[MAIN UNIT]
R28 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R29 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω) B
R30 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R31 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R32 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω) T
R33 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω) T
R34 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ) T
R35 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R36 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ) T
R37 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) T
R38 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R39 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) B
R40 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R43 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R44 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R45 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R46 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω) B
R50 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R51 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) T
R52 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R53 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) T
R54 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R55 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R56 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R57 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R58 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R59 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ) T
R61 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω) B
R62 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) B
R65 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω) B
R66 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R67 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R68 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R69 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R70 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R71 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω) T
R72 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R73 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R74 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R75 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R76 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω) T
R77 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R78 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R79 7030005341 S.RESISTOR ERA3YED 332V T
R80 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R81 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω) T
R82 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω) T
R83 7030005341 S.RESISTOR ERA3YED 332V T
R84 7030005341 S.RESISTOR ERA3YED 332V T
R85 7030005341 S.RESISTOR ERA3YED 332V T
R86 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R87 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R89 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R90 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) B
R91 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R92 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ) B
R93 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R95 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R96 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ) T
R97 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R98 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R100 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R101 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R103 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
R104 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) B
R105 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R106 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R110 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) B
R111 7030006571 S.RESISTOR ERA3YED 392V T
R112 7030008071 S.RESISTOR ERA3YED 273V T
R113 7030008061 S.RESISTOR ERA3YED 222V T
R114 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) T
R115 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) B
R116 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) B
R117 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ) B
R118 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) T
R119 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) T
R120 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R121 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R122 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R124 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R125 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R126 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R127 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R128 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R129 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R130 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R133 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) T
S.=Surface mount
6 - 3
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
R134 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ) T
R135 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ) T
R136 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R137 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R138 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R139 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R140 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R141 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R142 7410001130 S.ARRAY EXB28V102JX T
R143 7410001130 S.ARRAY EXB28V102JX T
R144 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R145 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R146 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R147 7410001130 S.ARRAY EXB28V102JX T
R148 7410001130 S.ARRAY EXB28V102JX T
R149 7410001130 S.ARRAY EXB28V102JX T
R150 7410001130 S.ARRAY EXB28V102JX T
R156 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R159 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R163 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R164 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R183 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) T
R184 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ) T
R185 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ) T
R186 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R187 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R188 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) T
R191 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R192 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R193 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) B
R194 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R195 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) B
R196 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R197 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R198 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R199 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R200 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R201 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R202 7030000440 S.RESISTOR MCR10EZHJ 3.3 kΩ B
R203 7030000440 S.RESISTOR MCR10EZHJ 3.3 kΩ B
R204 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R205 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R206 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) B
R207 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
R208 7030000440 S.RESISTOR MCR10EZHJ 3.3 kΩ B
R209 7510001470 S.THERMISTOR NTCG20 4AG 473JT T
R210 7030005871 S.RESISTOR ERA3YKD 104V (100 kΩ) T
R211 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω) B
R215 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R217 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R218 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R219 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R220 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R222 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R223 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R224 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) B
R225 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R226 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R227 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) B
R228 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R229 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) B
R230 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R231 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R232 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R234 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R235 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R236 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) B
R237 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ) B
R238 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R240 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R241 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R242 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) B
R243 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R244 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ) B
R245 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ) B
R246 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R247 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) B
R248 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) B
R249 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) B
R250 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R251 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) B
R252 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R261 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R262 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R263 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R264 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R265 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) T
R266 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
REF ORDER
DESCRIPTION M.
NO. NO.
