Icom IC-A220T Service Manual

The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-20g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
C108 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 182.8/36.9
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C108 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 182.8/36.9
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C109 4030006860 S.CER C1608 JB 1H 102K-T [#01] T 187.5/27.7
4030006860 S.CER C1608 JB 1H 102K-T [#02]
4030023850 S.CER 0603B102K500CT [#03]
Eqv. 4030026460 S.CER MG18B102K500CT [#03]
C109 4030006860 S.CER C1608 JB 1H 102K-T [#05] T 187.5/27.7
4030006860 S.CER C1608 JB 1H 102K-T [#11]
4030006860 S.CER C1608 JB 1H 102K-T [#21]
4030023850 S.CER 0603B102K500CT [#23]
4030006860 S.CER C1608 JB 1H 102K-T [#25]
C110 4030011340 S.CER C1608 CH 1H 471J-T [#01] B 15.3/54.3
4030011340 S.CER C1608 CH 1H 471J-T [#02]
4030023730 S.CER 0603N471J500CT [#03]
4030011340 S.CER C1608 CH 1H 471J-T [#05]
4030011340 S.CER C1608 CH 1H 471J-T [#11]
4030011340 S.CER C1608 CH 1H 471J-T [#21]
4030023730 S.CER 0603N471J500CT [#23]
4030011340 S.CER C1608 CH 1H 471J-T [#25]
C111 4030010760 S.CER C1608 CH 1H 331J-T [#01] T 133.1/106.3
4030010760 S.CER C1608 CH 1H 331J-T [#02]
4030024390 S.CER 0603N561J500CT [#03]
4030010760 S.CER C1608 CH 1H 331J-T [#05]
4030010760 S.CER C1608 CH 1H 331J-T [#11]
4030010760 S.CER C1608 CH 1H 331J-T [#21]
4030024390 S.CER 0603N561J500CT [#23]
4030010760 S.CER C1608 CH 1H 331J-T [#25]
C113 4030006900 S.CER C1608 JB 1H 103K-T [#01] T 141.4/108.3
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C113 4030006900 S.CER C1608 JB 1H 103K-T [#05] T 141.4/108.3
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C114 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) [#01] T 45.9/119.5
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#02]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#03]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#05]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#11]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#21]
4030016990 S.CER GRM32RR11H105KA01L
(GRM42-2R) [#23]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#25]
C115 4030006930 S.CER C1608 CH 1H 020C-T [#01] T 189.9/43.8
4030006930 S.CER C1608 CH 1H 020C-T [#02]
4030023300 S.CER 0603N2R0C500CT [#03]
4030006930 S.CER C1608 CH 1H 020C-T [#05]
4030006930 S.CER C1608 CH 1H 020C-T [#11]
4030006930 S.CER C1608 CH 1H 020C-T [#21]
4030023300 S.CER 0603N2R0C500CT [#23]
4030006930 S.CER C1608 CH 1H 020C-T [#25]
C116 4030018980 S.CER C1608 JB 1H 104K-T [#01] T 143.0/108.3
4030018980 S.CER C1608 JB 1H 104K-T [#02]
4030023870 S.CER 0603B104K500CT [#03]
Eqv. 4030026160 S.CER MG18B104K500CT [#03]
C116 4030018980 S.CER C1608 JB 1H 104K-T [#05] T 143.0/108.3
4030018980 S.CER C1608 JB 1H 104K-T [#11]
4030018980 S.CER C1608 JB 1H 104K-T [#21]
4030023870 S.CER 0603B104K500CT [#23]
4030018980 S.CER C1608 JB 1H 104K-T [#25]
C117 4030006900 S.CER C1608 JB 1H 103K-T [#01] T 182.0/33.2
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C117 4030006900 S.CER C1608 JB 1H 103K-T [#05] T 182.0/33.2
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C118 4510008500 S.ELE EEE1CA101WP T 147.4/110.0
C120 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) [#01] T 54.7/119.5
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#02]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#03]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#05]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#11]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#21]
4030019260 S.CER C3225 JB 1H 335MT [#23]
4030017070 S.CER GRM32MR11H474K A01L
(GRM42-2R) [#25]
C121 4030006900 S.CER C1608 JB 1H 103K-T [#01] T 92.9/105.9
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C121 4030006900 S.CER C1608 JB 1H 103K-T [#05] T 92.9/105.9
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C124 4030006900 S.CER C1608 JB 1H 103K-T [#01] T 193.0/24.5
4030006900 S.CER C1608 JB 1H 103K-T [#02]
4030023860 S.CER 0603B103K500CT [#03]
Eqv. 4030026180 S.CER MG18B103K500CT [#03]
C124 4030006900 S.CER C1608 JB 1H 103K-T [#05] T 193.0/24.5
4030006900 S.CER C1608 JB 1H 103K-T [#11]
4030006900 S.CER C1608 JB 1H 103K-T [#21]
4030023860 S.CER 0603B103K500CT [#23]
4030006900 S.CER C1608 JB 1H 103K-T [#25]
C125 4030007050 S.CER C1608 CH 1H 220J-T [#01] T 189.9/45.2
4030007050 S.CER C1608 CH 1H 220J-T [#02]
4030023580 S.CER 0603N220J500CT [#03]
4030007050 S.CER C1608 CH 1H 220J-T [#05]
4030007050 S.CER C1608 CH 1H 220J-T [#11]
4030007050 S.CER C1608 CH 1H 220J-T [#21]
4030023580 S.CER 0603N220J500CT [#23]
4030007050 S.CER C1608 CH 1H 220J-T [#25]
C126 4510008010 S.ELE 20SVP22M-AIC T 100.7/126.5
C127 4540000160 S.TRI JZ100 T 185.7/45.2
C128 4030007130 S.CER C1608 CH 1H 101J-T [#01] B 115.9/112.4
4030007130 S.CER C1608 CH 1H 101J-T [#02]
4030023460 S.CER 0603N101J500CT [#03]
Eqv. 4030026120 S.CER MG18N101J500CT [#03]
C128 4030007130 S.CER C1608 CH 1H 101J-T [#05] B 115.9/112.4
4030007130 S.CER C1608 CH 1H 101J-T [#11]
4030007130 S.CER C1608 CH 1H 101J-T [#21]
4030023460 S.CER 0603N101J500CT [#23]
4030007130 S.CER C1608 CH 1H 101J-T [#25]
C130 4030007020 S.CER C1608 CH 1H 120J-T [#01] T 194.5/34.8
4030007020 S.CER C1608 CH 1H 120J-T [#02]
4030023480 S.CER 0603N120J500CT [#03]
4030007020 S.CER C1608 CH 1H 120J-T [#05]
4030007020 S.CER C1608 CH 1H 120J-T [#11]
4030007020 S.CER C1608 CH 1H 120J-T [#21]
4030023480 S.CER 0603N120J500CT [#23]
4030007020 S.CER C1608 CH 1H 120J-T [#25]
C131 4030017490 S.CER C1608 JB 1A 105K-T B 120.5/116.3
C132 4030007170 S.CER C1608 CH 1H 221J-T [#01] T 95.1/95.2
4030007170 S.CER C1608 CH 1H 221J-T [#02]
4030023460 S.CER 0603N101J500CT [#03]
Eqv. 4030026120 S.CER MG18N101J500CT [#03]
C132 4030007170 S.CER C1608 CH 1H 221J-T [#05] T 95.1/95.2
4030007170 S.CER C1608 CH 1H 221J-T [#11]
4030007170 S.CER C1608 CH 1H 221J-T [#21]
4030023460 S.CER 0603N101J500CT [#23]
4030007170 S.CER C1608 CH 1H 221J-T [#25]
C134 4030018980 S.CER C1608 JB 1H 104K-T [#01] T 86.5/78.9
4030018980 S.CER C1608 JB 1H 104K-T [#02]
4030023870 S.CER 0603B104K500CT [#03]
Eqv. 4030026160 S.CER MG18B104K500CT [#03]
C134 4030018980 S.CER C1608 JB 1H 104K-T [#05] T 86.5/78.9
4030018980 S.CER C1608 JB 1H 104K-T [#11]
4030018980 S.CER C1608 JB 1H 104K-T [#21]
4030023870 S.CER 0603B104K500CT [#23]
4030018980 S.CER C1608 JB 1H 104K-T [#25]
C136 4540000160 S.TRI JZ100 T 190.4/35.2
C137 4030007080 S.CER C1608 CH 1H 390J-T [#01] T 189.9/46.4
4030007080 S.CER C1608 CH 1H 390J-T [#02]
4030023790 S.CER 0603N820J500CT [#03]
4030007080 S.CER C1608 CH 1H 390J-T [#05]
4030007080 S.CER C1608 CH 1H 390J-T [#11]
4030007080 S.CER C1608 CH 1H 390J-T [#21]
4030023700 S.CER 0603N390J500CT [#23]
4030007080 S.CER C1608 CH 1H 390J-T [#25]
C138 4030017070 S.CER GRM32MR11H474KA01L
(GRM42-2R) T 86.8/115.9
C139 4030007040 S.CER C1608 CH 1H 180J-T [#01] T 196.3/36.4
4030007040 S.CER C1608 CH 1H 180J-T [#02]
4030023700 S.CER 0603N390J500CT [#03]
4030007040 S.CER C1608 CH 1H 180J-T [#05]
4030007040 S.CER C1608 CH 1H 180J-T [#11]
4030007040 S.CER C1608 CH 1H 180J-T [#21]
4030023520 S.CER 0603N180J500CT [#23]
4030007040 S.CER C1608 CH 1H 180J-T [#25]
C140 4030017480 S.CER C1608 JB 1A 474K-T T 85.8/81.0
C141 4030018780 S.CER C3225 JB 2J 473K-T T 89.9/115.9
C142 4030006940 S.CER C1608 CH 1H 030C-T [#01] T 119.3/61.6
4030006940 S.CER C1608 CH 1H 030C-T [#02]
4030023320 S.CER 0603N3R0C500CT [#03]
4030006940 S.CER C1608 CH 1H 030C-T [#05]
4030006940 S.CER C1608 CH 1H 030C-T [#11]
4030006940 S.CER C1608 CH 1H 030C-T [#21]
4030023320 S.CER 0603N3R0C500CT [#23]
4030006940 S.CER C1608 CH 1H 030C-T [#25]
C143 4030007020 S.CER C1608 CH 1H 120J-T [#01] T 115.4/61.6
4030007020 S.CER C1608 CH 1H 120J-T [#02]
4030023480 S.CER 0603N120J500CT [#03]
4030007020 S.CER C1608 CH 1H 120J-T [#05]
4030007020 S.CER C1608 CH 1H 120J-T [#11]
4030023480 S.CER 0603N120J500CT [#23]
4030007020 S.CER C1608 CH 1H 120J-T [#25]
