SECTION 9 BOARD LAYOUTS
9 - 1
ANL
PTT
LIGHT
R30
J9001
R10K
TO LOGIC UNIT J6003
Add "9000" to each indicated part number on the unit
for the actual part number.
NOTE:
PTTSW
GND
R12K
GND
LV
5V
OUT
SHIFT
Add "7000" to each indicated part number on the board
for the actual part number.
NOTE:
TO MAIN UNIT
+
c
-
9-1 PTT UNIT
9-2 PRT UNIT
9-3 VCO BOARD
