Icom IC-F43GS Service Manual

Sep. 2008
5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF PARTS
DESCRIPTION M.
H/V
.ON .ON
LOCATION
C396 4030017360 S.CER ECJ0EC1H030B
[5], [7], [10], [16], [19], [21], [23],
[24] B 84.7/24.8
4030017580 S.CER ECJ0EC1H060C
except [5], [7], [10], [16], [19], [21],
[24] B 84.7/24.8
C397 4030017360 S.CER ECJ0EC1H030B [3], [17] B 84.9/27
4030017580 S.CER ECJ0EC1H060C except [3], [17] B 84.9/27
C398 4030017460 S.CER ECJ0EB1E102K B 68.1/34.3
C399 4550007120 S.TAN F92 1D 224MPA T 67.5/35.4
C400 4030017460 S.CER ECJ0EB1E102K B 72.2/27.5
C401 4030017330 S.CER ECJ0EF1C104Z B 71.3/28.2
C401 4030018860 S.CER ECJ0EB0J105K B 71.3/28.2
C402 4030017460 S.CER ECJ0EB1E102K T 92.9/19.9
C403 4030017460 S.CER ECJ0EB1E102K B 36.3/16.6
C404 4030016790 S.CER ECJ0EB1C103K B 59.1/35.3
C405 4030017460 S.CER ECJ0EB1E102K B 39.4/42.9
C406 4030017330 S.CER ECJ0EF1C104Z B 52.3/19.5
C407 4030017460 S.CER ECJ0EB1E102K T 95.9/2.9
C408 4030017460 S.CER ECJ0EB1E102K T 100.9/4.2
C409 4030017460 S.CER ECJ0EB1E102K B 16.6/32.9
C411 4030017330 S.CER ECJ0EF1C104Z
[5], [7], [10], [16], [19], [21], [23],
[24] B 18.6/32.4
4030018860 S.CER ECJ0EB0J105K
except [5], [7], [10], [16], [19], [21],
[24] B 18.6/32.4
C412 4030017420 S.CER ECJ0EC1H470J T 78.4/3.1
C413 4030018080 S.CER ECJ0EB1H182K
[4], [5], [6], [7], [8], [18], [19], [20],
[21], [22] only T 74.9/16.9
C414 4030018860 S.CER ECJ0EB0J105K B 34.5/34.2
C415 4030017570 S.CER ECJ0EC1H040B [9], [23] only B 69.1/34.4
C416 4030018860 S.CER ECJ0EB0J105K
[4], [6], [18], [20] only T 91.3/14.4
C417 4030017330 S.CER ECJ0EF1C104Z [4], [18] only T 80.9/12.2
C418 4030017420 S.CER ECJ0EC1H470J [4], [18] only B 80.6/22.6
C419 4030017620
S.CER ECJ0EC1H100C
[4], [18], [24] only B 79.3/23.1
C420 4030017380 S.CER ECJ0EC1H050B
[4], [6], [7], [18], [20], [21] only T 94.6/28.5
C421 4550006780 S.TAN TEESVB2 0J 476M8R
[4], [18] only B 30.5/41.2
C422 4550006780 S.TAN TEESVB2 0J 476M8R
[4], [18] only B 55.6/15.4
C423 4030017730 S.CER ECJ0EB1E471K [4], [18] only T 84.9/29.9
C424 4030017730 S.CER ECJ0EB1E471K
[4], [6], [8], [18][20], [22] only T 97.9/42.3
C425 4030017420 S.CER ECJ0EC1H470J
[1], [2], [3], [10], [11], [12], [13],
[14], [15], [16], [17], [24], [25],
1.72/7.07 T ylno ]62[
J2 6450002250 CNR HSJ1456-010320
[4], [6], [8], [18][20], [22] only
J3 6450001680 CNR HSJ1122-010010
J4 6510021901 S.CNR BM02B-ASRS-TF (LF) (SN) T 88.1/4.5
J5 6510018430 S.CNR AXN330C038P B 15.2/9.8
J6 6510024391 S.CNR IMSA-6176S-03Y902 B 88.2/8.8
J7 6510024740 S.CNR IPS-4039T-02B (4039T-01Y901) B 92.5/29
DS1 5010000160 S.LED LNJ310M6URA T 57.3/6
DS2 5010000160 S.LED LNJ310M6URA T 57.3/39.4
DS3 5030003110 LCD S11351 <SUC>
MC1 7700002760 MIC EM6027P-46C33-G-01 <HOR>
S1 2230001060 S.SW EVQ-PUL 02K T 102.2/38.1
S2 2260002840 SW SKHLLFA010
S3 2260002800 S.SW SW-167 (SKQTLAE010) B 61.1/44.2
S4 2260002800 S.SW SW-167 (SKQTLAE010) B 51.6/44.2
S5 2260002800 S.SW SW-167 (SKQTLAE010) B 99.6/44.2
S27 2250000180 ECR EC10SP16-47
EP1 6910015370 S.BEA ACZ1005Y-102-T B 76.6/30.8
EP3 6910015370 S.BEA ACZ1005Y-102-T B
59.4/36.9
EP4 6910015600 S.BEA ACZ1005Y-241 (240)
[1], [2], [9], [10], [13], [14], [15],
[16], [17], [26] only B 37.4/19
EP5 6910015370 S.BEA ACZ1005Y-102-T B 32/8.3
EP6 6910015370 S.BEA ACZ1005Y-102-T T 74.4/31.6
EP7 8930063020 LCT SRCN-2721-SP-N-W (SHJ)
EP11 6910015370 S.BEA ACZ1005Y-102-T T 78/11.7
EP12 0800008200 ADP IC20-DES TRANSCRYPT
[9], [23] only
S.=Surface mount
[PA UNIT]
REF PARTS
DESCRIPTION M.
H/V
.ON .ON
LOCATION
Q701 1560001232 S.FET RD07MVS2-T112 B 22.6/8.3
Q702 1560001241 S.FET RD01MUS1-T113 B 15.7/8.2
Q703 1530000370 S.TR 2SC3356-T1B T 8.4/14
Q704 1530003260 S.TR 2SC5006-T1 T 3.9/7
D701 1750000581 S.DIO 1SV307 (TPH3,F) T 33.9/12.8
D702 1790001670 S.DIO RB706F-40T106 T 28.8/17.8
D703 1790001670 S.DIO RB706F-40T106 B 30.9/13.6
D704 1790001260 S.DIO MA2S077-(TX) B 29.3/18
D705 1790001240 S.DIO MA2S728-(TX) T 25.9/18.1
L701 6200002851 S.COL NLV25T-R82J B 34.4/12.4
L703 6200012610 S.COL 0.40-0.9-2TL 2.8N <COMO> T 30.1/13.6
L704 6200012610 S.COL 0.40-0.9-2TL 2.8N <COMO> T 24.1/14.1
L705 6200013010 S.COL 0.30-0.9-5TL 10.3N <COMO> B 19.4/13.5
L706 6200003590 S.COL EXCCL3225U1 B 10.7/15.9
L707 6200005681 S.COL ELJRE 15NGFA [10], [16] T 9.1/16.1
6200005691 S.COL ELJRE 18NGFA
[1], [2], [3], [11], [13], [14], [15],
[17], ]62[ T 9.1/16.1
6200005701 S.COL ELJRE 22NGFA [9] T 9.1/16.1
L708 6200005741 S.COL ELJRE 47NGFA T 3.3/10.3
L709 6200013010 S.COL 0.30-0.9-5TL 10.3N <COMO> T 33.7/16.7
L712 6200009070 S.COL LQW18AN18NG00D B 32.2/15.8
R701 7030004980 S.RES ERJ2GEJ 101 X (100) B 31.4/11.8
R702 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 29.6/15.7
R703 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 27.2/16.3
R704 7030005530 S.RES ERJ2GEJ 100 X (10) T 18.4/2.9
R705 7030005220 S.RES ERJ2GEJ 223 X (22 k)
[5], [7], [10], [16], [19], [21], [24] only T 16.9/2.4
R706 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 14.5/2.9
R708 7030004990 S.RES ERJ2GEJ 221 X (220) B 12.8/11.4
R710 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 10.8/10.7
R712 7030005220 S.RES
ERJ2GEJ 223 X (22 k) T 4.5/13.9
R715 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 3.8/8.9
R726 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 27.7/14.9
R727 7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
[4], [5], [7], [10], [16], [18], [19],
7.41/9.43 B ]42[ ,]12[
7030005120 S.RES ERJ2GEJ 102 X (1 k)
except [4], [5], [7], [10], [16], [18],
[19], [21], [24] B 34.9/14.7
R728 7030010040 S.RES ERJ2GEJ-JPW
[5], [7], [10], [16], [19], [21], [23],
1.11/91 B ]42[
7030011210 S.RES ERJ2GEJ 1R0 X (1)
except [5], [7], [10], [16], [19], [21],
1.11/91 B ]42[
C701 4030017460 S.CER ECJ0EB1E102K T 35/10.7
C702 4030017420 S.CER ECJ0EC1H470J B 31.3/10.5
C703 4030017460 S.CER ECJ0EB1E102K B 32.3/10.5
C705 4030006990 S.CER C1608 CH 1H 080D-T
[5], [7], [10], [16], [19], [21], [23],
9.01/4.13 T ]42[
4030009520 S.CER C1608 CH 1H 020B-T
except [5], [7], [10], [16], [19],
9.01/4.13 T ]42[ ,]12[
C707 4030017460 S.CER ECJ0EB1E102K B 26.3/17.6
C708 4030006860 S.CER C1608 JB 1H 102K-T T 28.5/13.7
C709 4030006980 S.CER C1608 CH 1H 070D-T
[5], [7], [10], [16], [19], [21], [24] T 27.3/13.7
4030007010 S.CER C1608 CH 1H 100D-T [9], [23] T 27.3/13.7
4030011770 S.CER C1608 CH 1H 060B-T
[1], [2], [3], [11], [12], [13], [14],
[15], [17], [25], [26] T 27.3/13.7
C711 4030007020 S.CER C1608 CH 1H 120J-T T
25.9/13.7
4030009920 S.CER C1608 CH 1H 050B-T T 25.9/13.7
C712 4030007020 S.CER C1608 CH 1H 120J-T
[4], [5], [6], [7], [8], [10], [16], [18],
[19], [20], [21], [22], [24] T 22.3/13.8
4030007040 S.CER C1608 CH 1H 180J-T
[1], [2], [3], [11], [12], [13], [14],
[15], [17], [25], [26] T 22.3/13.8
4030009650 S.CER C1608 CH 1H 240J-T [9], [23] T 22.3/13.8
C713 4030007080 S.CER C1608 CH 1H 390J-T B 27/13.2
C715 4030017460 S.CER ECJ0EB1E102K B 15.4/13.1
C716 4030017460 S.CER ECJ0EB1E102K B 14.4/13.1
C718 4030017460 S.CER ECJ0EB1E102K T 15.9/2.4
C719 4030016790 S.CER ECJ0EB1C103K B 12.7/13.1
C720 4030017670 S.CER ECJ0EC1H390J
[5], [7], [10], [16], [19], [21], [24] B 19/8.4
4030018070 S.CER ECJ0EC1H300J
except [5], [7], [10], [16], [19], [21],
4.8/91 B ]42[
C721 4030017380 S.CER ECJ0EC1H050B [9], [23] only B 17.2/11.5
C722 4030017420 S.CER ECJ0EC1H470J B 16.4/13.1
C723 4030017460 S.CER ECJ0EB1E102K B 10.6/9.8
C724 4030017460 S.CER ECJ0EB1E102K B 8.3/16
C725 4030017420 S.CER ECJ0EC1H470J T 10.6/13.3
C726 4030017460 S.CER ECJ0EB1E102K T 11.6/13.3
C727 4030017460 S.CER ECJ0EB1E102K T 12.6/13.3
C729 4030017580 S.CER ECJ0EC1H060C
[4], [6], [8], [9], [18], [20][22], [23] B 11/11.8
4030017610 S.CER ECJ0EC1H090C [9], [23] B 11/11.8
C731 4030017360 S.CER ECJ0EC1H030B T 4.1/12.9
C732 4030017460 S.CER ECJ0EB1E102K T 5.1/10.6
C733 4030017360 S.CER ECJ0EC1H030B T 4.9/5.5
