[FRONT UNIT]
DS4 5040002310 S.LED SML-311YTT86 T
DS5 5040002310 S.LED SML-311YTT86 T
DS6 5040002310 S.LED SML-311YTT86 T
DS7 5040002310 S.LED SML-311YTT86 T
DS8 5040002310 S.LED SML-311YTT86 T
DS9 5040002310 S.LED SML-311YTT86 T
DS11 5030002510 LCD L2-0607TAY T
SP1 2510001220 SPEAKER C052SB500-13
W1 8900010500 CABLE OPC-1046 B
EP1 0910055684 PCB B 5910D
EP2 8930059170 LCD CONTACT SRCN-2622-SP-N-W T
IC1 1110003490 S.IC TA31136FN (D,EL) T
IC2 1110002750 S.IC TA75S01F (TE85R) T
IC3 1150002031 IC RA30H4452M-21 T
IC4 1140005990 S.IC MB15A02PFV1-G-BND-ER T
IC5 1110005330 S.IC NJM12904V-TE1 T
IC6 1190000350 S.IC M62363FP-650C B
IC8 1110003090 IC LA4425A T
IC9 1180001250 S.IC TA7808F (TE16L) T
IC10 1180000970 S.IC AN78L05M-(E1) B
IC14 1130008090 S.IC BU4066BCFV-E1 B
IC15 1110002750 S.IC TA75S01F (TE85R) B
IC16 1110005340 S.IC NJM12902V-TE1 B
IC17 1130007570 S.IC BU4094BCFV-E2 B
Q1 1560000840 S.FET 2SK1829 (TE85R) B
Q2 1580000730 S.FET 3SK293 (TE85L) B
Q3 1580000760 S.FET 3SK299-T1 U73 B
Q4 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q5 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q8 1530000371 S.TRANSISTOR 2SC3356-T1B R25 B
Q9 1530003310 S.TRANSISTOR 2SC5107-O (TE85R) B
Q10 1530003310 S.TRANSISTOR 2SC5107-O (TE85R) B
Q11 1530003310 S.TRANSISTOR 2SC5107-O (TE85R) T
Q12 1530003310 S.TRANSISTOR 2SC5107-O (TE85R) T
Q13 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q14 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q15 1590001400 S.TRANSISTOR XP1214 (TX) B
Q16 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q17 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) B
Q18 1560000540 S.FET 2SK880-Y (TE85R) T
Q19 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) B
Q23 1550000020 S.FET 2SJ377 (TE16R) T
Q24 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q25 1540000550 S.TRANSISTOR 2SD1664 T100Q B
Q26 1510000920 S.TRANSISTOR 2SA1577 T106 Q B
Q27 1510000920 S.TRANSISTOR 2SA1577 T106 Q B
Q28 1590001190 S.TRANSISTOR XP6501-(TX) .AB B
Q29 1590001050 S.TRANSISTOR DTC114TUA T106 B
Q30 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q31 1590001450 S.FET 2SJ144-GR (TE85R) B
Q33 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q34 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) B
Q35 1590000990 S.TRANSISTOR DTC363EK T146 B
Q36 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q37 1530003090 S.TRANSISTOR 2SC4213-B (TE85R) T
Q38 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q39 1590000430 S.TRANSISTOR DTC144EUA T106 T
D1 1790000660 S.DIODE MA728 (TX) B
D2 1750000510 S.DIODE UM9401F T
D4 1750000710 S.VARICAP HVC350BTRF B
D5 1750000510 S.DIODE UM9401F T
D7 1790000660 S.DIODE MA728 (TX) B
D8 1750000710 S.VARICAP HVC350BTRF B
D9 1750000710 S.VARICAP HVC350BTRF B
D10 1750000710 S.VARICAP HVC350BTRF B
D11 1790000660 S.DIODE MA728 (TX) B
D14 1750000580 S.DIODE 1SV307 (TPH3) B
S.=Surface mount
6 - 2
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
NO. NO.
[MAIN UNIT]
[MAIN UNIT]
D15 1790000620 S.DIODE MA77 (TX) B
D16 1750000710 S.VARICAP HVC350BTRF T
D17 1750000710 S.VARICAP HVC350BTRF T
D18 1720000570 S.VARICAP MA368 (TX) B
D20 1790001250 S.DIODE MA2S111-(TX) B
D21 1750000830 S.VARICAP HVC362TRF T
D22 1790000700 DIODE DSA3A1 B
D23 1750000370 S.DIODE DA221 TL B
D25 1790001250 S.DIODE MA2S111-(TX) B
D26 1790001250 S.DIODE MA2S111-(TX) B
D28 1790001250 S.DIODE MA2S111-(TX) T
D29 1790001250 S.DIODE MA2S111-(TX) B
D31 1750000520 S.DIODE DAN222TL B
D37 1790001250 S.DIODE MA2S111-(TX) T
D38 1790001250 S.DIODE MA2S111-(TX) T
D39 1160000140 S.DIODE DAP222 TL B
D40 1160000140 S.DIODE DAP222 TL B
D43 1750000710 S.VARICAP HVC350BTRF B
FI1 2030000150 S.MONOLITH FL-335 (46.350 MHz) T
FI2 2020001840 CERAMIC ALFYM450F=K B
FI3 2040001440 S.LC
NFE31PT152Z1E9L (NFM60R20T152)
B
FI4 2040001440 S.LC
NFE31PT152Z1E9L (NFM60R20T152)
B
X1 6070000190
S.DISCRIMINATOR
CDBCB450KCAY24-R0 (CDBC450CX24)
T
X2 6050011540 S.XTAL CR-741 (15.300 MHz) B
L1 6200010150 S.COIL AS080340-15N T
L2 6200010150 S.COIL AS080340-15N T
L3 6200010040 S.COIL AS100340-10N T
L4 6200008210 S.COIL 0.45-1.5-5TL 23.2N T
L5 6200010420 S.COIL FHW1210HC 1R0JGT T
L7 6200007680 S.COIL
LQW2BHN12NJ01L (LQN21A 12NJ04)
B
L8 6200007680 S.COIL
LQW2BHN12NJ01L (LQN21A 12NJ04)
B
L9 6200007680 S.COIL
LQW2BHN12NJ01L (LQN21A 12NJ04)
B
L10 6200004660 S.COIL MLF1608A 1R8K-T T
L11 6200007680 S.COIL
LQW2BHN12NJ01L (LQN21A 12NJ04)
B
L12 6200005720 S.COIL ELJRE 33NG-F B
L13 6200003010 S.COIL NL 322522T-R27J-3 B
L16 6200010150 S.COIL AS080340-15N T
L17 6200005660 S.COIL ELJRE 10NG-F B
L18 6200005680 S.COIL ELJRE 15NG-F T
L19 6200005710 S.COIL ELJRE 27NG-F B
L20 6200005710 S.COIL ELJRE 27NG-F B
L21 6200005700 S.COIL ELJRE 22NG-F B
L23 6200002850 S.COIL NL 252018T-R82J B
L25 6200009360 S.COIL 0.45-1.4-3TL 11N T
L26 6200009360 S.COIL 0.45-1.4-3TL 11N T
L27 6200004950 S.COIL NL 252018T-1R8J B
L28 6200002710 S.COIL ELJFC 1R8K-F B
L29 6200004660 S.COIL MLF1608A 1R8K-T T
L31 6200005720 S.COIL ELJRE 33NG-F B
L32 6200005680 S.COIL ELJRE 15NG-F B
L33 6200002850 S.COIL NL 252018T-R82J B
L35 6200002840 S.COIL NL 252018T-R22J B
L37 6200006980 S.COIL ELJRE R10G-F T
L38 6200005700 S.COIL ELJRE 22NG-F B
L41 6200005710 S.COIL ELJRE 27NG-F T
L42 6200005640 S.COIL ELJRE 6N8Z-F T
L43 6200005720 S.COIL ELJRE 33NG-F B
R1 7030000620 S.RESISTOR MCR10EZHJ 100 kΩ B
R2 7030000220 S.RESISTOR MCR10EZHJ 47 Ω (470) B
R3 7030000220 S.RESISTOR MCR10EZHJ 47 Ω (470) B
R4 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R5 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R6 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R7 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R8 7030006070 S.RESISTOR ERJ12YJ101U (100 Ω) B
R10 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ) B
R11 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R12 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R13 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R14 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R15 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R16 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω) B
R17 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) B
R18 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R19 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ) B
R20 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R21 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R22 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R23 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R25 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
REF ORDER
DESCRIPTION M.
NO. NO.
