Icom IC-2200H

Feb. 2010
11
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
C34 4030009500 S.CER C1608 CH 1H 0R5B-T T 41.6/29.3
C36 4030006860 S.CER C1608 JB 1H 102K-T T 32.9/23
C37 4030009500 S.CER C1608 CH 1H 0R5B-T T 41.6/28
C38 4030006860 S.CER C1608 JB 1H 102K-T T 40.4/22.8
C39 4030011600 S.CER C1608 JB 1E 104K-T B 57.5/20.1
C40 4030006860 S.CER C1608 JB 1H 102K-T T 72.9/12.8
C41 4030006860 S.CER C1608 JB 1H 102K-T T 68.2/10.1
C42 4030006860 S.CER C1608 JB 1H 102K-T T 66.6/11.4
C44 4030006860 S.CER C1608 JB 1H 102K-T T 52.4/26.4
C45 4030006860 S.CER C1608 JB 1H 102K-T B 56.2/20.1
C47 4030011600 S.CER C1608 JB 1E 104K-T B 59.3/19.3
C48 4030006860 S.CER C1608 JB 1H 102K-T T 48/27.3
C49 4030007010 S.CER C1608 CH 1H 100D-T T 53.9/24
C50 4030006940 S.CER C1608 CH 1H 030C-T T 52.4/19.1
C51 4030006860 S.CER C1608 JB 1H 102K-T T 48.9/37.8
C52 4030006860 S.CER C1608 JB 1H 102K-T T 48.9/39.1
C53 4030006860 S.CER C1608 JB 1H 102K-T B 60.6/23.2
C54 4030007000 S.CER C1608 CH 1H 090D-T T 56.8/26.9
C55 4030007050 S.CER C1608 CH 1H 220J-T T 57.6/18.4
C56 4030006860 S.CER C1608 JB 1H 102K-T T 56/29.5
C57 4030006860 S.CER C1608 JB 1H 102K-T T 52.4/20.4
C58 4030006860 S.CER C1608 JB 1H 102K-T T 52.4/21.7
C59 4030006860 S.CER C1608 JB 1H 102K-T T 41.7/46.5
C60 4030006860 S.CER C1608 JB 1H 102K-T B 67.9/16
C61 4030007050 S.CER C1608 CH 1H 220J-T B 54.1/27.1
C62 4030007020 S.CER C1608 CH 1H 120J-T T 54.2/15.1
C63 4030006860 S.CER C1608 JB 1H 102K-T T 30/52
C64 4030011600 S.CER C1608 JB 1E 104K-T T 41.3/51.5
C65 4030007050 S.CER C1608 CH 1H 220J-T B 54.1/28.5
C66 4030007050 S.CER C1608 CH 1H 220J-T B 63.1/24.5
C67 4030006860 S.CER C1608 JB 1H 102K-T B 55.6/30.6
C68 4030007000 S.CER C1608 CH 1H 090D-T T 54.2/16.6
C69 4510008540 S.ELE EEE1CA100SR T 36.5/46.9
C70 4030006860 S.CER C1608 JB 1H 102K-T B 68.3/29.9
C71 4030007090 S.CER C1608 CH 1H 470J-T B 67.3/24.5
C72 4030006860 S.CER C1608 JB 1H 102K-T B 50.7/33.8
C73 4030007050 S.CER C1608 CH 1H 220J-T B 71.5/24.5
C74 4030006860 S.CER C1608 JB 1H 102K-T B 45.1/37
C75 4030006860 S.CER C1608 JB 1H 102K-T B 109.8/21.2
C76 4030006980 S.CER C1608 CH 1H 070D-T B 43/37.4
C77 4030006900 S.CER C1608 JB 1H 103K-T B 102.5/20.8
C78 4030011600 S.CER C1608 JB 1E 104K-T B 111.4/16.7
C79 4030007080 S.CER C1608 CH 1H 390J-T B 72.5/32
C80 4030007050 S.CER C1608 CH 1H 220J-T B 102/22.8
C81 4030006900 S.CER C1608 JB 1H 103K-T B 112/18.7
C82 4510008540 S.ELE EEE1CA100SR T 103.9/19.2
C83 4030012600 S.CER C2012 JB 1A 105M-T B 113.6/19.1
C84 4030007170 S.CER C1608 CH 1H 221J-T B 112.5/12.7
C85 4030007170 S.CER C1608 CH 1H 221J-T B 111.9/14.7
C86 4030006860 S.CER C1608 JB 1H 102K-T B 106.9/21.2
C87 4030007100 S.CER C1608 CH 1H 560J-T B 73.8/32
C88 4030007060 S.CER C1608 CH 1H 270J-T B 74.3/35.3
C89 4030006900 S.CER C1608 JB 1H 103K-T B 98.7/23.4
C90 4030007070 S.CER C1608 CH 1H 330J-T B 41.3/44.8
C91 4030006860 S.CER C1608 JB 1H 102K-T B 41.3/43.5
C92 4030006860 S.CER C1608 JB 1H 102K-T B 74.8/36.5
C93 4030006910 S.CER C1608 CH 1H 0R5C-T B 97.1/28.7
C94 4030006860 S.CER C1608 JB 1H 102K-T B 100.7/19.6
C95 4030006860 S.CER C1608 JB 1H 102K-T B 98.1/20
C97 4030006960 S.CER C1608 CH 1H 050C-T B 88.7/28.7
C98 4030008900 S.CER C1608 JB 1H 333K-T B 99.4/17.2
C100 4030007120 S.CER C1608 CH 1H 820J-T B 98.7/13
C101 4030006860 S.CER C1608 JB 1H 102K-T B 103.5/14.2
C105 4030006860 S.CER C1608 JB 1H 102K-T B 103.5/12.9
C108 4030006860 S.CER C1608 JB 1H 102K-T B 78.5/40.1
C111 4030009990 S.CER C1608 CH 1H 200J-T B 77.2/32.5
C113 4030006860 S.CER C1608 JB 1H 102K-T B 80/35.4
C117 4030006900 S.CER C1608 JB 1H 103K-T B 86.9/24.3
C118 4510008520 S.ELE EEE1CA470SP T 62.5/64.7
C120 4030006900 S.CER C1608 JB 1H 103K-T B 81.8/23.3
C122 4030006860 S.CER C1608 JB 1H 102K-T T 68.4/65.6
C123 4030006860 S.CER C1608 JB 1H 102K-T T 46.9/57
C124 4030006960 S.CER C1608 CH 1H 050C-T B 81.4/42.2
C125 4510008540 S.ELE EEE1CA100SR T 44.5/50.2
C127 4030006920 S.CER C1608 CH 1H 010C-T B 83.5/42
C128 4030006860 S.CER C1608 JB 1H 102K-T B 84.3/37.1
C131 4030007120 S.CER C1608 CH 1H 820J-T B 84.8/42
C133 4030006920 S.CER C1608 CH 1H 010C-T B 87.4/42
C134 4030006860 S.CER C1608 JB 1H 102K-T B 91.6/12.5
C136 4030006920 S.CER C1608 CH 1H 010C-T B 86.1/42
C137 4030006860 S.CER C1608 JB 1H 102K-T T 46.4/58.3
C138 4030006860 S.CER C1608 JB 1H 102K-T B 88.2/37.1
C139 4030007120 S.CER C1608 CH 1H 820J-T B 88.7/42
C140 4030006900 S.CER C1608 JB 1H 103K-T B 88.2/24.3
C141 4030006930 S.CER C1608 CH 1H 020C-T B 90.1/42
C145 4030006920 S.CER C1608 CH 1H 010C-T B 91.4/42
C146 4030006860 S.CER C1608 JB 1H 102K-T B 93.5/37.1
C148 4030007150 S.CER C1608 CH 1H 151J-T B 94/42
C149 4030011600 S.CER C1608 JB 1E 104K-T B 91.8/54.1
C152 4030009510 S.CER C1608 CH 1H 010B-T B 92.7/42
C153 4030011600 S.CER C1608 JB 1E 104K-T B 89.2/55.4
C154 4030006860 S.CER C1608 JB 1H 102K-T B 19.5/51.1
C157 4510008810 S.ELE EEE1CA331UP T 24.9/48
C158 4030006860 S.CER C1608 JB 1H 102K-T B 95.3/42
C160 4030006860 S.CER C1608 JB 1H 102K-T B 96.6/41
C161 4030006860 S.CER C1608 JB 1H 102K-T T 87.7/42.5
C162 4030009550 S.CER C1608 CH 1H 2R5B-T B 102/42.2
C163 4030006860 S.CER C1608 JB 1H 102K-T B 93.7/58
C164 4030006860 S.CER C1608 JB 1H 102K-T B 104.6/39.4
C166 4510008500 S.ELE EEE1CA101WP T 16.9/47.9
C168 4030006860 S.CER C1608 JB 1H 102K-T B 10.8/52.2
C169 4030006860 S.CER C1608 JB 1H 102K-T B 83.5/55.1
C170 4030006860 S.CER C1608 JB 1H 102K-T B 106.7/39.9
C172 4030006860 S.CER C1608 JB 1H 102K-T B 10.8/53.5
C173 4030006860 S.CER C1608 JB 1H 102K-T B 21.3/58.5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
C174 4030006860 S.CER C1608 JB 1H 102K-T T 86.6/57.8
C175 4510008810 S.ELE EEE1CA331UP T 18.9/56.9
C176 4030011040 S.CER GRM31M4C2H2R0CY21L
(GRM42-6 CK) T 87.3/64.5
C177 4510008540 S.ELE EEE1CA100SR T 37/54.9
C178 4030007010 S.CER C1608 CH 1H 100D-T B 111.1/43.3
C179 4030006860 S.CER C1608 JB 1H 102K-T T 25.8/60.1
C180 4030006860 S.CER C1608 JB 1H 102K-T B 117.8/40.3
C181 4510008550 S.ELE EEE1HA010SR T 26.9/10.7
C182 4030007150 S.CER C1608 CH 1H 151J-T B 115.7/43.8
C184 4030006960 S.CER C1608 CH 1H 050C-T B 115.7/47.6
C185 4030006860 S.CER C1608 JB 1H 102K-T B 18.5/5
C187 4030006860 S.CER C1608 JB 1H 102K-T B 112.3/47.1
C188 4510008550 S.ELE EEE1HA010SR T 16.3/12.5
C189 4030006860 S.CER C1608 JB 1H 102K-T B 20.4/62.3
C190 4030011020 S.CER GRM31M4C2H1R0CY21L
(GRM42-6 CK) T 111.6/68.7
C191 4030007020 S.CER C1608 CH 1H 120J-T T 107.2/67.7
C192 4030006860 S.CER C1608 JB 1H 102K-T T 19.9/15
C193 4030006860 S.CER C1608 JB 1H 102K-T B 112.3/48.4
C194 4510008500 S.ELE EEE1CA101WP T 20/40
C195 4510008520 S.ELE EEE1CA470SP T 24.9/31.5
C196 4030011020 S.CER GRM31M4C2H1R0CY21L
(GRM42-6 CK) T 105.9/74.7
C197 4030007020 S.CER C1608 CH 1H 120J-T T 101.9/75.1
C198 4030006860 S.CER C1608 JB 1H 102K-T T 103.5/70.2
C200 4030006860 S.CER C1608 JB 1H 102K-T T 23.7/62.2
C201 4030007050 S.CER C1608 CH 1H 220J-T T 111.4/52.5
C204 4510008870 S.ELE EEE1AA471UP T 12.5/82.6
C205 4030006860 S.CER C1608 JB 1H 102K-T B 16.8/70.5
C206 4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [TPE-1] T 101.2/55.6
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [KOR-1]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [SEA-2]
4030011110 S.CER GRM31M2C2H9R0DV01L
(GRM42-6 CH) [THA-1]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [EXP-2]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [AUS-1]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [SEA-3]
4030011050 S.CER GRM31M3C2H3R0CY21L
(GRM42-6 CJ) [EXP-3]
C207 4510006021 ELE 16 ME 2200 HC
C208 4030011210 S.CER GRM31M2C2H330JV01L
(GRM42-6 CH) T 102.8/82.7
C209 4030011600 S.CER C1608 JB 1E 104K-T B 111/49.8
C210 4030011160 S.CER GRM31M2C2H150JV01L
(GRM42-6 CH) T 106.7/90.9
C211 4030006860 S.CER C1608 JB 1H 102K-T B 111/51.2
C212 4030006860 S.CER C1608 JB 1H 102K-T B 18.4/32.6
C215 4030011600 S.CER C1608 JB 1E 104K-T T 66.5/60.6
C216 4030011600 S.CER C1608 JB 1E 104K-T T 109.4/18
C217 4030011230 S.CER GRM31M2C2H390JV01L
(GRM42-6 CH) T 102.8/77.3
C218 4030011190 S.CER GRM31M2C2H270JV01L
(GRM42-6 CH) T 106.8/60.3
C221 4030010780 S.CER C1608 CH 1H 1R5C-T T 117.6/47.3
C222 4030006900 S.CER C1608 JB 1H 103K-T B 102/39.4
C224 4030011600 S.CER C1608 JB 1E 104K-T B 114.3/24.1
C225 4030017200 S.CER GRM31BR32J102KY01L T 106.8/57.7
C227 4030011210 S.CER GRM31M2C2H330JV01L
(GRM42-6 CH) T 106.8/65.5
C228 4030006900 S.CER C1608 JB 1H 103K-T T 75.1/17.6
C230 4510008540 S.ELE EEE1CA100SR [TPE-1] T 105.1/24.7
4510008540 S.ELE EEE1CA100SR [KOR-1]
4510008540 S.ELE EEE1CA100SR [SEA-2]
4510008540 S.ELE EEE1CA100SR [THA-1]
4510008540 S.ELE EEE1CA100SR [EXP-2]
C232 4030011600 S.CER C1608 JB 1E 104K-T B 98.5/10.9
C233 4030011600 S.CER C1608 JB 1E 104K-T B 107.4/11
C240 4030006860 S.CER C1608 JB 1H 102K-T B 66.2/30.6
C241 4030011600 S.CER C1608 JB 1E 104K-T B 78/23.1
C242 4030006860 S.CER C1608 JB 1H 102K-T B 48.5/34.8
C243 4030017810 S.CER C1608 CH 1H 102J-T B 78/27.4
C244 4030011600 S.CER C1608 JB 1E 104K-T B 99.7/26.6
C245 4030008680 S.CER C2012 JF 1C 105Z-T B 98.2/41
C246 4030006860 S.CER C1608 JB 1H 102K-T T 67.1/65.6
C247 4030006860 S.CER C1608 JB 1H 102K-T T 46.3/62.5
C250 4030007100 S.CER C1608 CH 1H 560J-T B 42/53.9
C251 4030006860 S.CER C1608 JB 1H 102K-T B 37.8/52.8
C252 4030006860 S.CER C1608 JB 1H 102K-T B 39.1/52.8
C253 4030007020 S.CER C1608 CH 1H 120J-T B 38.5/44.8
C254 4550006080 S.TAN TEESVB2 1C 106M8R B 35.5/54.3
C255 4030006860 S.CER C1608 JB 1H 102K-T T 84.4/48.9
C256 4030006860 S.CER C1608 JB 1H 102K-T T 90.5/53.7
C257 4030006860 S.CER C1608 JB 1H 102K-T T 83.7/52.3
C258 4030006860 S.CER C1608 JB 1H 102K-T T 90.5/55.1
C259 4030006860 S.CER C1608 JB 1H 102K-T T 84.9/35.2
C265 4030006860 S.CER C1608 JB 1H 102K-T T 102.2/5.2
C266 4030006860 S.CER C1608 JB 1H 102K-T T 110/16.1
C267 4030006860 S.CER C1608 JB 1H 102K-T T 111.8/4.9
C268 4030006900 S.CER C1608 JB 1H 103K-T T 105/5.2
C269 4030006900 S.CER C1608 JB 1H 103K-T T 106.9/13.4
C271 4550007610 S.TAN F931E474MAABMA T 102.6/14
C272 4030011600 S.CER C1608 JB 1E 104K-T T 104.3/13.4
C273 4550006480 S.TAN TEESVA 1C 475M8R T 111.8/9
C278 4510008580 S.ELE EEE0JA470SR T 25.1/16.8
C279 4510008550 S.ELE EEE1HA010SR T 23.3/24.2
C280 4340000250 S.MYL ECHU 1C 104JX5 B 23.6/26.4
C281 4510009160 S.ELE EEE1HA010NR T 88.1/14.3
C282 4030006860 S.CER C1608 JB 1H 102K-T B 98.5/65.5
