Icom IC-A6 Service Manual

5 - 6
SOFTWARE ADJUSTMENT (continued)
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
VOR OFF
(IC-A24 only)
[ ]
1 • Operating frequency: 108.000 MHz
• Connect a VOR tester to the antenna connector and set
as:
Level : –90 dBm* (7.1 µV)
Modulation : 9960 Hz, 10%
30 Hz, 30%
Bearing : 0°
• Receiving
• Push [ENT] key.
VOR PHASE
(IC-A24 only)
[ ]
1 • Operating frequency: 108.000 MHz
• Connect a VOR tester to the antenna connector and set
as:
Level : –60 dBm* (220 µV)
Modulation : 9960 Hz, 30%
30 Hz, 30%
Bearing : 0°
• Receiving
• Push [ENT] key.
Finished. Turn off the radio.
*This output level of a standard signal generator (SSG) is indicated as SSG's open circuit.

Icom IC-A6 Specifications

General

Frequency Range	118.000–136.975 MHz
Channel Spacing	25 kHz
Antenna Impedance	50Ω
Power Supply Requirement	7.2 V DC
Waterproof	No
Channels	200 channels
Current Drain	1.5 A (at max output)
RF Output Power	5 W (PEP)
Modulation	AM
Battery Life	15 hours
Weight	430g
Dimensions	54 x 129.3 x 35.5 mm
