SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC2 1110002750 S.IC TA75S01F (TE85R) T 88.1/12.4
IC6 1110005340 S.IC NJM12902V-TE1 B 55.4/23.8
IC8 1110005770 S.IC S-80942CNMC-G9C-T2 B 20.8/41.5
IC9 1110003200 S.IC TA31136FN (EL) T 81.5/17
IC10 1130011580 S.IC 24LC64T-I/SN B 29.7/13.2
IC12 1190001350 S.IC M62364FP 600D B 38.9/26.2
IC13 1130006220 S.IC TC4W53FU (TE12L) B 47.1/24
IC14 1110006220 S.IC AK2346-E2 B 41.5/13.2
IC15 1110001810 S.IC TA7368F (ER) T 97.3/15.4
IC17 1110005350 S.IC NJM2870F05-TE1 B 93.2/20.2
IC19 1110005330 S.IC NJM12904V-TE1 B 42.9/39.6
IC20 1130009090 S.IC LC75834W-TLM T 57.3/20.3
IC21 1130010100 S.IC LMX2352 T 79.5/34.1
IC22 1140011510 S.IC HD64F2238BTF13 B 17.4/22.4
IC23 1110005330 S.IC NJM12904V-TE1 B 36.9/39.3
IC24 1110002750 S.IC TA75S01F (TE85R) B 56.2/36.9
IC25 1130007020 S.IC TC7S66FU (TE85R) B 58.2/33
Q2 1590003320 S.FET TPC6103 (TE85L) T 98.4/4.8
Q3 1590003290 S.TR UNR9213J-(TX) T 93.4/5
Q4 1560000840 S.FET 2SK1829 (TE85R) T 90.9/34.7
Q5 1580000730 S.FET 3SK293 (TE85L) B 90.9/39
Q6 1580000760 S.FET 3SK299-T1 U73 B 86.8/29.5
Q7 1530002600 S.TR 2SC4215-O (TE85R) B 89.2/19.7
Q14 1530003260 S.TR 2SC5006-T1 B 78.7/34.3
Q15 1530003260 S.TR 2SC5006-T1 B 74.9/28.1
Q16 1530003260 S.TR 2SC5006-T1 B 76.6/25.1
Q17 1530003260 S.TR 2SC5006-T1 B 76.1/33.9
Q18 1590001400 S.TR XP1214 (TX) T 73.7/27.9
Q19 1590003290 S.TR UNR9213J-(TX) T 73.9/25.6
Q20 1530002850 S.TR 2SC4116-BL (TE85R) T 86.5/25.6
Q21 1560000540 S.FET 2SK880-Y (TE85R) T 70.8/23.8
Q22 1530002850 S.TR 2SC4116-BL (TE85R) T 81.3/24.3
Q24 1510000920 S.TR 2SA1577 T106 Q B 63.3/14.3
Q25 1510000920 S.TR 2SA1577 T106 Q B 64.4/10.4
Q26 1520000450 S.TR 2SB1132 T100 Q B 56.6/11.3
Q27 1590001190 S.TR XP6501-(TX) .AB B 57.5/7.3
Q28 1590003230 S.TR UNR9113J-(TX) B 54.1/7.1
Q29 1530003260 S.TR 2SC5006-T1 B 78.8/23.1
Q38 1590003290 S.TR UNR9213J-(TX) B 81.8/39.2
Q40 1590003290 S.TR UNR9213J-(TX) B 49.5/18.4
Q41 1590001190 S.TR XP6501-(TX) .AB T 90.8/21.3
Q42 1520000450 S.TR 2SB1132 T100 Q T 89.3/17.2
Q43 1590003400 S.TR UNR9112J T 77.7/4.9
Q44 1590003270 S.TR UNR9210J-(TX) B 29.8/5.8
Q45 1590003230 S.TR UNR9113J-(TX) T 54.6/4.5
Q500 1590003290 S.TR UNR9213J-(TX) T 78.6/23.7
Q501 1590003290 S.TR UNR9213J-(TX) T 84.7/11.9
Q502 1560001360 S.FET 2SK3019 TL B 36/11.7
D5 1160000060 S.DIO DAN202U T106 T 93.6/7.3
D6 1790001260 S.DIO MA2S077-(TX) B 27.6/31
D8 1790001250 S.DIO MA2S111-(TX) T 86.7/28.6
D9 1750000770 S.VCP HVC376BTRF B 69.4/30.5
D10 1750000770 S.VCP HVC376BTRF B 69.1/26.5
D11 1750000720 S.VCP HVC375BTRF B 73.3/33.7
D12 1720000470 S.VCP 1SV239 (TPH3) B 72/28.4
D13 1750000720 S.VCP HVC375BTRF B 73.5/23.1
D14 1750000710 S.VCP HVC350BTRF B 86.1/35.4
D15 1750000710 S.VCP HVC350BTRF B 87.4/39.5
D16 1790001260 S.DIO MA2S077-(TX) B 84.3/18
D17 1790001260 S.DIO MA2S077-(TX) B 83.4/22.2
D18 1790001250 S.DIO MA2S111-(TX) T 92.9/36.6
D19 1750000720 S.VCP HVC375BTRF B 94.8/39.1
D20 1790001240 S.DIO MA2S728-(TX) B 94.9/33.4
D21 1160000060 S.DIO DAN202U T106 B 28.4/22.6
D24 1750000720 S.VCP HVC375BTRF B 96.6/37.7
D25 1790001240 S.DIO MA2S728-(TX) B 94.9/34.7
D28 1790001670 S.DIO RB706F-40T106 B 29.8/2.9
D500 1750000770 S.VCP HVC376BTRF B 68.2/32.2
D501 1750000770 S.VCP HVC376BTRF B 68.1/24.9
D502 1790001260 S.DIO MA2S077-(TX) B 79.9/28.1
D503 1790001260 S.DIO MA2S077-(TX) T 80.2/26.7
D504 1750000940 S.DIO ISS400 TE61 B 28.2/24.5
FI1 2030000150 S.MLH FL-335 (46.350 MHz) T 91.3/27.1
FI2 2020001530 CER CFWLB450KFFA-B0 (GFWM450F)
X1 6070000190 S.DCR CDBCB450KCAY24-R0 B 80/16.9
X2 6050011930 S.XTL CR-781 (15.3 MHz) B 63.3/38.3
X5 6050011730 S.XTL CR-765 (3.6864 MHz) B 38.3/4
X6 6050011830 S.XTL CR-774 (12.288 MHz) B 30.9/31.5
L7 6200008090 S.COL LQW2BHN68NJ01L B 99.2/38.1
L8 6200008090 S.COL LQW2BHN68NJ01L B 93.1/40.3
L9 6200007750 S.COL LQW2BHN56NJ01L B 88.7/36.5
L11 6200007750 S.COL LQW2BHN56NJ01L B 85.9/33.8
L12 6200009350 S.COL ELJRE R22G-F3 B 84.3/26.5
L13 6200007850 S.COL ELJNC R82K-F B 89.4/32
L21 6200011030 S.COL ELJRF R10JF2 (0.1) B 80.5/22.8
L22 6200011030 S.COL ELJRF R10JF2 (0.1) B 77.2/28.5
L24 6200003640 S.COL MLF1608E 100K-T B 70.3/26.6
L25 6200007760 S.COL LQW2BHN82NJ01L B 71.9/23.5
L27 6200003550 S.COL MLF1608A 4R7K-T T 68.7/26.7
L28 6200003550 S.COL MLF1608A 4R7K-T T 68.8/30.4
L31 6200007000 S.COL ELJRE 82NG-F B 95.3/31.3
L32 6200007910 S.COL ELJRF 18NJF2 (18) T 77.8/27.4
L33 6200004480 S.COL MLF1608D R82K-T T 81.4/22.4
L35 6200003540 S.COL MLF1608D R22K-T T 84.6/25.5
L37 6200008090 S.COL LQW2BHN68NJ01L B 71.6/33.4
L41 6200007910 S.COL ELJRF 18NJF2 (18) B 80.2/33.5
L42 6200003550 S.COL MLF1608A 4R7K-T T 71.2/34.2
L43 6200003550 S.COL MLF1608A 4R7K-T T 69.4/21.9
L47 6200007720 S.COL LQW2BHN33NJ01L B 69.1/34.3
L48 6200008090 S.COL LQW2BHN68NJ01L B 69.3/22.7
L500 6200003640 S.COL MLF1608E 100K-T B 70.6/30.4
L501 6200003960 S.COL MLF1608A 1R0K-T T 74.7/31.9
L502 6200011000 S.COL ELJRF 56NJF2 (56) B 86.3/25.4
R1 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 87.4/14.6
R4 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) T 86.3/9.7
R5 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 86.6/8.1
R6 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 86/15.7
R7 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 85.5/13.4
R8 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 88/10.2
R9 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 90.5/12.3
R12 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 90.2/36.8
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 95.2/40.2
R15 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 92.2/39.3
R16 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 89.8/41.2
R17 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 88.7/36.8
R18 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 70.8/30.1
R19 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 91.1/37.6
R21 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 87.3/41.4
R22 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 88.5/38.9
R23 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 86.5/35.6
R24 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 86.2/22.8
R25 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 85.7/31.2
R29 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 89.2/27.5
R31 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 89.2/33.7
R32 7030010040 S.RES ERJ2GE-JPW T 92.2/31.9
R33 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 90.2/22.9
R34 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 88.6/21.6
R35 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 87.2/21.2
R36 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 81.9/12.6
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 81.8/12.2
R39 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 81.4/11.6
R40 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 81.8/21.3
R43 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 77.8/14.1
R44 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 77.9/21.3
R45 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 77.2/17.9
R46 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 76.6/20.7
R48 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 87.2/19.9
R50 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 84.9/22.8
R68 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 85.6/15.9
R69 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 85.6/18.2
R70 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 80.1/26.4
R71 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 80.1/25.5
R72 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 35.5/34.2
R73 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 39.1/19.5
R74 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 40.1/19.5
R75 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 78.5/31
R76 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 78.7/32
R77 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 77.2/30.9
R78 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 75.9/29.7
R79 7030008340 S.RES RR0510P-182-D (1.8 k
Ω
) B 76.1/32.4
R80 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 75.1/23.9
R81 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 47.9/20.8
