Icom IC-F3S - Page 27

S.=Surface mount
[MAIN UNIT]
J2 6450001680 CONNECTOR HSJ1122-010010
J3 6450001690 CONNECTOR HSJ1456-01-220
J4 6450000870 CONNECTOR HEC2711-01-020
J5 6510018430 S.CONNECTOR AXN330C038P
J6 6510007080 CONNECTOR PI28A-02M
J7 6910010850 CONNECTOR IMSA-9230B-1-05Z080-T
DS1 5030001460 LCD LM-1462B
DS2 5010000160 S.LED LNJ310M6URA
DS3 5010000160 S.LED LNJ310M6URA
DS4 5040002190 S.LED LNJ808R8ERA
MC1 7700002160 MICROPHONE KUC3523-040245
S1 2230000900 S.SWITCH JPM1990-2013R
SP1 2510000960 SPEAKER K036NA500-26
W1 7030003860 S.JUMPER ERJ3GE JPW V
W2 7030003860 S.JUMPER ERJ3GE JPW V
W7 7030003860 S.JUMPER ERJ3GE JPW V [2-BANK]
W8 7030003860 S.JUMPER ERJ3GE JPW V [16 ch]
W10 7030003860 S.JUMPER ERJ3GE JPW V
WS1 8600035801 M.OTHER FX1922 P01MA-1
EP1 0910048456 PCB B 4929F
EP2 8930042590 LCD CONTACT SRCN-1922-SP-N-W
R1 7210002950 VARIABLE RV-312 (RK0971110)
EP1 0910048462 PCB B 4930B
6 - 5
REF ORDER
DESCRIPTION
NO. NO.
[VR BOARD]
REF ORDER
DESCRIPTION
NO. NO.
F3/S
