[MAIN UNIT]
R267 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ) T
R268 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R269 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R270 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R271 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R285 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R287 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R290 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) T
R291 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R292 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) B
R297 7030005651 S.RESISTOR ERA3YKD 304V (300 kΩ) T
R298 7030005871 S.RESISTOR ERA3YKD 104V (100 kΩ) T
R304 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R305 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R306 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω) T
R308 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) T
R309 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R310 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R315 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R316 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R317 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) T
R318 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R319 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R320 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) T
R322 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω) T
R323 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) B
C1 4030011100 S.CERAMIC
GRM31M2C2H8R0DV01L (GRM42-6 CH)
T
C2 4030011080 S.CERAMIC
GRM31M2C2H6R0DV01L (GRM42-6 CH)
T
C3 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C4 4030007010 S.CERAMIC C1608 CH 1H 100D-T B
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C6 4030011020 S.CERAMIC
GRM31M4C2H1R0CY21L (GRM42-6 CK)
T
C7 4030011060 S.CERAMIC
GRM31M2C2H4R0CY21L (GRM42-6 CH)
T
C8 4030011020 S.CERAMIC
GRM31M4C2H1R0CY21L (GRM42-6 CK)
T
C9 4030011060 S.CERAMIC
GRM31M2C2H4R0CY21L (GRM42-6 CH)
T
C10 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C12 4030011340 S.CERAMIC C1608 CH 1H 471J-T B
C13 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C14 4030011240 S.CERAMIC
GRM31M2C2H470JV01L (GRM42-6 CH)
T
C15 4030006990 S.CERAMIC C1608 CH 1H 080D-T B
C16 4030011040 S.CERAMIC
GRM31M4C2H2R0CY21L (GRM42-6 CK)
T
C18 4030011770 S.CERAMIC C1608 CH 1H 060B-T B
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C20 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C21 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T B
C22 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T B
C25 4030009520 S.CERAMIC C1608 CH 1H 020B-T B
C26 4030011770 S.CERAMIC C1608 CH 1H 060B-T B
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C29 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T B
C30 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C33 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C34 4030017460 S.CERAMIC ECJ0EB1E102K B
C35 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C37 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C38 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C39 4030006990 S.CERAMIC C1608 CH 1H 080D-T B
C40 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T B
C41 4030007030 S.CERAMIC C1608 CH 1H 150J-T B
C42 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C44 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T B
C45 4030006990 S.CERAMIC C1608 CH 1H 080D-T B
C48 4030007050 S.CERAMIC C1608 CH 1H 220J-T B
C49 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C50 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C51 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C52 4030007080 S.CERAMIC C1608 CH 1H 390J-T B
C53 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C54 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C55 4030009920 S.CERAMIC C1608 CH 1H 050B-T T
C56 4030007050 S.CERAMIC C1608 CH 1H 220J-T T
C57 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C58 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C59 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C60 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C61 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C62 4030007130 S.CERAMIC C1608 CH 1H 101J-T T
C63 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C64 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C65 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C66 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
S.=Surface mount
6 - 4
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
C67 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C69 4030011330 S.CERAMIC C1608 CH 1H 391J-T B
C70 4030011330 S.CERAMIC C1608 CH 1H 391J-T B
C71 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C73 4030017490 S.CERAMIC C1608 JB 1A 105K-T T
C75 4550006050 S.TANTALUM TEESVA 0J 106M8L T
C76 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C77 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C78 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C79 4030011810 S.CERAMIC C1608 JB 1A 224K-T T
C80 4030006880 S.CERAMIC C1608 JB 1H 472K-T T
C81 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C82 4030011040 S.CERAMIC
GRM31M4C2H2R0CY21L (GRM42-6 CK)
T
C83 4030011040 S.CERAMIC
GRM31M4C2H2R0CY21L (GRM42-6 CK)
T
C84 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C85 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C86 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C87 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C88 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C89 4030009910 S.CERAMIC C1608 CH 1H 040B-T T
C90 4030009520 S.CERAMIC C1608 CH 1H 020B-T T
C91 4510005750
S.ELECTROLYTIC
ECEV1EA220SP T
C92 4030006980 S.CERAMIC C1608 CH 1H 070D-T B
C93 4030009920 S.CERAMIC C1608 CH 1H 050B-T B
C94 4030009520 S.CERAMIC C1608 CH 1H 020B-T B
C96 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C97 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C98 4030009520 S.CERAMIC C1608 CH 1H 020B-T B
C99 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C100 4030007010 S.CERAMIC C1608 CH 1H 100D-T B
C101 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C102 4030007020 S.CERAMIC C1608 CH 1H 120J-T T
C103 4030009920 S.CERAMIC C1608 CH 1H 050B-T T
C104 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C105 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C106 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C107 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C108 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C109 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C110 4030011340 S.CERAMIC C1608 CH 1H 471J-T B
C111 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C112 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C113 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T T
C114 4030006980 S.CERAMIC C1608 CH 1H 070D-T T
C115 4030009910 S.CERAMIC C1608 CH 1H 040B-T T
C116 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C117 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C118 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T T
C119 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C120 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C121 4030007000 S.CERAMIC C1608 CH 1H 090D-T T
C122 4030006990 S.CERAMIC C1608 CH 1H 080D-T T
C123 4030006990 S.CERAMIC C1608 CH 1H 080D-T T
C124 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T T
C125 4030008210 S.CERAMIC C1608 UJ 1H 060D-T T
C126 4030007000 S.CERAMIC C1608 CH 1H 090D-T T
C127 4030009570 S.CERAMIC C1608 CH 1H 0R3B-T T
C128 4030008190 S.CERAMIC C1608 UJ 1H 040C-T T
C129 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T B
C130 4030008920 S.CERAMIC C1608 JB 1H 473K-T T
C131 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C132 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C133 4540000040 S.TRIMMER ECR-KN006 A61X T
C134 4540000040 S.TRIMMER ECR-KN006 A61X T
C138 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C139 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C140 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C141 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C142 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C143 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C144 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C145 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C146 4550000530 S.TANTALUM TEESVA 1V 104M8L T
C147 4550003220 S.TANTALUM TEESVA 1E 105M8L T
C148 4510004630
S.ELECTROLYTIC
ECEV1CA100SR T
C151 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C152 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C153 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C154 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C155 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C156 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C157 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C158 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C159 4030011600 S.CERAMIC C1608 JB 1E 104K-T B
C160 4030007000 S.CERAMIC C1608 CH 1H 090D-T B
C161 4030007130 S.CERAMIC C1608 CH 1H 101J-T B
C162 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C163 4510004630
S.ELECTROLYTIC
ECEV1CA100SR T
REF ORDER
DESCRIPTION M.
NO. NO.
