[FRONT UNIT][FRONT UNIT]
IC1 1140011470 S.IC HD6433687A37FP (FX-2622B) B
IC2 1110005770 S.IC S-80942CNMC-G9C-T2 B
IC3 1140008650 S.IC HN58X2464TI B
IC5 1110005340 S.IC NJM12902V-TE1 B
IC6 1130009090 S.IC LC75834W-TLM B
Q1 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) B
Q2 1590001050 S.TRANSISTOR DTC114TUA T106 B
Q3 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q5 1590001050 S.TRANSISTOR DTC114TUA T106 B
D1 1790000950 S.ZENER MA8056-M (TX) B
D2 1790000950 S.ZENER MA8056-M (TX) T
D3 1790000950 S.ZENER MA8056-M (TX) B
D4 1790000620 S.DIODE MA77 (TX) B
D5 1790001250 S.DIODE MA2S111-(TX) B
X1 6050009520 S.XTAL CR-520 (19.6608 MHz+) B
L1 6200003640 S.COIL MLF1608E 100K-T B
L2 6200001980 S.COIL NL 252018T-1R0J B
R7 7030009160 S.RESISTOR ERJ2GEJ 181 X (180 Ω) B
R8 7030009160 S.RESISTOR ERJ2GEJ 181 X (180 Ω) B
R9 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) B
R11 7030009280 S.RESISTOR ERJ2GE B
R12 7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ) B
R14 7210003020 VARIABLE EVU-F2KFK1 B14 (10KB) T
R15 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R16 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R18 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R19 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R20 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ) B
R21 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ) B
R22 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) B
R23 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R24 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R25 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) B
R26 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R27 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R28 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R29 7030008290 S.RESISTOR ERJ2GEJ 183 X (18 kΩ) B
R30 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) B
R31 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R32 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R33 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) B
R34 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) B
R35 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) B
R36 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) B
R37 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) B
R38 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) B
R39 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) B
R40 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R41 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R42 7030007350 S.RESISTOR ERJ2GEJ 393 X (39 kΩ) B
R43 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) B
R44 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) B
R45 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R46 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R47 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) B
R48 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) B
R49 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) B
R50 7410001130 S.ARRAY EXB28V102JX B
R51 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R52 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R54 7410001130 S.ARRAY EXB28V102JX B
R55 7410000770 S.ARRAY EXB-V4V 102JV (1 kΩ) B
R56 7410001130 S.ARRAY EXB28V102JX B
R57 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) B
R58 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R59 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103 T
R60 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R65 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R67 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R68 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R73 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
S.=Surface mount
R74 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R75 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R76 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R77 7030005030 S.RESISTOR ERJ2GEJ 152 X (1.5 kΩ) B
R78 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R79 7410000770 S.ARRAY EXB-V4V 102JV (1 kΩ) B
R80 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R81 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R82 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R83 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R84 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R85 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R86 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R87 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R88 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R89 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R90 7030006610 S.RESISTOR ERJ2GEJ 394 X (390 kΩ) T
C1 4030018100 S.CERAMIC ECJ0EB1H681K B
C2 4030017420 S.CERAMIC ECJ0EC1H470J B
C3 4030017420 S.CERAMIC ECJ0EC1H470J B
C4 4030017420 S.CERAMIC ECJ0EC1H470J B
C5 4030017420 S.CERAMIC ECJ0EC1H470J B
C6 4030017420 S.CERAMIC ECJ0EC1H470J B
C7 4030017420 S.CERAMIC ECJ0EC1H470J B
C8 4030017460 S.CERAMIC ECJ0EB1E102K B
C9 4030017460 S.CERAMIC ECJ0EB1E102K B
C10 4030017460 S.CERAMIC ECJ0EB1E102K B
C11 4030017420 S.CERAMIC ECJ0EC1H470J T
C12 4030017460 S.CERAMIC ECJ0EB1E102K B
C14 4030017460 S.CERAMIC ECJ0EB1E102K B
C15 4030016960 S.CERAMIC ECJ0EB1C183K B
C16 4030016930 S.CERAMIC ECJ0EB1A104K B
C17 4030017740 S.CERAMIC ECJ0EB1E821K B
C19 4030016930 S.CERAMIC ECJ0EB1A104K B
C20 4030018110 S.CERAMIC ECJ0EB1H272K B
C21 4030018240 S.CERAMIC ECJ0EB1E562K B
C22 4030017710 S.CERAMIC ECJ0EC1H181J B
C23 4030018090 S.CERAMIC ECJ0EB1C822K B
C24 4030017510 S.CERAMIC ECJ0EC1H680J B
C25 4030016790 S.CERAMIC ECJ0EB1C103K B
C26 4030016930 S.CERAMIC ECJ0EB1A104K B
C27 4030017450 S.CERAMIC ECJ0EB1E271K B
C28 4030016930 S.CERAMIC ECJ0EB1A104K B
C29 4550006050 S.TANTALUM TEESVA 0J 106M8L B
C30 4030017030 S.CERAMIC ECJ0EB1A273K B
C31 4030017400 S.CERAMIC ECJ0EC1H220J B
C32 4030017640 S.CERAMIC ECJ0EC1H150J B
C33 4030017510 S.CERAMIC ECJ0EC1H680J B
C34 4030017730 S.CERAMIC ECJ0EB1E471K B
C35 4030016930 S.CERAMIC ECJ0EB1A104K B
C36 4030016930 S.CERAMIC ECJ0EB1A104K B
C37 4030017420 S.CERAMIC ECJ0EC1H470J B
C38 4030017420 S.CERAMIC ECJ0EC1H470J B
C41 4030017460 S.CERAMIC ECJ0EB1E102K B
C50 4030017420 S.CERAMIC ECJ0EC1H470J B
C54 4030017420 S.CERAMIC ECJ0EC1H470J B
C69 4030017420 S.CERAMIC ECJ0EC1H470J B
C74 4030017420 S.CERAMIC ECJ0EC1H470J B
C75 4030016930 S.CERAMIC ECJ0EB1A104K B
C76 4030016930 S.CERAMIC ECJ0EB1A104K B
C77 4030016950 S.CERAMIC ECJ0EB1A473K B
C78 4030017460 S.CERAMIC ECJ0EB1E102K B
C79 4030016930 S.CERAMIC ECJ0EB1A104K B
C80 4030016930 S.CERAMIC ECJ0EB1A104K B
C81 4030017460 S.CERAMIC ECJ0EB1E102K T
C82 4030017420 S.CERAMIC ECJ0EC1H470J B
C83 4030017420 S.CERAMIC ECJ0EC1H470J B
C84 4030017420 S.CERAMIC ECJ0EC1H470J B
C85 4030017420 S.CERAMIC ECJ0EC1H470J B
J1 6450002210 CONNECTOR 3017-8821 <KIN> T
J2 6510022470 S.CONNECTOR 40FLT-SM1-TB B
J3 6510022020 S.CONNECTOR 14FLT-SM1-TB B
DS1 5040002310 S.LED SML-311YTT86 T
DS2 5040002310 S.LED SML-311YTT86 T
DS3 5040002310 S.LED SML-311YTT86 T
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
