6 - 1
[FRONT UNIT] (FR)
REF ORDER
DESCRIPTION
QTY.
NO. NO.
W1 8900018460 OPC-1950 1
W2 8900009231 OPC-908A 1
W3 8900017820 OPC-852A 1
W4 8900009231 OPC-908A 1
W5 8900009231 OPC-908A 1
W6 8900009231 OPC-908A 1
W7 8900018480 OPC-1952 1
W8 8900018480 OPC-1952 1
EP1 6910020500 RMS20-250-201-1P/E 1
EP2 6910015650 MOUNT PLATE (S-G2218-3#01) 1
EP3 6910015650 MOUNT PLATE (S-G2218-3#01) 1
MP1 8210025390 3073 FRONT PANEL (Incl. MP13–15) 1
MP2 8010021410 3073 SUB CHASSIS (Incl. MP3) 1
MP3 8930077140 3073 JACK PLATE 1
MP4 8310072650 3073 WINDOW PLATE 1
MP5 8510019120 3073 LOGIC COVER 1
MP11 8930076840 3073 A-LENS 3
MP12 8930076850 3073 B-LENS 5
MP13 8930076860 3073 C-LENS 1
MP14 8930076870 3073 D-LENS 3
MP15 8930076880 3073 E-LENS 1
MP21 8610013940 KNOB K-281 (Incl. MP11) 1
MP22 8610013950 KNOB K-282 (Incl. MP11) 1
MP23 8610013960 KNOB K-283 (Incl. MP12) 1
MP24 8610013810 KNOB K-284 1
MP25 8610013820 KNOB K-285 1
MP26 8610013830 KNOB K-286 1
MP27 8610013970 KNOB K-287 (Incl. MP12) 1
MP28 8610013850 KNOB K-288 1
MP29 8610013860 KNOB K-289 1
MP30 8930076890 3073 KEYBOARD 1
MP31 8610013870 KNOB N-378 3
MP32 8610013880 KNOB N-379 1
MP33 8610013290 KNOB N-361 (Incl. MP39) 3
MP34 8610011830 KNOB N-301 (Incl. MP39) 1
MP35 8610013900 KNOB N-380 (Incl. MP37, 39) )
MP36 8610011741 KNOB N-307-1 (Incl. MP38) 4
MP37 8610013320 KNOB N-362 RING 1
MP38 8610009240 KNOB SPRING NO.7800P 4
MP39 8610007420 KNOB SPRING NO.6601 5
MP42 8610010040 KNOB N-239 FINGER REST 1
MP43 8930076900 3073 D-RUBBER 1
MP44 8930060190 2591 N-SPRING 1
MP45 8930076990 3073 BRAKE PLATE 1
MP46 8930076910 3073 BRAKE BUTTON (Incl. MP45) 1
MP47 8610013921 KNOB N-268 BASE-3 (Incl. MP42, 44, 51) 1
MP48 8310072900 3073 NAME PLATE 1
MP51 8930077340 3073 BRAKE SHEET 1
MP52 8930077360 3073 BRAKE PAD 2
MP53 8930077370 DOUBLE SIDE TAPE (BB) 2
MP54 8930077380 DOUBLE SIDE TAPE (BC) 2
MP55 8930074750 FERRITE SHEET (V) 1
MP56 8930059330 SHIELD SPONGE (W) 1
MP57 8930074750 FERRITE SHEET (V) 1
MP58 8930029050 THERMAL SHEET (AL) 2
MP61 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 4
MP62 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 6
MP63 8810008761 SCREW BT B0 2X8 NI-ZC3 (BT) 17
MP64 8930079010 SPONGE (KK) 4
MP65 8930061490 SHIELD SPONGE (AB) 1
MP66 8930055981 SHIELD SPONGE (F)-1 1
MP67 8930055981 SHIELD SPONGE (F)-1 1
MP68 8930055981 SHIELD SPONGE (F)-1 1
MP69 8930059330 SHIELD SPONGE (W) 1
[LOGIC UNIT] (LG)
[DISPLAY UNIT] (DS)
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J801* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J802* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J901* 6510018921 B8B-PH-SM4-TB (LF) (SN) 1
J1001* 6510024151 50FY-BMT-TB (LF) (SN) 1
J1002* 6510022191 B3B-PH-SM4-TB (LF) (SN) 1
J1101* 6510024151 50FY-BMT-TB (LF) (SN) 1
S51* 2260002740 LS8J2M 1
MP1 8930078890 3073 EARTH SPRING 1
MP2 8930065741 2590 D-EARTH SPRING-1 1
MP4 8930058170 SHIELD SPONGE (O) 1
MP101 8510002280 VCO SHIELD PLATE (A) (FX-15) 1
MP102 8930058700 SHIELD SPONGE (R) 1
MP103 8930079230 3073 SHIELD SPRING 1
MP104 8930071550 SHIELD SPONGE (BM) 2
MP202 8930079230 3073 SHIELD SPRING 1
MP203 8930071550 SHIELD SPONGE (BM) 2
MP601 8930065741 2590 D-EARTH SPRING-1 1
MP851 8510015720 2590 DC-DC A-CASE 1
MP852 8930063980 SHIELD SPONGE (AL) 1
MP871 8510015720 2590 DC-DC A-CASE 1
MP872 8930063980 SHIELD SPONGE (AL) 1
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J4* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J21* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J31* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J33* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J107 6510026080 XM7A-0441 1
J113* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J114* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J301* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J407* 6510026740 IMSA-9637S-60Y922 1
J601* 6510026730 IMSA-9637S-08Y902 1
J603* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN) 1
J604* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
S1001* 2260002740 LS8J2M 1
S1002* 2260002740 LS8J2M 1
S1003* 2260002740 LS8J2M 1
S1004* 2260002740 LS8J2M 1
S1005* 2260002740 LS8J2M 1
S1006* 2260002740 LS8J2M 1
S1007* 2260002740 LS8J2M 1
S1008* 2260002740 LS8J2M 1
S1009* 2260002740 LS8J2M 1
S1010* 2260002740 LS8J2M 1
S1011* 2260002740 LS8J2M 1
S1012* 2260002740 LS8J2M 1
S1013* 2260002740 LS8J2M 1
S1014* 2260002740 LS8J2M 1
S1015* 2260002740 LS8J2M 1
S1016* 2260002740 LS8J2M 1
S1017* 2260002740 LS8J2M 1
S1018* 2260002740 LS8J2M 1
S1019* 2260002740 LS8J2M 1
S1020* 2260002740 LS8J2M 1
S1021* 2260002740 LS8J2M 1
S1022* 2260002740 LS8J2M 1
S1023* 2260002740 LS8J2M 1
S1024* 2260002740 LS8J2M 1
S1025* 2260002740 LS8J2M 1
S1026* 2260002740 LS8J2M 1
S1027* 2260002740 LS8J2M 1
S1028* 2260002740 LS8J2M 1
S1029* 2260002740 LS8J2M 1
S1030* 2260002740 LS8J2M 1
S1031* 2260002740 LS8J2M 1
S1101* 2260002740 LS8J2M 1
S1102* 2260002740 LS8J2M 1
S1103* 2260002740 LS8J2M 1
S1104* 2260002740 LS8J2M 1
S1105* 2260002740 LS8J2M 1
S1106* 2260002740 LS8J2M 1
S1107* 2260002740 LS8J2M 1
S1108* 2260002740 LS8J2M 1
S1109* 2260002740 LS8J2M 1
S1110* 2260002740 LS8J2M 1
S1111* 2260002740 LS8J2M 1
S1112* 2260002740 LS8J2M 1
S1113* 2260002740 LS8J2M 1
S1201* 2260002740 LS8J2M 1
SECTION 6
MECHANICAL PARTS
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
