6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R235 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 20.3/4.2
R236 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 23.3/5.2
R237 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 21.1/39.1
R238 7410001140 S.ARY EXB28V104JX B 40.9/9.5
R240 7030005590 S.RES ERJ2GEJ 680 X (68
Ω
) T 99.7/12.3
R241 7030010040 S.RES ERJ2GE-JPW T 39.4/6.4
[US2S], [US3S], [EU2S], [GE2S], [GE3S] only
R242 7030010040 S.RES ERJ2GE-JPW T 41.4/6.4
[US2S], [US3S], [EU2S], [GE2S], [GE3S] only
R251 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 5.9/9.1
R252 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 13.7/9.1
R254 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 9.3/10.1
R255 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 7.6/10.1
R256 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 6/8.6
R257 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 9/22.1
R258 7410001140 S.ARY EXB28V104JX T 6.6/20.6
R259 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 21.6/22.1
R260 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 21.5/25
R261 7410001130 S.ARY EXB28V102JX T 19.4/19.9
R262 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 21.3/13.9
R263 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 21.3/12.9
R264 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 21.3/10.9
R265 7410001130 S.ARY EXB28V102JX T 19.7/9.2
R266 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 5.7/18.8
R271 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 10/39.3
R272 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 11/39.3
R273 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 12/39.3
R274 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 15/39.3
R275 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 13/39.3
R276 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 8/39.3
R277 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 9/39.3
R278 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 14/39.3
R280 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 16.2/36.2
R284 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 16.3/27
R287 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 18.4/24
R288 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 14.7/22.7
R291 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 5.9/12.5
R292 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 7.6/12.5
R293 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 61.4/43.4
R294 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 60.4/43.4
R295 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 95.1/43.4
R296 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) B 91.8/35.3
R297 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 91.3/36.2
R301 7030010040 S.RES ERJ2GE-JPW B 93.1/22.4
R302 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 93.3/34.9
R303 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 33.6/20.7
C1 4030017590 S.CER ECJ0EC1H070C B 94.2/41.5
[US3], [GE3], [US3S], [GE3S]
4030017600 S.CER ECJ0EC1H080C [Others]
C2 4030017350 S.CER ECJ0EC1H020B B 93.2/36
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
4030017550 S.CER ECJ0EC1H1R5B [Others]
C3 4030017590 S.CER ECJ0EC1H070C B 96.5/33.9
[US3], [GE3], [US3S], [GE3S]
4030017600 S.CER ECJ0EC1H080C [Others]
C4 4030017560 S.CER ECJ0EC1H2R5B B 94.9/33.9
C5 4030017360 S.CER ECJ0EC1H030B B 94.6/30.2
[US3], [GE3], [US3S], [GE3S]
4030017570 S.CER ECJ0EC1H040B [Others]
C6 4030017460 S.CER ECJ0EB1E102K B 92.8/33.4
C7 4030017460 S.CER ECJ0EB1E102K B 92.9/29.6
C8 4030017370 S.CER ECJ0EC1H3R5B B 93.2/28.1
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
4030017580 S.CER ECJ0EC1H060C [Others]
C11 4030006980 S.CER C1608 CH 1H 070D-T B 91.5/21.9
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
4030009530 S.CER C1608 CH 1H 030B-T [Others]
C13 4030007000 S.CER C1608 CH 1H 090D-T B 88.3/20.8
[US3], [GE3], [US3S], [GE3S]
4030007020 S.CER C1608 CH 1H 120J-T [Others]
C14 4030017570 S.CER ECJ0EC1H040B B 86.8/38.7
C16 4030008560 S.CER C1608 CH 1H 300J-T B 86.4/21.5
C17 4030017510 S.CER ECJ0EC1H680J B 83.4/38.7
C18 4030006860 S.CER C1608 JB 1H 102K-T T 83.6/31.4
C19 4030017460 S.CER ECJ0EB1E102K B 86/37.7
C20 4030017590 S.CER ECJ0EC1H070C B 84.1/37.7
C21 4030017400 S.CER ECJ0EC1H220J B 85.8/34.3
[US3], [GE3], [US3S], [GE3S]
4030017410 S.CER ECJ0EC1H240J [Others]
C22 4030017600 S.CER ECJ0EC1H080C B 84.1/36.7
C23 4030017350 S.CER ECJ0EC1H020B B 82/37.7
[US3], [GE3], [US3S], [GE3S]
4030017560 S.CER ECJ0EC1H2R5B [Others]
C24 4030017400 S.CER ECJ0EC1H220J B 79.7/33.2
[US3], [GE3], [US3S], [GE3S]
4030017410 S.CER ECJ0EC1H240J [Others]
C25 4030017600 S.CER ECJ0EC1H080C B 80.4/36.1
C27 4030017460 S.CER ECJ0EB1E102K T 83.9/35.7
C28 4030017460 S.CER ECJ0EB1E102K T 83.9/37.7
C30 4030017590 S.CER ECJ0EC1H070C B 79.6/37.8
C31 4030017460 S.CER ECJ0EB1E102K T 80.4/37.2
C32 4030017460 S.CER ECJ0EB1E102K B 75.8/39.9
C33 4030017460 S.CER ECJ0EB1E102K T 77.1/38.7
C34 4030017420 S.CER ECJ0EC1H470J T 77.1/39.7
C35 4030016930 S.CER ECJ0EB1A104K T 78.8/37.7
C36 4030017460 S.CER ECJ0EB1E102K B 71.8/33.3
C37 4030017460 S.CER ECJ0EB1E102K B 73.4/34.2
C38 4030017350 S.CER ECJ0EC1H020B B 74.8/37.7
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
4030017550 S.CER ECJ0EC1H1R5B [Others]
C39 4030017620 S.CER ECJ0EC1H100C B 73.5/38.8
C40 4030017520 S.CER ECJ0EC1H0R3B B 73.5/39.8
C41 4030017380 S.CER ECJ0EC1H050B B 68.5/39.2
C42 4030017460 S.CER ECJ0EB1E102K T 68.5/37.7
C43 4030017460 S.CER ECJ0EB1E102K T 70.2/38.9
C44 4030017340 S.CER ECJ0EC1H010B B 69/37.8
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
4030017550 S.CER ECJ0EC1H1R5B [Others]
C45 4030017620 S.CER ECJ0EC1H100C B 72.2/38.8
[US3], [GE3], [US3S], [GE3S]
4030017630 S.CER ECJ0EC1H120J [Others]
C46 4030017460 S.CER ECJ0EB1E102K T 68.2/38.9
C48 4030017400 S.CER ECJ0EC1H220J B 64.2/37.2
C49 4030017350 S.CER ECJ0EC1H020B B 64.2/40
[US3], [GE3], [US3S], [GE3S]
4030017380 S.CER ECJ0EC1H050B [Others]
C50 4030017460 S.CER ECJ0EB1E102K B 64.2/36.1
C51 4030017460 S.CER ECJ0EB1E102K B 66.1/32.1
C52 4030017420 S.CER ECJ0EC1H470J B 66.1/35.7
C53 4030016790 S.CER ECJ0EB1C103K B 64.2/33.1
C54 4030017460 S.CER ECJ0EB1E102K B 64.2/32.1
C56 4030017400 S.CER ECJ0EC1H220J B 64.3/24.4
C57 4030017460 S.CER ECJ0EB1E102K T 64.1/36.8
C58 4030017460 S.CER ECJ0EB1E102K B 53.9/24.3
C59 4030017460 S.CER ECJ0EB1E102K B 49.5/25.2
C60 4030017460 S.CER ECJ0EB1E102K B 52.5/26.9
C61 4030017430 S.CER ECJ0EC1H101J B 49.5/22.7
C62 4030017680 S.CER ECJ0EC1H820J B 47.5/17.6
C63 4030017420 S.CER ECJ0EC1H470J B 46.5/20.7
C64 4030016790 S.CER ECJ0EB1C103K T 49.7/16.3
C65 4030017460 S.CER ECJ0EB1E102K B 46.5/18.9
C66 4030017460 S.CER ECJ0EB1E102K B 47.5/13.7
C67 4030017460 S.CER ECJ0EB1E102K B 53.9/22.3
C68 4030017440 S.CER ECJ0EC1H221J B 51.8/13.7
C69 4030017730 S.CER ECJ0EB1E471K B 53.8/15.4
C70 4030017730 S.CER ECJ0EB1E471K B 54.8/13.7
C71 4030016930 S.CER ECJ0EB1A104K B 56.2/17.5
C72 4030017420 S.CER ECJ0EC1H470J T 69.8/18.7
C73 4030017460 S.CER ECJ0EB1E102K T 69.3/24
C74 4030017460 S.CER ECJ0EB1E102K T 93.3/37
C75 4550005980 S.TAN TEESVA 1A 475M8L B 54.5/9.9
C76 4030016790 S.CER ECJ0EB1C103K T 66.7/21.1
C77 4030017460 S.CER ECJ0EB1E102K T 65.7/22.7
C78 4030017460 S.CER ECJ0EB1E102K T 74.8/20.8
C79 4030018890 S.CER ECJ0EB0J224K T 72.3/21.1
C80 4030017780 S.CER ECJ0EB1E472K T 68/18.7
C81 4030016790 S.CER ECJ0EB1C103K B 77.2/21.5
C82 4030017460 S.CER ECJ0EB1E102K B 78.2/21.5
C83 4030017620 S.CER ECJ0EC1H100C T 81.3/22.3
[US3], [GE3], [US3S], [GE3S]
4030017400 S.CER ECJ0EC1H220J [Others]
C84 4030017420 S.CER ECJ0EC1H470J T 81.3/20.5
C86 4030017420 S.CER ECJ0EC1H470J T 78.7/24.3
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S],
4030017650 S.CER ECJ0EC1H270J [Others]
C88 4030017460 S.CER ECJ0EB1E102K T 73.1/24
C89 4030017570 S.CER ECJ0EC1H040B T 75.5/24.4
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
C91 4510004650 S.ELE ECEV1EA4R7SR B 69.7/20.3
C92 4030017630 S.CER ECJ0EC1H120J T 74.6/30.9
C93 4030017380 S.CER ECJ0EC1H050B T 70.9/33.5
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
4030017600 S.CER ECJ0EC1H080C [Others]
C94 4030017730 S.CER ECJ0EB1E471K T 70.3/24
C96 4030017460 S.CER ECJ0EB1E102K T 73.8/36
[US3], [GE3], [US3S], [GE3S] only
C97 4030017420 S.CER ECJ0EC1H470J T 74.8/36
C98 4030017380 S.CER ECJ0EC1H050B T 66.1/33.9
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
4030017620 S.CER ECJ0EC1H100C [Others]
C99 4030017460 S.CER ECJ0EB1E102K T 68.3/36.3
C100 4030017620 S.CER ECJ0EC1H100C B 61.3/36.1
C102 4030017380 S.CER ECJ0EC1H050B T 59.5/34.3
C103 4030017350 S.CER ECJ0EC1H020B B 58.2/35.1
C104 4030017460 S.CER ECJ0EB1E102K T 58.9/29.4
C105 4030017460 S.CER ECJ0EB1E102K B 58.6/37.1
C106 4030017420 S.CER ECJ0EC1H470J B 70.3/33.9
C107 4030017460 S.CER ECJ0EB1E102K T 70.6/36.3
C108 4030016790 S.CER ECJ0EB1C103K T 69.7/36.3
C109 4030017460 S.CER ECJ0EB1E102K B 57.6/41.3
C110 4030017730 S.CER ECJ0EB1E471K B 55.7/30.5
C111 4030017420 S.CER ECJ0EC1H470J B 56.3/34.4
C112 4030017460 S.CER ECJ0EB1E102K T 60.2/38.6
C113 4030017520 S.CER ECJ0EC1H0R3B T 56.1/32.6
[US2]=USA-02, [GE2]=GEN-02, [EU2]=EUR-02, [US3]=USA-03, [GE3]=GEN-03 S.=Surface mount
To Next Page
