5 - 5
J151
TX peak check point
TX peak
adjustment
L271
L253
L251
L251
L252
R546
Transmitter total
gain adjustment
L330
TX peak adjustment
R555
Ic APC adjustment
R204, R215
Idling current adjustment
for 144 MHz band
final amplifier
R11
Idling current adjustment
for driver
R18, R109
Idling current adjustment
for HF/50 MHz bands
final amplifier
C202
TX peak adjustment
