6 - 2
[DISPLAY UNIT] (DS)
REF ORDER
DESCRIPTION QTY.
NO. NO.
S1202* 2260002740 LS8J2M 1
S1203* 2260002740 LS8J2M 1
S1204* 2260002740 LS8J2M 1
S1205* 2260002740 LS8J2M 1
S1206* 2260002740 LS8J2M 1
S1207* 2260002740 LS8J2M 1
S1208* 2260002740 LS8J2M 1
S1209* 2260002740 LS8J2M 1
S1210* 2260002740 LS8J2M 1
S1211* 2260002740 LS8J2M 1
S1212* 2260002740 LS8J2M 1
S1213* 2260002740 LS8J2M 1
S1214* 2260002740 LS8J2M 1
S1215* 2260002740 LS8J2M 1
EP2 6910020190 L5S30853P00 1
MP1 8930077470 3073 EARTH SHIELD 1
MP2 8930077470 3073 EARTH SHIELD 1
MP3 8510002280 VCOSHIELD PLATE (A) (FX-15) 1
MP4 8510002280 VCOSHIELD PLATE (A) (FX-15) 1
MP11 8930077000 3073 LCD HOLDER 1
MP12 8930078950 3073 A-LCD SPONGE 1
MP13 8930062550 SPONGE (HP) 4
MP23 8930043610 INSULATION SHEET (EZ) 1
MP24 8930043610 INSULATION SHEET (EZ) 1
MP33 8930072060 SHIELD SPONGE (BU) 1
MP34 8930072060 SHIELD SPONGE (BU) 1
MP35 8930055981 SHIELD SPONGE (F)-1 1
MP36 8930055981 SHIELD SPONGE (F)-1 1
MP37 8930055981 SHIELD SPONGE (F)-1 1
MP38 8930049131 SHIELD TAPE (D)-1 1
MP39 8930049131 SHIELD TAPE (D)-1 1
MP40 8930049131 SHIELD TAPE (D)-1 1
MP41 8930049131 SHIELD TAPE (D)-1 1
MP51 8930058700 SHIELD SPONGE (R) 1
MP52 8930058700 SHIELD SPONGE (R) 1
MP53 8930058700 SHIELD SPONGE (R) 1
[VR-A UNIT] (VRA)
[VR-B UNIT] (VRB)
[VR-C UNIT] (VRC)
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
R1 7210002970 RV-314 (RK0972210 10KB/10KB) 1
R2 7210002970 RV-314 (RK0972210 10KB/10KB) 1
J32* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN)
J33* 6510022611 16FMN-BMTTR-A-TBT (LF) (SN)
R1 7210002970 RV-314 (RK0972210 10KB/10KB) 1
J1* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
S1 2250000410 TP90D96E20-30F-2178-1 1
R1 7210001130 RK097111T005A 10KB 1
R2 7210001130 RK097111T005A 10KB 1
R3 7210001130 RK097111T005A 10KB 1
R4 7210001130 RK097111T005A 10KB 1
J1* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
[RIT UNIT] (RIT)
[MIC UNIT] (MIC)
[JACK UNIT] (JCK)
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
S1 2250000650 EVEGC2F2524B 1
J1 6510000191 FM214-8SS (P)-1 1
J2* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J1* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) 1
J2 6510023891 S-G4617#01F 1
J102 6510023900 LGR4619-7000 1
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
