INTRODUCTION
This service manual describes the latest service
information for the
IC-A22/E and IC-A3/E VHF AIR BAND
TRANSCEIVERS
at the time of publication.
6 versions of the IC-A22/E and 5 versions of the IC-A3/E
have been designed. This service manual covers each
version.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1110003680 IC SC1303 IC-A22 RF unit 5 pieces
8810008480 Screw PH BT M2×29 ZK IC-A22 Chassis 10 pieces
Addresses are provided on the inside back cover for your
convenience.
REPAIR NOTES
1. Make sure the problem is internal before disassembling
the transceiver.
2. DO NOT open the transceiver until the transceiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An
insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
transceiver is defective.
6. DO NOT transmit power into a signal generator or a
sweep generator.
7. ALWAYS connect a 40 dB to 50 dB attenuator between
the transceiver and a deviation meter or spectrum
analyzer when using such test equipment.
8. READ the instructions of test equipment thoroughly
before connecting equipment to the transceiver.
DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 15 V. Such a connection
could cause a fire or electric hazard.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the trans-
ceiver's front end.
To upgrade quality, all electrical or mechanical parts and internal
circuits are subject to change without notice or obligation.
Icom, Icom Inc. and logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United
Kingdom, Germany, France, Spain, Russia and/or other countries.
MODEL VERSION NO. VERSION SYMBOL
IC-A22
#01 U.S.A. USA
#07 U.S.A. USA-1
IC-A22E
#03 Europe EUR
#04 Europe EUR-1
#05 Australia AUS
#06 U.K. UK
IC-A3 #01 U.S.A. USA
IC-A3E
#03 Europe EUR
#04 Europe EUR-1
#05 Australia AUS
#06 U.K. UK
