August 2015
(Amended page)
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
3
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R108 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 56.3/71.7
R109 7030003360 S.RES ERJ3GEYJ 221 V (220) T 189.6/24.5
R112 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 58.7/68.9
R113 7030003620 S.RES ERJ3GEYJ 333 V (33K)ATEX T 96.1/84.5
R114 7030003620 S.RES ERJ3GEYJ 333 V (33K)ATEX T 95.2/85.7
R118 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 165.3/114.1
R120 7030003860 S.RES ERJ3GE JPW V T 61.4/68.9
R129 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 95.4/77.9
R130 7030003240 S.RES ERJ3GEYJ 220 V (22) T 82.6/79.6
R131 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 88.5/75.5
R137 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 103.4/79.6
R138 7030003580 S.RES ERJ3GEYJ 153 V (15K)ATEX T 100.8/79.6
R141 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 97.9/94.0
R144 7030003320 S.RES ERJ3GEYJ 101 V (100) T 94.6/75.2
R148 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX T 124.5/67.4
R149 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX
[#01] T 126.0/59.3
7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX
[#02]
7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX
[#03]
7030003520 S.RES ERJ3GEYJ 472 V 4.7K)ATEX
[#05]
7030003520 S.RES ERJ3GEYJ 472 V 4.7K)ATEX
[#11]
7030003520 S.RES ERJ3GEYJ 472 V 4.7K)ATEX
[#23]
7030003520 S.RES ERJ3GEYJ 472 V 4.7K)ATEX
[#25]
R151 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)ATEX T 127.5/54.7
R152 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 132.4/126.0
R156 7030003860 S.RES ERJ3GE JPW V T 133.6/91.6
R158 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 126.6/89.1
R160 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 134.4/90.3
R161 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 136.0/126.6
R163 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 125.8/90.3
R164 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 129.1/63.0
R165 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 131.0/63.5
R167 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 136.0/94.7
R168 7030003280 S.RES ERJ3GEYJ 470 V (47) T 129.1/65.8
R169 7030003340 S.RES ERJ3GEYJ 151 V (150) T 131.5/60.4
R170 7030003580 S.RES ERJ3GEYJ 153 V (15K)ATEX T 123.9/90.0
R171 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 125.8/91.5
R173 7030003580 S.RES ERJ3GEYJ 153 V (15K)ATEX T 139.9/93.5
R174 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 138.5/94.7
R175 7030003860 S.RES ERJ3GE JPW V T 141.1/93.5
R177 7030003860 S.RES ERJ3GE JPW V T 140.4/69.0
R178 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 120.5/90.5
R179 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 140.7/91.6
R181 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 137.7/60.4
R183 7030003750 S.RES ERJ3GEYJ 394 V (390K) T 147.0/94.7
R184 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 144.8/93.5
R185 7030003400 S.RES ERJ3GEYJ 471 V (470) T 142.9/62.0
R186 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 117.8/89.6
R187 7030003320 S.RES ERJ3GEYJ 101 V (100) T 152.6/92.6
R188 7030003530 S.RES ERJ3GEYJ 562 V (5.6K)ATEX T 146.6/61.2
R189 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 150.0/87.9
R191 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [#01] T 117.0/92.8
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [#02]
7030003860 S.RES ERJ3GE JPW V [#03]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [#05]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [#11]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [#21]
7030003860 S.RES ERJ3GE JPW V [#23]
7030003500 S.RES ERJ3GEYJ 332 V (3.3K) [#25]
R192 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 150.5/62.9
R193 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 151.0/85.9
R194 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 145.6/53.6
R196 7030003630 S.RES ERJ3GEYJ 393 V (39K)ATEX T 115.8/94.1
R197 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 148.6/60.0
R198 7030003630 S.RES ERJ3GEYJ 393 V (39K)ATEX T 115.8/91.4
R199 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 150.0/83.9
R200 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 153.0/82.7
R201 7030003670 S.RES ERJ3GEYJ 823 V (82K) T 150.5/61.7
R202 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)ATEX T 151.3/57.1
R203 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 150.4/80.1
R204 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)ATEX T 150.4/78.9
R205 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 153.0/81.4
R206 7030003240 S.RES ERJ3GEYJ 220 V (22) T 136.5/60.4
R207 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 153.0/78.2
R208 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX B 152.7/48.9
R209 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 152.9/72.7
R210 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 149.8/69.2
R211 7030003320 S.RES ERJ3GEYJ 101 V (100) B 148.3/72.1
R212 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 152.9/71.4
R213 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX B 154.1/51.7
R214 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX B 154.1/50.5
R215 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) B 145.6/70.2
R216 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 195.3/58.3
R217 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 193.4/61.7
R218 7030003570 S.RES ERJ3GEYJ 123 V (12K) T 195.0/59.9
R220 7030003220 S.RES ERJ3GEYJ 150 V (15) T 176.0/33.4
R222 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 188.9/63.4
R223 7030003220 S.RES ERJ3GEYJ 150 V (15) T 176.2/31.5
R227 7030003400 S.RES ERJ3GEYJ 471 V (470) T 179.2/26.1
R230 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 179.2/27.3
R232 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX B 173.7/29.4
R233 7030003320 S.RES ERJ3GEYJ 101 V (100) B 172.3/33.8
R237 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 182.0/63.4
R238 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX B 181.5/59.0
R245 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX T 178.7/112.5
R246 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX T 173.6/116.0
R247 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX B 165.5/33.5
R248 7030003320 S.RES ERJ3GEYJ 101 V (100) T 178.5/64.9
R252 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 169.5/30.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R253 7030003310 S.RES ERJ3GEYJ 820 V (82) [#01] T 166.2/31.4
7030003310 S.RES ERJ3GEYJ 820 V (82) [#02]
7030003300 S.RES ERJ3GEYJ 680 V (68) [#03]
7030003310 S.RES ERJ3GEYJ 820 V (82) [#05]
7030003310 S.RES ERJ3GEYJ 820 V (82) [#11]
7030003310 S.RES ERJ3GEYJ 820 V (82) [#21]
7030003300 S.RES ERJ3GEYJ 680 V (68) [#23]
7030003310 S.RES ERJ3GEYJ 820 V (82) [#25]
R254 7030003670 S.RES ERJ3GEYJ 823 V (82K) T 179.5/57.5
R256 7030003320 S.RES ERJ3GEYJ 101 V (100) [#01] T 168.1/30.7
7030003320 S.RES ERJ3GEYJ 101 V (100) [#02]
7030003340 S.RES ERJ3GEYJ 151 V (150) [#03]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#05]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#11]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#21]
7030003340 S.RES ERJ3GEYJ 151 V (150) [#23]
7030003320 S.RES ERJ3GEYJ 101 V (100) [#25]
R257 7030003310 S.RES ERJ3GEYJ 820 V (82) [#01] T 166.2/29.9
7030003310 S.RES ERJ3GEYJ 820 V (82) [#02]
7030003300 S.RES ERJ3GEYJ 680 V (68) [#03]
7030003310 S.RES ERJ3GEYJ 820 V (82) [#05]
7030003310 S.RES ERJ3GEYJ 820 V (82) [#11]
7030003310 S.RES ERJ3GEYJ 820 V (82) [#21]
7030003300 S.RES ERJ3GEYJ 680 V (68) [#23]
7030003310 S.RES ERJ3GEYJ 820 V (82) [#25]
R258 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [#01] T 178.7/55.5
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [#02]
7030003510 S.RES ERJ3GEYJ 392 V (3.9K) [#03]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [#05]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [#11]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [#21]
7030003510 S.RES ERJ3GEYJ 392 V (3.9K) [#23]
7030003460 S.RES ERJ3GEYJ 152 V (1.5K) [#25]
R259 7030003620 S.RES ERJ3GEYJ 333 V (33K)ATEX T 167.9/27.6
R262 7030003360 S.RES ERJ3GEYJ 221 V (220) T 169.3/27.6
R263 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)ATEX B 196.4/25.0
R264 7030003380 S.RES ERJ3GEYJ 331 V (330) T 170.1/24.0
R267 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 78.1/86.2
R269 7030003200 S.RES ERJ3GEYJ 100 V (10) T 93.4/118.4
R270 7030003200 S.RES ERJ3GEYJ 100 V (10) T 90.0/108.2
R277 7030003640 S.RES ERJ3GEYJ 473 V (47K)ATEX T 171.8/115.2
R278 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX T 170.5/115.2
R279 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX T 135.1/92.8
R280 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 142.3/93.5
R282 7030003860 S.RES ERJ3GE JPW V T 80.7/86.2
R283 7030003610 S.RES
ERJ3GEYJ 273 V (27K)ATEX
[#01] B 117.8/114.4
7030003610 S.RES
ERJ3GEYJ 273 V (27K)ATEX
[#02]
7030003560 S.RES
ERJ3GEYJ 103 V (10K)ATEX
[#03]
7030003610 S.RES
ERJ3GEYJ 273 V (27K)ATEX
[#05]
7030003610 S.RES
ERJ3GEYJ 273 V (27K)ATEX
[#11]
7030003610 S.RES
ERJ3GEYJ 273 V (27K)ATEX
[#21]
7030003560 S.RES
ERJ3GEYJ 103 V (10K)ATEX
[#23]
7030003610 S.RES
ERJ3GEYJ 273 V (27K)ATEX
[#25]
R288 7030003580 S.RES ERJ3GEYJ 153 V (15K)ATEX B 112.7/124.1
R289 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 121.9/112.1
R290 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 124.5/112.1
R291 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 119.1/115.2
R292 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 70.1/72.8
R293 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX T 65.9/69.3
R294 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)ATEX T 80.7/89.0
R295 7030003620 S.RES ERJ3GEYJ 333 V (33K)ATEX T 82.0/86.2
R297 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) B 108.5/53.1
R298 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 111.5/52.2
R299 7030003200 S.RES ERJ3GEYJ 100 V (10) B 101.2/55.1
R300 7030003280 S.RES ERJ3GEYJ 470 V (47) B 101.2/52.7
R301 7030003640 S.RES ERJ3GEYJ 473 V (47K)ATEX T 173.4/118.9
R302 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 118.9/119.6
R303 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 121.7/119.6
R304 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 121.7/118.4
R305 7030003860 S.RES ERJ3GE JPW V B 96.9/66.7
R312 7030003860 S.RES ERJ3GE JPW V B 98.9/70.7
R313 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX B 171.2/135.4
R314 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX B 178.4/135.5
R315 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX B 171.2/134.1
R316 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 181.3/64.9
R317 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 184.0/65.3
R318 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 186.7/65.5
R319 7030003860 S.RES ERJ3GE JPW V B 181.7/61.5
R320 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 195.3/56.7
R322 7030003860 S.RES ERJ3GE JPW V T 96.1/81.5
R323 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX B 181.1/126.5
R324 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)ATEX B 182.3/126.5
R327 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 178.1/58.7
R328 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 179.3/102.2
R329 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX T 125.6/109.2
R330 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 122.0/109.2
R331 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 97.9/95.2
R332 7030003630 S.RES ERJ3GEYJ 393 V (39K)ATEX B 121.0/114.4
R336 7030003860 S.RES ERJ3GE JPW V B 168.6/28.2
R340 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)ATEX B 88.0/61.9
R341 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX B 93.6/71.1
R342 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX B 90.0/67.3
R343 7030003530 S.RES ERJ3GEYJ 562 V (5.6K)ATEX T 123.2/112.1
R344 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) T 142.9/64.7
R350 7030001290 S.RES MCR50JZHJ 2.2K (222) B 120.5/128.5
R351 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 94.6/124.3
R352 7030003560 S.RES ERJ3GEYJ 103 V (10K)ATEX B 107.4/124.1
R353 7030003710 S.RES ERJ3GEYJ 184 V (180K) B 103.5/128.1
R354 7030003700 S.RES ERJ3GEYJ 154 V (150K) B 114.4/127.4
R355 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 110.0/124.1
R356 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 143.8/87.3
R357 7030006060 S.RES ERJ12YJ100U (10) T 151.4/117.5
R358 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 151.7/109.6
R359 7030003620 S.RES ERJ3GEYJ 333 V (33K)ATEX T 75.9/68.3
R360 7030003680 S.RES ERJ3GEYJ 104 V (100K)ATEX T 78.3/70.7
To Next Page
Loading...
Need help?
General
