S.=Surface mount
6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R82 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 74.8/25.7
R83 7030008340 S.RES RR0510P-182-D (1.8 k
Ω
) B 75.3/23.9
R84 7030011000 S.RES RR0510P-392-D (3.9 k
Ω
) B 74.6/22.7
R85 7030011000 S.RES RR0510P-392-D (3.9 k
Ω
) B 73.5/29.7
R86 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 71.5/25.8
R87 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 75.4/31.2
R88 7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) B 75.1/26.6
R89 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 70.2/25.6
R90 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 71.3/21
R91 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 70.7/19.7
R92 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 72.5/21.8
R93 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 46.2/20.4
R94 7030010040 S.RES ERJ2GE-JPW T 72.3/29.6
R95 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 69.9/30.1
R96 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 87.2/37.4
R97 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 11.6/29.9
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 86.4/27.5
R100 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 72.9/20.5
R101 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 73.9/23.9
R103 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 56.6/40.1
R104 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 55/39.1
R106 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 43.5/7.9
R107 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 37.5/7.7
R108 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 64/35.4
R110 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 70.8/17.9
R111 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 66.1/32.4
R114 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) B 38.9/7.3
R115 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) T 85.8/23.4
R116 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) T 83.2/26.3
R117 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 40.6/7.2
R118 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 26.9/6.3
R119 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 36.5/7.7
R120 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 41.6/19.9
R121 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 36.4/44.6
R122 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 35/43.1
R123 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 70.3/41.9
R124 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 67.3/20.9
R130 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 99.4/35.2
R131 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 101.3/41.5
R147 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 55.2/29.8
R148 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 55.2/30.8
R151 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 49.8/25.5
R152 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 52.1/24.4
R154 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 53.5/28
R156 7030010040 S.RES ERJ2GE-JPW B 54.7/28.5
R157 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 53.5/29
R161 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 61.4/14.4
R162 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 60.1/12.9
R163 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 62.5/11.4
R164 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 62.1/10.1
R165 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 55.5/8.2
R166 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 58/5.3
R172 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 88.7/34.9
R173 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) T 91.1/36.6
R174 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 92.9/34.4
R175 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 92.2/32.9
R181 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 40/34.9
R182 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 39.4/41.3
R183 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 40.4/41.3
R184 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 43.8/33.3
R185 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 43.8/35.3
R186 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 45.5/39.7
R203 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 12.2/5.5
R204 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 12.3/3.6
R205 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 28/19.3
R209 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 51.2/17.8
R210 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 51.2/19.5
R211 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 53.6/18.7
R213 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 51.8/20.8
R214 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 50.2/20.6
R215 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 59/20.7
R216 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 59/22.8
R217 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 58.9/24.8
R218 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 59/25.9
R219 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 59/27.8
R220 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 58.7/29.6
R221 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 5.7/13.8
R222 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) B 7.8/15.6
R223 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 6.8/15.4
R224 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 5.8/15.4
R225 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) T 101.4/18.8
R226 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 94.5/18.8
R227 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 89/20.8
R228 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 88.6/22.3
R229 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 92.9/22.1
R230 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 59/26.9
R231 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 30.4/22.6
R232 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 58.7/28.7
R233 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 98.4/10.3
R234 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 100.7/12.4
R235 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 83.5/5
R236 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 75.7/4.3
R237 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 23.6/14
R238 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 83/8.4
R239 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 27.9/6.4
R240 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 35.2/32.9
R241 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 40/31.9
R242 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 35.2/31.9
R243 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 38.6/32.4
R244 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 40/33.9
R245 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 40/35.9
R246 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 98.5/8.1
R247 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 36.6/20.7
R256 7510001730 S.TMR ERTJOEP 473J B 20/32.9
R257 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 19/33.9
R258 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 24.9/28
R259 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 27.7/27.8
R260 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 27.3/29.3
R261 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 26/30.5
R262 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 27.3/34
R263 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 22.9/32.9
R264 7030006010 S.RES RR0510P-472-D (4.7 k
Ω
) B 15.3/33.7
R265 7030006010 S.RES RR0510P-472-D (4.7 k
Ω
) B 14.8/32.7
R266 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 45/18.5
R267 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 44/18.5
R269 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 46/18.5
R270 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 19.9/31.9
R272 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 56.3/4.4
R273 7030010040 S.RES ERJ2GE-JPW B 15.6/5.3
R275 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 14.4/5
R282 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 34.4/39.5
R283 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 34.4/37.9
R288 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 13.5/5
R289 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 38.4/33.6
R291 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 9.5/14.7
R292 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 29.8/18
R293 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 28.3/18
R295 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 62.1/14.1
R300 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 61.7/16.4
R301 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 47.9/27.4
R302 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 95.2/39.2
R303 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 95.1/41.2
R307 7030005580 S.RES ERJ2GEJ 560 X (56
Ω
) T 76.1/28.8
R308 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 71.8/17.9
R309 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 7/14.1
R315 7210003061 VAR TP76N00N-15F-A103-2251A
R318 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) T 95.9/3.9
R319 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 94.3/3.4
R320 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 93.7/9
R321 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 14.6/41.6
R323 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 5.3/26.6
R325 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 5.3/25.6
R327 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 5.3/24.6
R329 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 5.3/23.6
R331 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 5.3/22.6
R333 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 5.3/21.6
R335 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 5.3/20.6
R336 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 7/26.6
R337 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 7/25.6
R338 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 7/24.6
R339 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 7/23.6
R340 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 7/22.6
R341 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 7/21.6
R342 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 7/20.6
R343 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 7/19.6
R344 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 5.3/19.6
R345 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 81/38.7
R346 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 82/38.7
R347 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 83/38.7
R348 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 84.1/33.2
R349 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 28/20.4
R350 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 22.7/15.1
R351 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 31.4/20.8
R352 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 8.5/26.9
R353 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 13.9/13.6
R354 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 12.7/14
R355 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 11.4/14.3
R356 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 11.5/15.4
R357 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 34.4/41.1
R358 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 34.4/36.3
R359 7030010040 S.RES ERJ2GE-JPW T 84/30.6
R362 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 55.5/33.1
R500 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 78.6/27.3
R501 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 79.1/27
R502 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 76.5/24.4
R506 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 89/34
R507 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 76.2/17.9
R508 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 49.3/28.2
R509 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 50.9/28.2
R510 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 37.8/19.9
