Icom IC-2200H

Feb. 2010
4
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
IC1 1130008351 S.IC LV2105V-TLM-E B 65.1/20
IC2 1130011760 S.IC CD4094BPWR T 59/6.5
IC4 1110003491 S.IC TA31136FNG(D,EL) B 106/17.7
IC5 1190000350 S.IC M62363FP-650C B 86.5/17.5
IC6 1110004050 S.IC NJM3404AV-TE1-#FMZB B 90.5/49.5
IC7 1180001252 S.IC TA7808F(TE16L1,NQ) B 15.5/47.9
IC8 1180000970 S.IC AN78L05M-(E1) B 23.8/61.6
IC9 1110002550 IC TA7252AP
IC10 1150002182 IC S-AV36A(I,Q) [EUR]
1150002182 IC S-AV36A(I,Q) [TPE]
1150002182 IC S-AV36A(I,Q) [USA]
1150002182 IC S-AV36A(I,Q) [KOR]
1150002182 IC S-AV36A(I,Q) [SEA]
1150002300 IC S-AV39(I,Q) [THA]
1150002182 IC S-AV36A(I,Q) [EXP]
1150002182 IC S-AV36A(I,Q) [EUR-1]
1150002182 IC S-AV36A(I,Q) [AUS]
1150002182 IC S-AV36A(I,Q) [SEA-1]
1150002182 IC S-AV36A(I,Q) [EXP-1]
1150002182 IC S-AV36A(I,Q) [CHN]
1150002182 IC S-AV36A(I,Q) [CHN-01]
1150002182 IC S-AV36A(I,Q) [CHN-02]
IC11 1110004050 S.IC NJM3404AV-TE1-#FMZB T 87.1/49.5
IC12 1130011781 S.IC SN74AHC2G53HDCT3 T 98.8/6.8
Q1 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 33.4/38.2
Q2 1590001650 S.TRA XP4601(TX) B 34.8/17.3
Q3 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 28.3/31.7
Q4 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 76/21.3
Q5 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 29.3/34.9
Q6 1530002920 S.TRA 2SC4226-T1 R25 T 34.8/25
Q7 1530002920 S.TRA 2SC4226-T1 R25 T 40.5/26
Q8 1590001040 S.TRA DTA113ZU T106 B 33.8/34.9
Q9 1530002920 S.TRA 2SC4226-T1 R25 T 50.2/26.2
Q10 1560000811 S.FET 2SK1069-4-TL-E T 50.1/35.9
Q11 1530002920 S.TRA 2SC4226-T1 R25 T 56.6/24.7
Q12 1530002920 S.TRA 2SC4226-T1 R25 T 55.4/18.5
Q13 1590000720 S.TRA DTA144EUA T106 [EUR] T 110.5/20
1590000720 S.TRA DTA144EUA T106 [TPE]
1590000720 S.TRA DTA144EUA T106 [USA]
1590000720 S.TRA DTA144EUA T106 [KOR]
1590000720 S.TRA DTA144EUA T106 [SEA]
1590000720 S.TRA DTA144EUA T106 [THA]
1590000720 S.TRA DTA144EUA T106 [EXP]
1590000720 S.TRA DTA144EUA T106 [EUR-1]
1590000720 S.TRA DTA144EUA T106 [CHN]
1590000720 S.TRA DTA144EUA T106 [CHN-01]
Q14 1510000591 S.TRA 2SA1362-Y(TE85L,F) T 32.4/48.8
Q15 1530002851 S.TRA 2SC4116-BL(TE85R,F) T 38.5/50.6
Q16 1530003221 S.TRA 2SC4406-4-TL-E [EUR] B 103.7/26.2
1530003221 S.TRA 2SC4406-4-TL-E [TPE]
1530003221 S.TRA 2SC4406-4-TL-E [USA]
1530003221 S.TRA 2SC4406-4-TL-E [KOR]
1530003221 S.TRA 2SC4406-4-TL-E [SEA]
1530003221 S.TRA 2SC4406-4-TL-E [THA]
1530003221 S.TRA 2SC4406-4-TL-E [EXP]
1530003221 S.TRA 2SC4406-4-TL-E [EUR-1]
1530003221 S.TRA 2SC4406-4-TL-E [AUS]
1530003220 S.TRA 2SC4406-4-TL [SEA-1]
1530003221 S.TRA 2SC4406-4-TL-E [EXP-1]
1530003221 S.TRA 2SC4406-4-TL-E [CHN]
1530003221 S.TRA 2SC4406-4-TL-E [CHN-01]
1530003221 S.TRA 2SC4406-4-TL-E [CHN-02]
Q17 1530000370 S.TRA 2SC3356-T1B B 41.1/39.8
Q19 1580000760 S.FET 3SK299-T1 U73 B 77.3/35.9
Q21 1590001010 S.TRA DTB113ZK T146 T 38.2/42.8
Q22 1590000430 S.TRA DTC144EUA T106 T 34.9/43.2
Q25 1590001010 S.TRA DTB113ZK T146 T 64.8/24.5
Q26 1590000720 S.TRA DTA144EUA T106 B 86.4/54.8
Q27 1580000760 S.FET 3SK299-T1 U73 B 105.5/42
Q28 1530003910 S.TRA 2SC4684 (TE16L1 NQ) B 15.5/59.9
Q29 1530003091 S.TRA 2SC4213-B(TE85R,F) B 16.3/7.9
Q30 1510000890 S.TRA DTA143TU T106 T 23.8/64.1
Q31 1590001320 S.TRA DTC143ZUA T106 T 23.8/66.6
Q34 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 103.9/11
Q35 1530002340 S.TRA 2SC2954-T1 [EUR] B 44/50.7
1530003270 S.TRA 2SC4703-T1 SF [TPE]
1530003270 S.TRA 2SC4703-T1 SF [USA]
1530003270 S.TRA 2SC4703-T1 SF [KOR]
1530003270 S.TRA 2SC4703-T1 SF [SEA]
1530003270 S.TRA 2SC4703-T1 SF [THA]
1530003270 S.TRA 2SC4703-T1 SF [EXP]
1530002340 S.TRA 2SC2954-T1 [EUR-1]
1530003270 S.TRA 2SC4703-T1 SF [AUS]
1530003270 S.TRA 2SC4703-T1 SF [SEA-1]
1530003270 S.TRA 2SC4703-T1 SF [EXP-1]
1530003270 S.TRA 2SC4703-T1 SF [CHN]
1530003270 S.TRA 2SC4703-T1 SF [CHN-01]
1530003270 S.TRA 2SC4703-T1 SF [CHN-02]
Q36 1590001040 S.TRA DTA113ZU T106 T 101.7/10.1
Q37 1590001190 S.TRA XP6501-(TX).AB T 109.1/13.6
Q38 1590001190 S.TRA XP6501-(TX).AB T 108.4/6.6
Q39 1590000430 S.TRA DTC144EUA T106 B 83.3/53.1
Q40 1590000430 S.TRA DTC144EUA T106 B 86.2/52.2
Q41 1530003630 S.TRA 2SC4617 TLS B 16.6/10.2
D1 1790001251 S.DIO MA2S1110GL B 35.3/38.2
D2 1750000721 S.VAR HVC375BTRF-E T 36.5/17
D3 1750000771 S.VAR HVC376BTRF-E T 87.8/21.3
D4 1720000730 S.VAR MA2S30400L T 36.5/18.3
D5 1720000730 S.VAR MA2S30400L T 41.5/18.2
D6 1790000620 S.DIO MA77(TX) B 53.1/32.9
D7 1790000620 S.DIO MA77(TX) B 64.4/32.3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
D9 1750000711 S.VAR HVC350BTRF-E B 84.8/39.2
D10 1750000711 S.VAR HVC350BTRF-E B 88.7/39.2
D11 1750000711 S.VAR HVC350BTRF-E B 94/39.2
D12 1710001061 DIO L407CDB
D13 1750000711 S.VAR HVC350BTRF-E B 117.8/42.7
D14 1790000981 S.DIO MA3J7420GL T 107.2/69.9
D15 1750000550 S.DIO 1SS355 TE-17 T 117.9/48.9
D16 1710000871 S.DIO HVU131TRF-E T 117.9/50.7
D17 1790000981 S.DIO MA3J7420GL T 102.3/72.8
D18 1790001251 S.DIO MA2S1110GL B 93.9/45.2
D19 1710001081 DIO L308CCB
D20 1730000521 ZEN RD20E-AZ B2
D21 1790000700 DIO DSA3A1
D23 1790001251 S.DIO MA2S1110GL [EUR] B 117.1/24.1
1790001251 S.DIO MA2S1110GL [TPE]
1790001251 S.DIO MA2S1110GL [USA]
1790001251 S.DIO MA2S1110GL [KOR]
1790001251 S.DIO MA2S1110GL [SEA]
1790001251 S.DIO MA2S1110GL [THA]
1790001251 S.DIO MA2S1110GL [EXP]
1790001251 S.DIO MA2S1110GL [EUR-1]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
D24 1790001251 S.DIO MA2S1110GL [EUR] T 108.8/25.8
1790001251 S.DIO MA2S1110GL [TPE]
1790001251 S.DIO MA2S1110GL [USA]
1790001251 S.DIO MA2S1110GL [KOR]
1790001251 S.DIO MA2S1110GL [SEA]
1790001251 S.DIO MA2S1110GL [THA]
1790001251 S.DIO MA2S1110GL [EXP]
1790001251 S.DIO MA2S1110GL [EUR-1]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
D25 1790001251 S.DIO MA2S1110GL [EUR] T 111.4/17.3
1790001251 S.DIO MA2S1110GL [TPE]
1790001251 S.DIO MA2S1110GL [USA]
1790001251 S.DIO MA2S1110GL [KOR]
1790001251 S.DIO MA2S1110GL [SEA]
1790001251 S.DIO MA2S1110GL [THA]
1790001251 S.DIO MA2S1110GL [EXP]
1790001251 S.DIO MA2S1110GL [EUR-1]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
D26 1790001251 S.DIO MA2S1110GL [EUR] B 116.3/22.8
1790001251 S.DIO MA2S1110GL [TPE]
1790001251 S.DIO MA2S1110GL [USA]
1790001251 S.DIO MA2S1110GL [KOR]
1790001251 S.DIO MA2S1110GL [SEA]
1790001251 S.DIO MA2S1110GL [THA]
1790001251 S.DIO MA2S1110GL [EXP]
1790001251 S.DIO MA2S1110GL [EUR-1]
1790001251 S.DIO MA2S1110GL [CHN]
1790001251 S.DIO MA2S1110GL [CHN-01]
D27 1710001061 DIO L407CDB
D29 1750000370 S.DIO DA221 TL B 98.8/28.5
D30 1750000550 S.DIO 1SS355 TE-17 B 38.2/46.4
D31 1790001251 S.DIO MA2S1110GL B 113.1/41.3
D38 1720000730 S.VAR MA2S30400L T 40.2/15.5
FI1 2020002380 CER LT450FW <JJE>
FI2 2020002510 CER LTW450HT <JJE> [EUR]
2020002510 CER LTW450HT <JJE> [TPE]
2020002510 CER LTW450HT <JJE> [USA]
2020002510 CER LTW450HT <JJE> [KOR]
2020002510 CER LTW450HT <JJE> [SEA]
2020002510 CER LTW450HT <JJE> [THA]
2020002510 CER LTW450HT <JJE> [EXP]
2020002510 CER LTW450HT <JJE> [EUR-1]
2020002510 CER LTW450HT <JJE> [CHN]
2020002510 CER LTW450HT <JJE> [CHN-01]
FI3 2030000270 MON MCF21R15AB 21.7 MHz (FL-363)
FI4 2030000270 MON MCF21R15AB 21.7 MHz (FL-363)
X1 6050011871 S.XTA CR-779A SX-2112 21.250 MHz T 81.9/19.5
X2 6070000290 DIS JTB450C24 <JJE>
L1 6200009351 S.COI ELJRE R22GFA [EUR] T 39.4/18
6200009351 S.COI ELJRE R22GFA [TPE]
6200009351 S.COI ELJRE R22GFA [USA]
6200009351 S.COI ELJRE R22GFA [KOR]
6200009351 S.COI ELJRE R22GFA [SEA]
6200009351 S.COI ELJRE R22GFA [THA]
6200009351 S.COI ELJRE R22GFA [EXP]
6200009351 S.COI ELJRE R22GFA [EUR-1]
6200009351 S.COI ELJRE R22GFA [AUS]
6200009350 S.COI ELJRE R22G-F3 [SEA-1]
6200009351 S.COI ELJRE R22GFA [EXP-1]
6200009351 S.COI ELJRE R22GFA [CHN]
6200009351 S.COI ELJRE R22GFA [CHN-01]
6200009351 S.COI ELJRE R22GFA [CHN-02]
L2 6200003550 S.COI MLF1608A 4R7K-T T 36.4/15.1
L3 6200001620 S.COI ELJFC 1R0K-F B 45.9/31.6
L6 6200009920 S.COI C2012C-R10G-A T 34/20
L7 6200010570 S.COI C6342A-R11J-A T 45.9/19.3
L8 6200004870 S.COI ELJFC 2R7K-F T 37.7/27
L9 6200004880 S.COI ELJFC 3R3K-F T 44.6/25.5
L10 6200001620 S.COI ELJFC 1R0K-F B 45.9/29.1
