8
1
PANEL DESCRIPTION
SCRAMBLER/ENCRYPTION KEY
(LMR (P25 Conventional) operation only)
While in the analog mode operation, push to toggle the
voice scrambler function ON and OFF.
While in the digital mode operation, push to toggle the
encryption transmission function ON and OFF.
While in the mixed (digital and analog) mode operation,
push to toggle the voice scrambler and encryption trans-
mission functions ON and OFF, separately or simultane-
ously as below.
D For Digital mode operation only
INDIVIDUAL KEY
Push to enter the individual ID code selection mode directly.
Then select the desired individual ID code using [CH Up]/
[CH Down]. (p. 13)
Push to stop the beep emission when receiving a matched
individual ID code.
TALKGROUP KEY
Push to enter the talkgroup ID code selection mode directly.
Then select the desired talkgroup ID code using [CH Up]/
[CH Down]. (p. 13)
Push to stop the beep emission when receiving a matched
talkgroup ID code.
ZEROIZE KEY
Push and hold to zeroize the encryption key data, pro-
grammed by the FS-F70/F1700
FLASH LOADER
.
ENCRYPTION KEY
Push to toggle the encryption transmission function ON or
OFF.
When this function is turned ON, “ ” appears on the function
display.
Voice scrambler function ON
Voice scrambler and Encryption transmittion
functions ON
Voice scrambler and Encryption transmittion
functions OFF
Encryption transmittion function ON
PUSH
PUSH
PUSH
PUSH
( appears)
(
appears)
(
appears)
( disappears)
