IC6001 1140004860 S.IC HD4074829TF (Z-TAT) [IC-A3E]
1140004880 S.IC HD404829B96TF [Others]
IC6002 1190000260 S.IC 24LC08BTI/SN
IC6003 1110005930 S.IC S-80845CLMC-B66-T2 [EUR-1], [AUS]
1130007340 S.IC S-80745SL-A9-T1 [IC-A3], [EUR], [UK]
IC6004 1130003920 S.IC TC4S69F (TE85R)
Q6001 1590001840 S.TR XN4601 (TX)
Q6002 1530003280 S.TR 2SC4211-6-TL
Q6003 1530003280 S.TR 2SC4211-6-TL
Q6004 1520000460 S.TR 2SB1132 T100 R
Q6005 1530003280 S.TR 2SC4211-6-TL
Q6006 1590001150 S.TR UN9211 (TX) [IC-A3]
1590003280 S.TR UNR9211J-(TX) [IC-A3E]
Q6007 1510000880 S.TR 2SA1622-6-TL
D6001 1790001280 S.DIO MA111 (TX)
D6002 1790001280 S.DIO MA111 (TX)
D6003 1790001280 S.DIO MA111 (TX)
D6004 1790001280 S.DIO MA111 (TX)
D6005 1790001200 S.DIO MA6S121 (TX)
D6008 1790000840 S.DIO MA132WA (TX)
D6010 1790000840 S.DIO MA132WA (TX)
D6011 1790000840 S.DIO MA132WA (TX)
D6014 1790000990 S.ZEN MA8051-H (TX)
X6001 6050007390 XTL CR-331 (3.9744 MHz)
R6001 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6002 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R6003 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R6004 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
)
R6005 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
)
R6006 7030004870 S.RES ERJ3GEYF 224 V (220 k
Ω
)
R6007 7030004810 S.RES ERJ3GEYF 433 V (43 k
Ω
)
R6008 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
)
R6009 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
)
R6010 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
)
R6011 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
)
R6012 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
)
R6013 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6016 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
)
R6017 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
)
R6018 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
)
R6019 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
)
R6020 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
R6021 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
)
R6022 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
)
R6023 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
R6024 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
)
R6025 7410000590 S.ARY EXB-V4V 473JV (47 k
Ω
)
R6026 7030003240 S.RES ERJ3GEYJ 220 V (22
Ω
)
R6027 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
C6001 4550006370 S.TAN ECST0JX226R
C6002 4550006530 S.TAN ECST0JY685R
C6003 4030007030 S.CER C1608 CH 1H 150J-T
C6004 4030007030 S.CER C1608 CH 1H 150J-T
C6005 4030011600 S.CER C1608 JB 1E 104K-T
C6006 4030011600 S.CER C1608 JB 1E 104K-T
C6007 4030011600 S.CER C1608 JB 1E 104K-T
C6008 4030011600 S.CER C1608 JB 1E 104K-T
C6009 4030006900 S.CER C1608 JB 1H 103K-T
C6011 4030006860 S.CER C1608 JB 1H 102K-T
J6001 6510017710 S.CNR IL-WX-18SB-VF-H4.75-B-E800
J6002 6510017710 S.CNR IL-WX-18SB-VF-H4.75-B-E800
J6003 6510017900 CNR 3-174642-6
DS6001 5030001180 LCD LD-BU4279J (E-4148) [IC-A3], [EUR], [UK]
5030002200 LCD TTR5674 UPFDHW [EUR-1], [AUS]
DS6002 5010000120 S.LED LN1371G-(TR)
DS6003 5010000120 S.LED LN1371G-(TR)
DS6004 5010000120 S.LED LN1371G-(TR)
DS6005 5010000120 S.LED LN1371G-(TR)
DS6006 5040001920 S.LED SML-110MT T86
DS6007 5040001920 S.LED SML-110MT T86
MC6001 7700001520 MIC EM-123T [IC-A3E]
MC6001 7700002310 MIC EM-140 [IC-A3]
[LOGIC UNIT]
5 - 9
REF ORDER
DESCRIPTION
NO. NO.
C5013 4510004440 S.ELE ECEV1HA010SR
C5014 4510005810 S.ELE ECEV1HAR47R
C5015 4030006850 S.CER C1608 JB 1H 471K-T
C5016 4510005870 S.ELE ECEV1HA3R3SR
C5017 4510005320 S.ELE ECEV0JA101SP
C5018 4030008920 S.CER C1608 JB 1H 473K-T
C5019 4030011600 S.CER C1608 JB 1E 104K-T
C5020 4510005370 S.ELE ECEV1AA221P
C5021 4510005860 S.ELE ECEV1HA2R2SR
C5022 4030011600 S.CER C1608 JB 1E 104K-T
C5024 4510005740 S.ELE ECEV1HAR22SR
C5026 4510005810 S.ELE ECEV1HAR47R
C5030 4030007130 S.CER C1608 CH 1H 101J-T
C5031 4030006860 S.CER C1608 JB 1H 102K-T
C5032 4030006860 S.CER C1608 JB 1H 102K-T
C5033 4030006900 S.CER C1608 JB 1H 103K-T
C5034 4030006900 S.CER C1608 JB 1H 103K-T
C5040 4030008920 S.CER C1608 JB 1H 473K-T [AUS], [UK]
4030010070 S.CER C1608 X7S 1C 104K-T [USA], [EUR], [EUR-1]
C5041 4030011600 S.CER C1608 JB 1E 104K-T
C5043 4550006200 S.TAN ECST0JY106R [USA]
4550006220 S.TAN TEESVA 0J 156M8L Except [USA]
C5045 4510005860 S.ELE ECEV1HA2R2SR
C5046 4510004630 S.ELE ECEV1CA100SR
C5048 4030008470 S.CER C1608 JB 1H 272K-T
C5049 4030006900 S.CER C1608 JB 1H 103K-T
C5050 4030007150 S.CER C1608 CH 1H 151J-T
C5051 4550006150 S.TAN ECST1CY105R
C5052 4510005630 S.ELE ECEV1EA330SP
C5053 4030006860 S.CER C1608 JB 1H 102K-T
C5054 4030006860 S.CER C1608 JB 1H 102K-T
C5055 4510005430 S.ELE ECEV0JA220SR
C5056 4510005430 S.ELE ECEV0JA220SR
C5057 4510005430 S.ELE ECEV0JA220SR
C5058 4510005430 S.ELE ECEV0JA220SR
C5059 4510005430 S.ELE ECEV0JA220SR
C5060 4030006900 S.CER C1608 JB 1H 103K-T
C5062 4510004630 S.ELE ECEV1CA100SR
C5063 4030006900 S.CER C1608 JB 1H 103K-T
C5064 4030006860 S.CER C1608 JB 1H 102K-T
C5065 4030011600 S.CER C1608 JB 1E 104K-T
C5066 4030006900 S.CER C1608 JB 1H 103K-T
C5067 4030006900 S.CER C1608 JB 1H 103K-T
C5068 4030006860 S.CER C1608 JB 1H 102K-T
C5069 4030006860 S.CER C1608 JB 1H 102K-T
C5070 4030006860 S.CER C1608 JB 1H 102K-T
C5071 4030006860 S.CER C1608 JB 1H 102K-T
C5072 4550006370 S.TAN ECST0JX226R
C5073 4030006860 S.CER C1608 JB 1H 102K-T
C5074 4030006860 S.CER C1608 JB 1H 102K-T
C5075 4030011600 S.CER C1608 JB 1E 104K-T
C5076 4030006880 S.CER C1608 JB 1H 472K-T [AUS], [UK]
4030010070 S.CER C1608 X7S 1C 104K-T [USA], [EUR], [EUR-1]
C5077 4510004630 S.ELE ECEV1CA100SR
C5078 4030011600 S.CER C1608 JB 1E 104K-T
C5079 4030006850 S.CER C1608 JB 1H 471K-T [AUS], [UK]
4030010070 S.CER C1608 X7S 1C 104K-T [USA], [EUR], [EUR-1]
C5080 4030011600 S.CER C1608 JB 1E 104K-T
C5081 4030006900 S.CER C1608 JB 1H 103K-T
C5082 4550006220 S.TAN TEESVA 0J 156M8L
C5083 4550006360 S.TAN ECST1VY104R
C5084 4030011600 S.CER C1608 JB 1E 104K-T
C5085 4510005820 S.ELE ECEV1CA101P
C5086 4510004440 S.ELE ECEV1HA010SR
C5088 4030006860 S.CER C1608 JB 1H 102K-T
C5089 4030006860 S.CER C1608 JB 1H 102K-T
C5090 4510004650 S.ELE ECEV1EA4R7SR
J5001 6510017700 S.CNR IL-WX-18PB-VF84-B-E900
J5002 6510017700 S.CNR IL-WX-18PB-VF84-B-E900
J5003 6510017730 S.CNR IL-FPR-30S-HF-E3000
J5005 6510007080 CNR PI28A-02M
S5001 2250000240 SW SW-157 (RH09710HH)
W5002 7030003860 S.RES ERJ3GE JPW V
W5008 7030003860 S.RES ERJ3GE JPW V
WS1 8600034070 M.OTH AX1541 P5001
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
S.=Surface mount
