Feb. 2009
7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC2 1180002151 S.IC NJM2370U1-32-TE1-#ZZZB T 60.2/14.2
IC3 1110006260 S.IC BD5242G-TR B 109.5/24.9
IC4 1140014365 S.IC HD64F38347WV (AX-2974A-5) B 91.5/13.9
IC5 1130011581 S.IC 24LC64T-I/SN G B 102.7/5.3
IC6 1130013540 S.IC TC74LVX4245FS(EL,F) T 77.6/14.1
IC7 1130013540 S.IC TC74LVX4245FS(EL,F) T 69.3/14.1
IC9 1130013990 S.IC NJU7008F3-TE1-#ZZZB B 120.4/24.9
IC10 1120003050 S.IC ADM202EARUZ-REEL7 <FE> B 120/8.2
IC11 1130006551 S.IC TC7S08FU(TE85R,F) T 93.2/13.4
IC12 1130006551 S.IC TC7S08FU(TE85R,F) T 90.3/12.9
IC14 1130006891 S.IC TC7S04FU(TE85R,F) T 90.3/9.2
IC15 1130013460 S.IC NJU6060V-TE1-#ZZZB T 83.7/13.9
IC16 1180000421 S.IC TA78L05F(TE12R,F) B 119.6/16.1
IC17 1130013770 S.IC TC7S00FU(TE85L,F) T 93.2/8.9
IC18 1130008361 S.IC TC7SHU04FU(TE85L,JF) B 99.7/21.7
Q4 1590001040 S.TRA DTA113ZU T106 T 89.1/17.6
Q5 1590001040 S.TRA DTA113ZU T106 T 77.9/22.4
Q6 1530002381 S.TRA 2SC4215-Y(TE85L,F) B 99.4/24.6
Q7 1590001040 S.TRA DTA113ZU T106 T 86.6/17.6
D2 1790001820 S.VAR BCS2015G1 T 131.5/26.2
D4 1730002531 S.ZEN NNCD6.2G-T1-A B 27.3/19.1
X1 6050012011 S.XTA CR-789A SX-2121 9.8304 MHz B 106.3/18.2
L1 6200003181 S.COI NLV32T-390J B 103.7/22.4
R5 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 64/11.7
R6 7030003320 S.RES ERJ3GEYJ 101 V (100) B 134.5/7.9
R7 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 93/2.9
R8 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 91.8/2.9
R9 7030006550 S.RES ERJ3GEYJ 914V (910K) T 84.2/18.4
R10 7030003740 S.RES ERJ3GEYJ 334 V (330K) T 85.7/7.8
R11 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 131.3/9.3
R12 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 134.5/9.3
R13 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 134.5/14.5
R14 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 134.5/13.2
R19 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 140.5/17.2
R20 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 94.7/2.9
R21 7030003390 S.RES ERJ3GEYJ 391 V (390) B 138.5/4.5
R22 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 74.8/7.9
R23 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 70/9.4
R26 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 107.2/24.3
R31 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 82.6/2.9
R34 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 118.4/22.5
R35 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 95.5/24.4
R36 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 96.8/24.4
R37 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 90.6/2.9
R38 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) B 83.3/24.5
R40 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 91.8/23.4
R43 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 101.7/19.6
R44 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 82.6/6.5
R45 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 82.6/5.3
R46 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 82.6/4.1
R47 7030003390 S.RES ERJ3GEYJ 391 V (390) B 18.2/19.5
R48 7030003390 S.RES ERJ3GEYJ 391 V (390) B 16.7/19.5
R49 7030003390 S.RES ERJ3GEYJ 391 V (390) B 140.3/4.5
R50 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 101.5/17.5
R51 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 104.7/14.7
R52 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 105.9/14.7
R57 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 96.2/2.9
R58 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 80/20.2
R59 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 81.2/20.1
R60 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 78.5/7.4
R61 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 78.5/6.2
R62 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 78.8/5
R63 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 78.8/3.6
R64 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 78.8/2.4
R65 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 58.1/6.9
R66 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 59.4/6.9
R67 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 60.7/6.9
R68 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 62/6.9
R69 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 63.3/6.9
R70 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 106.2/9.8
R71 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 103.8/10.5
R72 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 107.4/9.8
R73 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 105/10.5
R74 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) B 83.3/23.3
R75 7030003760 S.RES ERJ3GEYJ 474 V (470K) B 83.3/20.8
R76 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 83.3/22
R77 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 24.4/16.7
R78 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 116.3/25.1
R79 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 18.2/24.3
R80 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 4.6/21.6
R81 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 127.1/5.4
R82 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 112/15
R83 7030003220 S.RES ERJ3GEYJ 150 V (15) B 119.7/12.9
R85 7030003380 S.RES ERJ3GEYJ 331 V (330) B 122.8/24.3
R86 7030003380 S.RES ERJ3GEYJ 331 V (330) B 21.2/24.3
R88 7030003390 S.RES ERJ3GEYJ 391 V (390) B 127.1/3.8
R89 7030003390 S.RES ERJ3GEYJ 391 V (390) B 127.1/2.6
R90 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 89.4/2.9
R91 7030009920 S.RES ERJ3GEYJ 335 V (3.3M) B 120.6/23
R93 7030003320 S.RES ERJ3GEYJ 101 V (100) B 120.6/21.8
R97 7030003380 S.RES ERJ3GEYJ 331 V (330) B 4.6/25.2
R98 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 143.2/17.2
R99 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 143.2/15.9
R100 7030003380 S.RES ERJ3GEYJ 331 V (330) B 122.9/18.8
S.=Surface mount
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R101 7030003280 S.RES ERJ3GEYJ 470 V (47) T 84.5/7.8
R102 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 143.2/10.7
R103 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 143.2/12
R104 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 83.5/19.4
R113 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 98.4/5.6
R114 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 137.3/4.5
R115 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 19.8/19.5
R116 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 96.9/15
R117 7030003320 S.RES ERJ3GEYJ 101 V (100) B 25.6/15.6
R118 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 87.2/23.3
R119 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 96.5/21.4
R120 7030003200 S.RES ERJ3GEYJ 100 V (10) B 23.1/16.7
R121 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 28.2/15.6
R122 7030003860 S.RES ERJ3GE JPW V T 91.2/16.8
R123 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 93.2/6.1
R124 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 90/6.1
R125 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 91.6/6.1
R126 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) T 87.9/20.2
R127 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 102.6/25.2
R128 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 106/23.3
R129 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 121.3/4.7
R130 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 113.7/24.6
R131 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 114.9/12.3
R132 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 6.9/22.6
R133 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 20/23.3
R134 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 123.5/21.2
R135 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 98.2/20
R136 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 138.1/25.4
R137 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 136.9/25.4
R138 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 135.7/25.4
R139 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 130.1/26.1
R140 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 130.1/24.9
R141 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 134.7/21.2
R142 7030003860 S.RES ERJ3GE JPW V [USA-01] B 101.5/23.3
7030003860 S.RES ERJ3GE JPW V [EXP-01]
7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [EUR-01]
7030003860 S.RES ERJ3GE JPW V [CHN-01]
7030003860 S.RES ERJ3GE JPW V [USA-02]
7030003520 S.RES ERJ3GEYJ 472 V (4.7K) [EUR-02]
C1 4030006900 S.CER C1608 JB 1H 103K-T B 54.2/6.9
C2 4510009570 S.ELE 20SVPB15M T 46.4/10.9
C3 4030006900 S.CER C1608 JB 1H 103K-T B 99.4/8.3
C4 4510009570 S.ELE 20SVPB15M T 55.5/5.3
C7 4030006900 S.CER C1608 JB 1H 103K-T B 127.4/6.6
C8 4030006900 S.CER C1608 JB 1H 103K-T B 114.2/25.8
C9 4550007080 S.TAN TEESVA 1C 106M8R T 53.2/14.2
C10 4030006900 S.CER C1608 JB 1H 103K-T B 4.6/23.4
C11 4030006900 S.CER C1608 JB 1H 103K-T B 16.7/24.3
C12 4030011600 S.CER C1608 JB 1E 104K-T T 82.1/7.8
C13 4030011600 S.CER C1608 JB 1E 104K-T T 90.4/14.8
C14 4030006900 S.CER C1608 JB 1H 103K-T B 134.5/15.8
C15 4030006900 S.CER C1608 JB 1H 103K-T B 134.5/10.6
C16 4030018980 S.CER C1608 JB 1H 104K-T B 56.8/6.9
C17 4030006900 S.CER C1608 JB 1H 103K-T T 56.3/13.4
C18 4030006900 S.CER C1608 JB 1H 103K-T B 131.3/7.5
C19 4030006900 S.CER C1608 JB 1H 103K-T B 134.5/11.9
C20 4030006900 S.CER C1608 JB 1H 103K-T B 143.2/13.3
C21 4030006900 S.CER C1608 JB 1H 103K-T B 143.2/14.6
C22 4030006900 S.CER C1608 JB 1H 103K-T B 135.9/17.1
C23 4550006840 S.TAN TEESVA 1E 225M8R B 74.3/6.1
C27 4030007020 S.CER C1608 CH 1H 120J-T B 97.8/21.5
C28 4030007020 S.CER C1608 CH 1H 120J-T B 107.9/15.5
C30 4030008890 S.CER C1608 JB 1H 273K-T B 108.8/22.5
C31 4030006900 S.CER C1608 JB 1H 103K-T B 55.5/6.9
C32 4030006860 S.CER C1608 JB 1H 102K-T B 131/20.1
C33 4030011600 S.CER C1608 JB 1E 104K-T B 26.8/15.6
C34 4030011600 S.CER C1608 JB 1E 104K-T B 117.5/11.7
C35 4030011600 S.CER C1608 JB 1E 104K-T B 120.2/11.7
C36 4030011600 S.CER C1608 JB 1E 104K-T B 122.8/11.7
C37 4030011600 S.CER C1608 JB 1E 104K-T B 124.8/9.3
C38 4030011600 S.CER C1608 JB 1E 104K-T B 124.8/6.7
C39 4030006900 S.CER C1608 JB 1H 103K-T B 136.1/4.5
C40 4030006900 S.CER C1608 JB 1H 103K-T T 86.9/7.8
C41 4030006900 S.CER C1608 JB 1H 103K-T T 55.5/15.8
C42 4030006900 S.CER C1608 JB 1H 103K-T B 22.4/24.3
C43 4030006900 S.CER C1608 JB 1H 103K-T T 91.6/18.7
C44 4550003080 S.TAN TEESVA 1A 335M8R B 119.5/20.1
C45 4030006900 S.CER C1608 JB 1H 103K-T B 117.5/25.1
C46 4030011600 S.CER C1608 JB 1E 104K-T T 64.1/15.1
C47 4030006900 S.CER C1608 JB 1H 103K-T T 83.3/7.8
C49 4550006250 S.TAN TEESVA 1A 106M8R T 94.5/17.4
C50 4030006900 S.CER C1608 JB 1H 103K-T B 113.2/15
C51 4550007080 S.TAN TEESVA 1C 106M8R T 56.8/17.7
C52 4550006250 S.TAN TEESVA 1A 106M8R B 115.9/15.4
C53 4030006900 S.CER C1608 JB 1H 103K-T B 122.8/13.2
C54 4030006900 S.CER C1608 JB 1H 103K-T B 123.6/15.5
C55 4550007080 S.TAN TEESVA 1C 106M8R B 125.4/13.5
C58 4030006860 S.CER C1608 JB 1H 102K-T B 85.5/24.5
C59 4030006900 S.CER C1608 JB 1H 103K-T B 103.4/8.7
C60 4030006900 S.CER C1608 JB 1H 103K-T B 21.9/16.7
C61 4030006860 S.CER C1608 JB 1H 102K-T B 29.4/15.6
C62 4030006860 S.CER C1608 JB 1H 102K-T B 143.2/20.2
C63 4030006860 S.CER C1608 JB 1H 102K-T B 143.2/19
C64 4030006860 S.CER C1608 JB 1H 102K-T B 143.3/21.8
C66 4030006860 S.CER C1608 JB 1H 102K-T B 127.4/24.9
C67 4030006860 S.CER C1608 JB 1H 102K-T B 134.6/19.2
C68 4030006860 S.CER C1608 JB 1H 102K-T T 131.2/22.2
C70 4030006860 S.CER C1608 JB 1H 102K-T B 52.9/6.9
C71 4030006860 S.CER C1608 JB 1H 102K-T B 72.7/9.4
C72 4030006860 S.CER C1608 JB 1H 102K-T T 66.7/9.1
C73 4030006860 S.CER C1608 JB 1H 102K-T T 66.8/20.6
C74 4030006860 S.CER C1608 JB 1H 102K-T T 75/8.6
