The actual configuration of the PC board can be seen by viewing the top and bottom BOARD LAYOUT pages together.
See the PARTS LIST H/V location on the PARTS LIST for location details.
7-14g
The underlined parts have been updated from the previous version of the addendum, or the original pages.
(Amended page)
July 2019
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80 H85 H90
V0V5
V10V15V20V25V30
AUDIO GND
NC
HEADPHONE+
SPEAKER+
• D-CONNECT UNIT (B8129B for only IC-A220: Bottom view)
