S.=Surface mount
6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R21 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 72.2/38.9
R22 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 69.2/38.9
R23 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 71.2/38.9
R24 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 64.6/38
R25 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 68/37.8
R29 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 64.2/35.1
R30 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 67.7/35.7
R31 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 64.2/34.1
R32 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 66.1/31.1
R33 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 55.5/25.2
R34 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 52.5/25.2
R35 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 50.5/25.2
R36 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 52.5/15.5
R37 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 50.7/16.3
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 46.5/21
R39 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 55.8/22.3
R40 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 56.2/21.1
R43 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 47.5/15.4
R44 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 54.8/15.4
R45 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 52.8/13.7
R46 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 53.8/13.7
R48 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 51.5/25.2
R50 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 66.3/38
R51 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 96.5/37.3
R52 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 93.3/35.9
R53 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 80/22.5
R53 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 80/22.5
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
7030005710 S.RES ERJ2GEJ 121 X (120
Ω
) [Others]
R54 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 81.3/21.4
R55 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 80/20.9
R56 7030003860 S.RES ERJ3GE JPW V T 78/22.4
R57 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 75.2/23.2
R58 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 72.1/24
[US3], [GE3], [US3S], [GE3S] only
R59 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 71.2/24
R61 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 71.8/36.3
R62 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 72.1/35
R65 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 69.4/34.2
R66 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 67.8/34.2
R67 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 67.8/35.1
R68 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 69.4/35.1
R69 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 64.1/35.2
R70 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 57.6/40.3
R71 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 58.2/38.6
R73 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 57.7/30.5
R75 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 58.4/36.1
R76 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 57.6/39.3
R77 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 56.7/30.5
R78 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 57.8/33.3
R79 7030006020 S.RES RR0510P-682-D (6.8 k
Ω
) T 56.5/39.1
R80 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 54.6/32.8
[US3], [GE3], [US3S], [GE3S]
7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) [Others]
R82 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 52.6/32
R83 7030006020 S.RES RR0510P-682-D (6.8 k
Ω
) T 54.1/32.6
R84 7030006020 S.RES RR0510P-682-D (6.8 k
Ω
) T 52.1/28.6
R85 7030006020 S.RES RR0510P-682-D (6.8 k
Ω
) T 54.7/39.1
R86 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 48.2/28.8
R87 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 48.1/25.3
R88 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 54.6/31
[US3], [GE3], [US3S], [GE3S]
7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) [Others]
R89 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 49.3/41.2
R90 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 46.9/25.1
R92 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 46.9/26.1
R93 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 39.8/39.4
R94 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 41.8/40.8
R95 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 49.9/36.4
R96 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 49.3/40.1
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) [Others]
R97 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 49.3/38.1
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 53.5/44.1
R100 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 52.9/38.8
R101 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 51.4/43.3
R103 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 33.1/27.8
R104 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 31.5/26.9
R105 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 32.6/29.1
R106 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 37.5/32
R107 7030005580 S.RES ERJ2GEJ 560 X (56
Ω
) B 55.9/43.3
R108 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 44.9/21
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) [Others]
R109 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 43.9/21
R110 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 21.8/34.3
R111 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 27.1/28.7
R113 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 46.9/31.1
R114 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 46.9/29.1
R115 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) T 40.5/32
R116 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) T 43.4/32.7
R117 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 35.3/40.1
R118 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 37.2/40.1
R123 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) T 75.2/37.7
R124 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 72.7/40.4
R125 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 73.2/38.9
R131 7510001730 S.TMR ERTJOEP 473J T 40.9/28.1
R132 7030010080 S.RES ERJ2RHD 104 X (100 k
Ω
) T 40.9/27.1
R133 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 84.1/14.2
R134 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 74/14.3
R135 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 24.5/24
R136 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 22.8/24
R137 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 69.8/14.7
R138 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 69.8/16.7
R141 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 37/9.9
R142 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 43/9.9
R143 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 37.2/24.4
R144 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 46.5/13.7
R145 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 33.4/18.1
R146 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 31.6/18.1
R147 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 33.4/16.1
R148 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 31.6/16.1
R149 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 33.4/12.9
R150 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 33.4/11.9
R151 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 33.4/13.9
R152 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 31.1/29.6
R153 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 29.9/29.1
R154 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 28.2/30.1
R155 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 29.8/41.1
R156 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 29.8/40.1
R157 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 31.5/39.1
R159 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 15.7/28.8
R160 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 5.5/31
R161 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 12.9/27.3
R162 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 8.7/29.1
R163 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 14.1/29.8
R164 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) T 15.7/27.8
R165 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) T 12.6/31.9
R166 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 12.6/36.1
R167 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) T 15.7/29.8
R168 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 16.3/40.1
R169 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 18/41.1
R170 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 12.9/29.3
R171 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 11.6/36.1
R172 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) T 18/39.1
R173 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 19.4/26.8
R174 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 19.4/28.8
R175 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 19.4/27.8
R176 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 17.7/27.8
R177 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 17.7/28.8
R178 7030005710 S.RES ERJ2GEJ 121 X (120
Ω
) T 19.4/30.7
R179 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 11.5/16.8
R180 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 24.7/40.1
R181 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 21.1/40.1
R182 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 24.7/39.1
R183 7030006020 S.RES RR0510P-682-D (6.8 k
Ω
) B 17.2/39.1
R184 7030008250 S.RES RR0510P-562-D (5.6 k
Ω
) B 17.7/40.4
R185 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 18.7/40.4
R186 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 19.4/29.8
R187 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 9/18.2
R190 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 34.7/18.9
R191 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 18/4.1
R192 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) T 18/5.1
R193 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 18/6.1
R194 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 23.9/10.9
R195 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 19.7/4.1
R196 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 23.9/11.9
R197 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 23.9/12.9
R198 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 25.7/12.9
R200 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 25.7/14.9
R201 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 23.9/14.9
R206 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 13.4/4.1
R207 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 13.4/5.1
R208 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 15.6/5.1
R209 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 15.6/6.1
R210 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 15.6/4.1
R211 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 27.1/4.1
R212 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 27.1/5.1
R213 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 27.1/6.1
R214 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 29.1/7.1
R215 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 31/6.1
R220 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 15.9/23.3
R221 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 66.5/13.7
R222 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) B 63.9/8.5
R223 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 61/11.3
R224 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 75.5/10.3
R225 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 33.9/7.1
R226 7210003061 VAR TP76N00N-15F-A103-2251A
R227 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 94.9/13.9
R228 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 94.2/15.2
R229 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 86/9.7
R230 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 87.2/17.2
R231 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 90.6/2.8
R232 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 93.2/4.4
R233 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 92.7/2.8
R234 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 23.3/6.2
[US2S]=F24S USA-02, [GE2S]=F24S GEN-02, [EU2S]=F25S EUR-02
[US3S]=F24S USA-03, [GE3S]=F24S GEN-03
To Next Page
Loading...
Need help?
General
