Its Mostly About The Receiver
Controls to Optimize Weak Signals
7
Not to Scale
• Filters Limit Bandwidth and optimize adjacent signal rejection
• RF Gain Control, Preamp/Attenuator, and AGC Time Constant settings
optimize Dynamic Range
• Adaptive Noise Filtering is used to reduce noise; improving S/N Ratio
RF
Gain
Adjusts *’ed
Items
Preamp/
Attenuator
Noise
Reduction/
Blanker*
Passband Tuning
(DSP) Filter & IF Shift
Access Function Screen
(AGC Controls)
To Next Page
