73 4510008530 S.ELE EEE1HA2R2SR B 33.4/21.6
C74 4030018240 S.CER ECJ0EB1E562K B 30.3/29.7
C75 4030017450 S.CER ECJ0EB1E271K B 23.1/25.2
C76 4030017040 S.CER ECJ0EB1A333K B 25.8/20.5
C77 4510008530 S.ELE EEE1HA2R2SR B 9.1/19.9
C78 4030016790 S.CER ECJ0EB1C103K B 23.9/22.9
C79 4030017440 S.CER ECJ0EC1H221J B 17.2/21.1
C80 4030016790 S.CER ECJ0EB1C103K B 97/12.4
C81 4030016790 S.CER ECJ0EB1C103K B 94/11.6
C82 4030017730 S.CER ECJ0EB1E471K B 95/11.6
C583 4030016930 S.CER ECJ0EB1A104K T 14.7/21
C584 4030016930 S.CER ECJ0EB1A104K T 16.5/27.7
C585 4030016930 S.CER ECJ0EB1A104K B 10.4/26.1
C586 4510008490 S.ELE EEE1CS100SR B 14.1/25.4
C587 4550006250 S.TAN TEESVA 1A 106M8R B 10.2/31.8
C588 4030017490 S.CER C1608 JB 1A 105K-T B 22/12.8
C591 4030017460 S.CER ECJ0EB1E102K T 21.3/21.2
C592 4030017460 S.CER ECJ0EB1E102K B 29.3/15
C593 4030016930 S.CER ECJ0EB1A104K B 43.3/30.5
C594 4030017460 S.CER ECJ0EB1E102K B 14.7/28.4
C595 4030017460 S.CER ECJ0EB1E102K T 22.5/21.5
C596 4030017460 S.CER ECJ0EB1E102K B 29.7/17.2
C597 4030017460 S.CER ECJ0EB1E102K B 37.6/9
C599 4030016930 S.CER ECJ0EB1A104K B 12.5/28
C600 4030017460 S.CER ECJ0EB1E102K T 36.4/16.9
C601 4550007510 S.TAN F931C106MBABMA T 51.4/20.1
C602 4550006250 S.TAN TEESVA 1A 106M8R B 49.2/14.2
J1 6450002210 CON 3017-8821 <KIN>
J3 6510024231 S.CON 08-6210-036-340-800 B 50.1/6.7
J4 6510021970 S.CON AXN330C130P B 53.6/18.8
DS1 5030002660 LCD IS08264E00V2 <SKD>
DS2 5040001760 S.LED SEC 2422C T 46.5/21.1
DS3 5040001760 S.LED SEC 2422C T 57.2/21.1
DS4 5040001760 S.LED SEC 2422C T 68/21.1
DS5 5040001760 S.LED SEC 2422C T 78.8/21.1
DS6 5040001760 S.LED SEC 2422C T 89.6/21.1
DS7 5040001760 S.LED SEC 2422C T 100.3/21.1
DS8 5040001760 S.LED SEC 2422C T 46.5/18.1
DS9 5040001760 S.LED SEC 2422C T 57.2/18.1
DS10 5040001760 S.LED SEC 2422C T 68/18.1
DS11 5040001760 S.LED SEC 2422C T 78.8/18.1
DS12 5040001760 S.LED SEC 2422C T 89.6/18.1
DS13 5040001760 S.LED SEC 2422C T 100.3/18.1
S1 2260001890 S.SWI SKQDPA T 8.9/30.7
S2 2260001890 S.SWI SKQDPA T 103.4/4.1
S3 2260001890 S.SWI SKQDPA T 91.4/4.1
S4 2260001890 S.SWI SKQDPA T 79.4/4.1
S5 2260001890 S.SWI SKQDPA T 67.4/4.1
S6 2260001890 S.SWI SKQDPA T 55.4/4.1
S7 2260001890 S.SWI SKQDPA T 43.4/4.1
S8 2260001890 S.SWI SKQDPA T 8.9/21.4
S9 2250000460 ENC EVQ-VENF0224B
S10 2260001890 S.SWI SKQDPA T 114.6/4.1
EP1 6910012350 S.BEA MMZ1608Y 102BT T 18.4/10.7
EP2 6910012350 S.BEA MMZ1608Y 102BT B 17.9/11.6
EP3 6910012350 S.BEA MMZ1608Y 102BT B 11.5/15.8
EP4 6910012350 S.BEA MMZ1608Y 102BT B 17.9/10.3
EP5 6910012350 S.BEA MMZ1608Y 102BT T 11.2/16.4
EP6 6910012350 S.BEA MMZ1608Y 102BT B 12.9/15.8
EP7 6910012350 S.BEA MMZ1608Y 102BT B 17.9/9
EP8 6910012350 S.BEA MMZ1608Y 102BT B 17.9/7.7
EP9 6910012350 S.BEA MMZ1608Y 102BT B 46.9/21.8
EP10 6910012350 S.BEA MMZ1608Y 102BT B 46.9/20.5
EP11 8930062251 LCD SRCN-2698-SP-N-W-1 (SHJ)
