Icom IC-A220T Service Manual

Sep. 2009
11
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MB-113] (Except [USA-02], [EUR-02])
D1 1790001750 S.DIO DSM3MA4 T 65.7/16.5
L1 6110001660 COL LA-252
R1 7540000250 ABS SA05C 401N
R2 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 43.5/14.1
R3 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 40.3/14.1
R4 7030003860 S.RES ERJ3GE JPW V T 37.9/13.4
R5 7030003860 S.RES ERJ3GE JPW V T 35.7/14.1
R6 7030003860 S.RES ERJ3GE JPW V T 31.6/14.1
R7 7030003860 S.RES ERJ3GE JPW V T 29.4/13.6
R8 7030003860 S.RES ERJ3GE JPW V T 26.1/14.1
R9 7030003860 S.RES ERJ3GE JPW V T 24.2/13.6
R10 7540000410 ABS ERZV14D470
R11 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 22.3/13.4
C2 4030004750 S.CER C2012 JB 1H 103K-T T 53.8/5.2
C3 4030004750 S.CER C2012 JB 1H 103K-T T 62.4/16.5
C4 4030007130 S.CER C1608 CH 1H 101J-T T 43.5/12.8
C5 4030007130 S.CER C1608 CH 1H 101J-T T 41.1/12.1
C6 4030006860 S.CER C1608 JB 1H 102K-T T 38.7/11
C7 4030006860 S.CER C1608 JB 1H 102K-T T 35.7/12.8
C8 4030006860 S.CER C1608 JB 1H 102K-T T 34.5/10.8
C9 4030006860 S.CER C1608 JB 1H 102K-T T 31.6/12.8
C10 4030006860 S.CER C1608 JB 1H 102K-T T 30.5/11.5
C11 4030006860 S.CER C1608 JB 1H 102K-T T 28/12.1
C12 4030006860 S.CER C1608 JB 1H 102K-T T 26.6/12.1
C13 4030006860 S.CER C1608 JB 1H 102K-T T 24.1/11.7
C14 4030011070 S.CER GRM31M2C2H5R0CY21L T 7.6/8.9
C15 4030011070 S.CER GRM31M2C2H5R0CY21L T 14.1/4.1
C16 4030006860 S.CER C1608 JB 1H 102K-T T 52.1/5.3
C17 4030018980 S.CER C1608 JB 1H 104K-T T 50.8/5.3
C18 4030006860 S.CER C1608 JB 1H 102K-T T 22.3/10.5
J1 6510026210 CNR 2974BNC-BR
J2 6510017150 CNR TMP-S01X-C1
J4 6510018941 S.CNR B13B-PH-SM4-TB (LF) (SN) T 32.3/4.9
J5 6510025900 CNR DALC-J15PAF-11L9-E
J6 6510021071 CNR S2P-VH (LF) (SN)
F1 5210001070 S.FUS 0451008.MRL T 49.8/11.3
W1 7120000490 JMP ERD25T0
