Icom IC-A22 Service Manual

C5089 4030006860 S.CER C1608 JB 1H 102K-T
C5090 4510004650 S.ELE ECEV1EA4R7SR
J5001 6510017700 S.CNR IL-WX-18PB-VF84-B-E900
J5002 6510017700 S.CNR IL-WX-18PB-VF84-B-E900
J5003 6510017730 S.CNR IL-FPR-30S-HF-E3000
J5005 6510007080 CNR PI28A-02M
S5001 2250000240 SW SW-157 (RH09710HH)
W5002 7030003860 S.RES ERJ3GE JPW V
W5008 7030003860 S.RES ERJ3GE JPW V
[MAIN UNIT]
S.=Surface mount
5 - 4
REF ORDER
DESCRIPTION
NO. NO.
IC6001 1140004860 S.IC HD404829B96TF
IC6002 1190000260 S.IC 24LC08BTI/SN
IC6003 1110005930 S.IC S-80845CLMC-B66-T2
IC6004 1130003920 S.IC TC4S69F (TE85R)
IC6105 1110003780 S.IC NJM2902V-TE1
IC6106 1110003790 S.IC NJM2903V-TE1
IC6107 1110003800 S.IC NJM2904V-TE1
IC6108 1110003790 S.IC NJM2903V-TE1
Q6001 1590001840 S.TR XN4601 (TX)
Q6002 1530003280 S.TR 2SC4211-6-TL
Q6003 1530003280 S.TR 2SC4211-6-TL
Q6004 1520000460 S.TR 2SB1132 T100 R
Q6005 1530003280 S.TR 2SC4211-6-TL
Q6006 1590003280 S.TR UNR9211J-(TX)
Q6007 1510000880 S.TR 2SA1622-6-TL
Q6108 1590001980 S.TR XP4315 (TX)
Q6109 1530003280 S.TR 2SC4211-6-TL
Q6110 1590003290 S.TR UNR9213J-(TX)
D6001 1790001280 S.DIO MA111 (TX)
D6002 1790001280 S.DIO MA111 (TX)
D6003 1790001280 S.DIO MA111 (TX)
D6004 1790001280 S.DIO MA111 (TX)
D6005 1790001200 S.DIO MA6S121 (TX)
D6008 1790000810 S.DIO MA132A (TX)
D6009 1160000050 S.DIO DAP202U T106 [IC-A22E] only
D6014 1790000990 S.ZEN MA8051-H (TX)
D6115 1790001280 S.DIO MA111 (TX)
D6116 1790001280 S.DIO MA111 (TX)
X6001 6050007390 XTL CR-331 (3.9744 MHz)
R6001 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6002 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R6003 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R6004 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R6005 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
)
R6006 7030004870 S.RES ERJ3GEYF 224 V (220 k
Ω
)
R6007 7030004810 S.RES ERJ3GEYF 433 V (43 k
Ω
)
R6008 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
)
R6009 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
)
R6010 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
)
R6011 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
)
R6012 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
)
R6013 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6016 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R6017 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6018 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
)
R6019 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
)
R6020 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R6021 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
)
R6022 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
)
R6023 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R6024 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
)
R6025 7410000590 S.ARY EXB-V4V 473JV (47 k
Ω
)
R6026 7030003240 S.RES ERJ3GEYJ 220 V (22
Ω
)
R6027 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R6101 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
)
R6125 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
)
R6126 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
)
R6127 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
)
R6128 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
)
R6129 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
)
R6130 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
)
R6131 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R6132 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6133 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
)
R6134 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R6135 7310004540 S.TRI EVM-2WSX80 BQ4 (473)
R6136 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
)
R6137 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
)
R6138 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6139 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R6140 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R6141 7510000980 S.TMR TBPS1R333K460H5Q
R6142 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
)
R6143 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
)
R6144 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
)
R6145 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
)
R6146 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
)
R6147 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R6148 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
)
R6149 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R6150 7310004630 S.TRI EVM-2WSX80 B24 (203)
R6151 7310004670 S.TRI EVM-2WSX80 B55 (504)
R6153 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R6154 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R6155 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6156 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
)
R6159 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R6160 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R6161 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R6162 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R6163 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
R6164 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
)
C6001 4550006370 S.TAN ECST0JX226R
C6002 4550006530 S.TAN ECST0JY685R
C6003 4030007030 S.CER C1608 CH 1H 150J-T
C6004 4030007030 S.CER C1608 CH 1H 150J-T
C6005 4030010070 S.CER C1608 CH 1H 104J-T
C6006 4030010070 S.CER C1608 CH 1H 104J-T
C6007 4030010070 S.CER C1608 CH 1H 104J-T
C6008 4030010070 S.CER C1608 CH 1H 104J-T
C6009 4030006900 S.CER C1608 JB 1H 103K-T
C6011 4030006860 S.CER C1608 JB 1H 102K-T
C6112 4550006200 S.TAN ECST0JY106R
C6113 4550006150 S.TAN ECST1CY105R
C6114 4550006200 S.TAN ECST0JY106R
C6115 4030010070 S.CER C1608 CH 1H 104J-T
C6116 4030006860 S.CER C1608 JB 1H 102K-T
C6117 4030006860 S.CER C1608 JB 1H 102K-T
C6118 4550006360 S.TAN ECST1VY104R
C6119 4030006900 S.CER C1608 JB 1H 103K-T
C6120 4030010070 S.CER C1608 CH 1H 104J-T
C6121 4550006340 S.TAN ECST1AY335R
C6122 4550006360 S.TAN ECST1VY104R
C6123 4550006360 S.TAN ECST1VY104R
C6124 4030006850 S.CER C1608 JB 1H 471K-T
C6125 4550006360 S.TAN ECST1VY104R
C6126 4550006360 S.TAN ECST1VY104R
C6128 4550006360 S.TAN ECST1VY104R
C6129 4030006880 S.CER C1608 JB 1H 472K-T
C6130 4550006370 S.TAN ECST0JX226R
C6131 4550006200 S.TAN ECST0JY106R
J6001 6510017710 S.CNR IL-WX-18SB-VF-H4.75-B-E800
J6002 6510017710 S.CNR IL-WX-18SB-VF-H4.75-B-E800
J6003 6510017900 CNR 3-174642-6
DS6001 5030002100 LCD TTR5680 UPFDHW
DS6002 5010000120 S.LED LN1371G-(TR)
DS6003 5010000120 S.LED LN1371G-(TR)
DS6004 5010000120 S.LED LN1371G-(TR)
DS6005 5010000120 S.LED LN1371G-(TR)
DS6006 5040001920 S.LED SML-110MT T86
DS6007 5040001920 S.LED SML-110MT T86
MC6001 7700002310 MIC EM-140
W6101 7030003860 S.RES ERJ3GE JPW V
EP6002 8930045060 LCT SRCN-1541-SP-N-W
EP6003 8950004480 TUB SR tube 2.9 X 4 CP (L=1M) [USA-1] only
[LOGIC UNIT]
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
