Feb. 2009
8
[PA UNIT] (For IC-A210)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C75 4030006860 S.CER C1608 JB 1H 102K-T T 74.9/21.3
C76 4030006900 S.CER C1608 JB 1H 103K-T B 115.4/3.4
C77 4550007690 S.TAN TEESVP 1C 105M8R B 78.5/24.5
C78 4030006900 S.CER C1608 JB 1H 103K-T B 78.2/22.9
C79 4030006860 S.CER C1608 JB 1H 102K-T B 78.2/21.7
C80 4030006860 S.CER C1608 JB 1H 102K-T B 111.8/25.1
C81 4030006900 S.CER C1608 JB 1H 103K-T T 96.5/9.7
C82 4030011600 S.CER C1608 JB 1E 104K-T T 97.7/9.7
C83 4030006860 S.CER C1608 JB 1H 102K-T B 90.6/24.2
C85 4030006900 S.CER C1608 JB 1H 103K-T B 105.3/25.2
C86 4030006900 S.CER C1608 JB 1H 103K-T B 123.5/22.4
J3 6510026160 S.CON 06FLZ-SM2-TB(LF)(SN) B 28.3/8.4
J4 6510025142 S.CON 10FLT-SM2-TB(LF)(SN)(M) B 110.8/4.2
J5 6510022201 S.CON 40FLZ-SM2-R-TB(LF)(SN) B 66.5/14
J6 6510026101 S.CON 22FLT-SM2-TB(LF)(SN)(M) B 138.3/24.6
DS1 5040002930 S.LED SML-512MW T86 T 138.7/22.7
DS2 5040002930 S.LED SML-512MW T86 T 138.7/6.1
DS3 5040002960 S.LED SML-A12MT T86 T 10.5/16.8
DS4 5040002960 S.LED SML-A12MT T86 T 14.5/1.2
DS5 5040002930 S.LED SML-512MW T86 T 120.5/3.3
DS6 5040002930 S.LED SML-512MW T86 T 115.9/3.3
DS7 5040002930 S.LED SML-512MW T86 T 16.7/26.3
DS8 5040002930 S.LED SML-512MW T86 T 4.1/26.3
DS9 5040002930 S.LED SML-512MW T86 T 118.2/16.5
DS10 5040002930 S.LED SML-512MW T86 T 118.2/26.3
DS11 5060000020 EL UEL127
S1 2250000580 ENC EC11EAB24C
S2 2230001200 S.SWI LS35J2-T T 118.2/24
S3 2230001200 S.SWI LS35J2-T T 118.2/14.2
S4 2230001200 S.SWI LS35J2-T T 4.1/24
S5 2230001200 S.SWI LS35J2-T T 16.7/24
S6 2230001200 S.SWI LS35J2-T T 118.2/3.3
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC500 1110003800 S.IC NJM2904V-TE1-#FMZB T 28.5/11.4
IC501 1110002751 S.IC TA75S01F(TE85R,F) T 18.8/6.5
Q500 1560001101 S.FET 2SK3074(TE12L,F) T 10.8/25.3
Q501 1560001061 S.FET 2SK3075(TE12L,Q) T 23/28.4
Q502 1590000430 S.TRA DTC144EUA T106 T 15.8/6.7
Q503 1590000430 S.TRA DTC144EUA T106 T 13.7/10.5
Q504 1590002841 FET MRF137 <M/A> T 58.9/21
D500 1790001670 S.DIO RB706F-40T106 T 101.1/21.5
D501 1790001670 S.DIO RB706F-40T106 T 106.9/22.6
D502 1750000760 S.DIO MA4PH224 (MA4P1250-1072T) T 112.3/22.5
D503 1750000760 S.DIO MA4PH224 (MA4P1250-1072T) T 118.5/8.5
D504 1750000760 S.DIO MA4PH224 (MA4P1250-1072T) T 118.5/13
D505 1790001670 S.DIO RB706F-40T106 T 133.4/19.7
D506 1790001670 S.DIO RB706F-40T106 T 129/19.7
D507 1750000550 S.DIO 1SS355 TE-17 T 15.8/14.9
L502 6200002380 S.COI LQW31HN56NJ03L T 15.2/19.2
L503 6200013260 S.COI C1608CB-56NG T 15.2/27
L504 6200013030 S.COI 0.35-1.6-6TL 31.0N <COMO> T 28.6/23.7
L505 6200012780 S.COI 0.30-1.4-6TL 27.2N <COMO> T 28.9/28.9
L506 6200009320 S.COI C3328A-12NG-A T 35/30.2
L507 6200009390 S.COI C3328A-8N0J-A T 34.5/25.4
L508 6200009390 S.COI C3328A-8N0J-A T 34.8/20.3
L509 6140000670 COI LR-89
L511 6140000670 COI LR-89
L512 6200010040 S.COI AS100340-10N T 73.6/24.2
L513 6200010040 S.COI AS100340-10N T 79.7/26.6
L514 6200010040 S.COI AS100340-10N T 91/25.1
L516 6110001610 COI LA-244
L517 6110001720 COI LA-258
L518 6110001610 COI LA-244
L519 6110001610 COI LA-244
L521 6110001740 COI LA-263
L522 6110001670 COI LA-253
L523 6110001740 COI LA-263
L524 6110001720 COI LA-258
R500 7030003860 S.RES ERJ3GE JPW V T 8/13.7
R501 7030003380 S.RES ERJ3GEYJ 331 V (330) T 5.3/13.7
R502 7030003230 S.RES ERJ3GEYJ 180 V (18) T 8/14.9
R503 7030003380 S.RES ERJ3GEYJ 331 V (330) T 8/16.1
R504 7030003360 S.RES ERJ3GEYJ 221 V (220) T 10.7/20
R505 7030003400 S.RES ERJ3GEYJ 471 V (470) [USA-01] T 17.8/27
7030003400 S.RES ERJ3GEYJ 471 V (470) [EXP-01]
7030003400 S.RES ERJ3GEYJ 471 V (470) [CHN-01]
7030003320 S.RES ERJ3GEYJ 101 V (100) [USA-02]
R506 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 17.9/28.5
R507 7030003380 S.RES ERJ3GEYJ 331 V (330) [USA-01] T 17.8/23.4
7030003380 S.RES ERJ3GEYJ 331 V (330) [EXP-01]
7030003380 S.RES ERJ3GEYJ 331 V (330) [CHN-01]
7030003470 S.RES ERJ3GEYJ 182 V (1.8K) [USA-02]
R508 7030000410 S.RES MCR10EZHJ 1.8K (182) T 20/24.3
R509 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) [USA-01] T 12.4/14.5
7030003550 S.RES ERJ3GEYJ 822 V (8.2K) [EXP-01]
7030003550 S.RES ERJ3GEYJ 822 V (8.2K) [CHN-01]
7030003560 S.RES ERJ3GEYJ 103 V (10K) [USA-02]
R511 7030003670 S.RES ERJ3GEYJ 823 V (82K) T 32.3/13.5
R512 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 30.7/15.9
R513 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 28.1/15.9
R514 7030003320 S.RES ERJ3GEYJ 101 V (100) T 23.2/9
R515 7030003590 S.RES ERJ3GEYJ 183 V (18K) [USA-01] T 43/13.9
7030003590 S.RES ERJ3GEYJ 183 V (18K) [EXP-01]
7030003590 S.RES ERJ3GEYJ 183 V (18K) [CHN-01]
7030003630 S.RES ERJ3GEYJ 393 V (39K) [USA-02]
R516 7030003580 S.RES ERJ3GEYJ 153 V (15K) T 51.3/10.3
R517 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 24.5/11.6
R518 7030010250 S.RES ERJ1TYJ 0R00U T 42/19
R520 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 25.8/9
R521 7030011250 S.RES ERJ1TY 390U (39) T 48.1/12.7
R522 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 32.4/10.8
R524 7030003620 S.RES ERJ3GEYJ 333 V (33K) T 28.6/5.2
R525 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) T 30.6/6
R526 7030003320 S.RES ERJ3GEYJ 101 V (100) T 105/17.2
R527 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 102.5/18
R528 7030006070 S.RES ERJ12YJ101U (100) T 112.6/7.4
R529 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 106.8/19.1
R534 7030003410 S.RES ERJ3GEYJ 561 V (560) T 31.3/14.7
R535 7510001571 S.THE NTCG16 4LH 104JT T 23.4/20.8
R536 7030003590 S.RES ERJ3GEYJ 183 V (18K) T 21.2/6.8
R537 7030003580 S.RES ERJ3GEYJ 153 V (15K) T 18.1/13.6
R538 7030003630 S.RES ERJ3GEYJ 393 V (39K) T 18.3/10
R539 7030003790 S.RES ERJ3GEYJ 824 V (820K) T 16.6/8.8
R541 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 96.7/15.9
R542 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 22/14.8
R543 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 17.8/25.8
R545 7030003860 S.RES ERJ3GE JPW V T 106.9/6.4
R546 7070001250 RES ERG3SJ 151P (150)
R548 7030003240 S.RES ERJ3GEYJ 220 V (22) T 8.1/22.4
R549 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 133.3/16.4
R550 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 130.9/17.1
R553 7030003860 S.RES ERJ3GE JPW V T 9.3/20.9
R554 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 16.1/12.6
R555 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [USA-01] T 18.8/14.8
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [EXP-01]
7030003480 S.RES ERJ3GEYJ 222 V (2.2K) [CHN-01]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [USA-02]
R557 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 21.2/9.5
To Next Page
