BATTERY PACKS
D Rapid charging with the BC-144+AD-99
DD
Spacer combination.
• Be sure to attach the
spacer (Spacer B/C) to
the adapter (Spacer A)
with the orientation as il-
lustrated in the diagram at
right.
• Attach the spacer
(Spacer B/C) to the
adapter with the orientation of the stamp “” pointing up.
NOTE: Push the notch carefully
when remove the spacer from the
adapter.
Turn power OFF
BP-209, BP-210
or BP-222 attached
to the transceiver.
AC adaptor
BC-145A/E/V/UK
Charging indicator
Check orientation
and
Spacer A
Spacer B/C
Check orientation
and the spacer com-
bination as follows.
IC-F21_1 IM 01.11.13 2:02 PM Page 13 (1,1)
