Its Mostly About The Receiver - Some Terms
Bandwidth, Dynamic Range and Signal to Noise Ratio
4
Not to Scale
• Bandwidth – tools to limit your receiver so it “hears” only
what you want to hear and to protect it from overload
• Mostly about filters
• Dynamic Range – the difference between the loudest and
the weakest signal you rig can handle
• Want to maximize Dynamic Range for the target signal
• Mostly about adjusting for optimum RF gain and
operation of Automatic Gain Controls
• Signal to Noise Ratio – the relative power between the signal
you are trying to hear (good) and noise/interference (bad)
• Noise reduction processors to reduce noise along with
proper use of other controls

Icom IC-7300 Specifications

General

Product type	Portable CB radio
Product color	Black
Housing material	Steel
Input voltage	13.8 V
Microphone included	Yes
Output power	100 W
Frequency range	0.5 - 70 MHz
Channels quantity	101 channels
Compatible products	AH-2B; AH-4; AH-5NV; AH-710; AH-740; CT-17; HM-219; MB-118; MB-123; OPC-2321; OPC-420; OPC-599; PS-126; RC-28; SM-30; SM-50; SP-23; SP-33; SP-34; SP-35; SP-35L; SP-38; SP-41;
Display type	LCD

Weight and Dimensions

Depth	238 mm
Width	240 mm
Height	94 mm
