Icom IC-E2820 Service Manual

ADJUSTMENT ITEM ADJUSTMENT CONDITIONS OPERATION VALUE
DIVERSITY 145.020 MHz
(S0 level)
(Left Band)
[L DL2]
1 • Set the SSG as;
Frequency : 145.020 MHz
Level : −6 dBµ
Push the right
band’s [MAIN•
BAND] key.
(Automatic
adjustment)
(Right Band)
[R DL2]
2
(S3 level) (Left Band)
[L DM2]
3 • Set the SSG as;
Level : −1 dBµ
(Right Band)
[R DM2]
4
(Full scale) (Left Band)
[L DH2]
5 • Set the SSG as;
Level : +15 dBµ
(Right Band)
[R DH2]
6
387.020 MHz
(S0 level)
(Left Band)
[L DL5]
1 • Set the SSG as;
Frequency : 387.020 MHz
Level : −6 dBµ
(Right Band)
[R DL5]
2
(S3 level) (Left Band)
[L DM5]
3 • Set the SSG as;
Level : −1 dBµ
(Right Band)
[R DM5]
4
(Full scale) (Left Band)
[L DH5]
5 • Set the SSG as;
Level : +15 dBµ
(Right Band)
[R DH5]
6
435.020 MHz
(S0 level)
(Left Band)
[L DL6]
1 • Set the SSG as;
Frequency : 435.020 MHz
Level : −6 dBµ
(Right Band)
[R DL6]
2
(S3 level) (Left Band)
[L DM6]
3 • Set the SSG as;
Level : −1 dBµ
(Right Band)
[R DM6]
4
(Full scale) (Left Band)
[L DH6]
5 • Set the SSG as;
Level : +15 dBµ
(Right Band)
[R DH6]
6
500.020 MHz
(S0 level)
(Left Band)
[L DL7]
1 • Set the SSG as;
Frequency : 500.020 MHz
Level : −6 dBµ
(Right Band)
[R DL7]
2
(S3 level) (Left Band)
[L DM7]
3 • Set the SSG as;
Level : −1 dBµ
(Right Band)
[R DM7]
4
(Full scale) (Left Band)
[L DH7]
5 • Set the SSG as;
Level : +15 dBµ
(Right Band)
[R DH7]
6
¤ DIVERSITY ADJUSTMENT (continued)
5 - 11
