Icom IC-F1821D - D Individual ID Code Selection; D Talkgroup ID Code Selection; D DTMF Transmission

13
2
BASIC OPERATION
2
D Individual ID code selection
(Digital mode operation only)
If the transceiver has [Individual] assigned to it, the indication
can be toggled between the operating channel number (or
name) and Individual ID code (or name). When the Individual
ID code (or name) is displayed, [CH Up], [CH Down] or [CH
Up/Down] selects the desired Individual ID code.
q Push [Individual]— an Individual ID code (or name)
appears.
w Push [CH Up] or [CH Down], or rotate [CH Up/Down] to
select the desired Individual ID code.
e Push [PTT] to transmit the selected Individual ID code.
r Push [Individual]— cancels the selected Individual ID code
(return to the pre-set Talkgroup ID code in the channel.)
D Talkgroup ID code selection
(Digital mode operation only)
If the transceiver has [Talkgroup] assigned to it, the indication
can be toggled between the operating channel number (or
name) and Talkgroup ID code (or name). When the Talkgroup
ID code (or name) is displayed, [CH Up], [CH Down] or [CH
Up/Down] selects the desired Talkgroup ID code.
q Push [Talkgroup]— a Talkgroup ID code (or name)
appears.
w Push [CH Up] or [CH Down], or rotate [CH Up/Down] to
select the desired Talkgroup ID code.
e Push [PTT] to transmit the selected Talkgroup ID code.
r Change the channel— cancels the selected Talkgroup ID
code (return to the pre-set Talkgroup ID code in the chan-
nel.)
D DTMF transmission
If the transceiver has [DTMF Autodial] assigned to it, the auto-
matic DTMF transmission function is available. Up to 8 DTMF
channels are available.
TO SELECT A TX CODE:
q Push [DTMF Autodial]— a DTMF channel appears.
w Push [CH Up] or [CH Down], or rotate [CH Up/Down] to
select the desired DTMF channel.
e Push [DTMF Autodial] to transmit the DTMF code in the
selected DTMF channel.
