Convenient functions for transmit
D
About 5 MHz band operation (USA version only)
Operation on the 5 MHz band is allowed on 5 discrete
frequencies and must adhere to the following:
• USB mode
• Maximum of 50 watts ERP
(Effective Radiated Power)
• 2.8 kHz bandwidth
It is the operator’s responsibility to set all controls so
that the transmission in this band meets the stringent
conditions under which we may use these frequen-
cies.
NOTE: We recommend that you store these fre-
quencies, mode and filter settings into the memory
channel for easy recall.
*The channel center frequencies that are specified
by the FCC, show the center frequency of their
passband. However, the IC-7800 displays carrier
point frequency, so set 1.5 kHz below from FCC
channel center frequency.
• Speech compressor (p. 6-5)
➥ Push [COMP] to turn the speech compressor ON
and OFF.
• Pushing [COMP] for 1 sec. to select the compression
bandwidth from wide, middle and narrow.
• VOX (voice operated transmit) (p. 6-2)
➥ Push [VOX/BK-IN] to turn the VOX function ON
and OFF.
• “VOX” appears when the VOX function is set to ON.
• Transmit quality monitor (p. 6-4)
➥ Push [MONI] to turn the monitor function ON and
OFF.
• Rotate [MONI GAIN] to adjust the monitor gain.
• Monitor indicator (above [MONI] switch) lights when
the monitor function is set to ON.
• Audio tone control (p. 12-4)
➥ Push [F-7•SET] then [F-1•LEVEL] to enter level
set mode. Select an item with [F-1•Y]/[F-2•Z]
then rotate the main dial to adjust the audio tone.
4-3
4
RECEIVE AND TRANSMIT
IC-7800 Tuning FCC Channel
Frequency* Center Frequency*
5.33050 MHz 5.33200 MHz
5.34650 MHz 5.34800 MHz
5.36650 MHz 5.36800 MHz
5.37150 MHz 5.37300 MHz
5.40350 MHz 5.40500 MHz
To assist you in operating the 5 MHz band correctly
within the rules specified by the FCC, transmission
is impossible on any 5 MHz band frequency other
than the 5 frequencies indicated in the table above.
