Icom IC-F50 Service Manual

[FRONT UNIT]
C434 4550006250 S.TANTALUM TEESVA 1A 106M8L T
C435 4550007060 S.TANTALUM ECSTIAX336R T
C436 4030016950 S.CERAMIC ECJ0EB1A473K T
C437 4030017490 S.CERAMIC C1608 JB 1A 105K-T B
C441 4030016780 S.CERAMIC ECJ0EB1C153K T
C442 4030016930 S.CERAMIC ECJ0EB1A104K T
C443 4030017740 S.CERAMIC ECJ0EB1E821K T
C444 4030016930 S.CERAMIC ECJ0EB1A104K T
C445 4030017460 S.CERAMIC ECJ0EB1E102K T
C446 4030017460 S.CERAMIC ECJ0EB1E102K T
C447 4030017760 S.CERAMIC ECJ0EB1H222K T
C448 4030017690 S.CERAMIC ECJ0EC1H121J T
C449 4030017770 S.CERAMIC ECJ0EB1E332K T
C450 4030017420 S.CERAMIC ECJ0EC1H470J T
C461 4030017420 S.CERAMIC ECJ0EC1H470J T
C462 4030017420 S.CERAMIC ECJ0EC1H470J T
C463 4030017420 S.CERAMIC ECJ0EC1H470J T
C464 4030017420 S.CERAMIC ECJ0EC1H470J T
C465 4030017420 S.CERAMIC ECJ0EC1H470J T
C466 4030017420 S.CERAMIC ECJ0EC1H470J T
C467 4030017420 S.CERAMIC ECJ0EC1H470J T
C468 4030017420 S.CERAMIC ECJ0EC1H470J T
C473 4030016790 S.CERAMIC ECJ0EB1C103K T
C474 4030017490 S.CERAMIC C1608 JB 1A 105K-T T
C475 4030017460 S.CERAMIC ECJ0EB1E102K T
C476 4030017460 S.CERAMIC ECJ0EB1E102K T
C477 4030017460 S.CERAMIC ECJ0EB1E102K T
C478 4030017460 S.CERAMIC ECJ0EB1E102K T
C479 4030017460 S.CERAMIC ECJ0EB1E102K T
C481 4030017460 S.CERAMIC ECJ0EB1E102K T
C482 4030017460 S.CERAMIC ECJ0EB1E102K T
C483 4030017460 S.CERAMIC ECJ0EB1E102K T
C484 4030017460 S.CERAMIC ECJ0EB1E102K B
C485 4030017460 S.CERAMIC ECJ0EB1E102K B
C486 4030017460 S.CERAMIC ECJ0EB1E102K T
C487 4030017460 S.CERAMIC ECJ0EB1E102K T
C488 4030017460 S.CERAMIC ECJ0EB1E102K T
C489 4030017460 S.CERAMIC ECJ0EB1E102K T
C490 4030017460 S.CERAMIC ECJ0EB1E102K T
C491 4030017460 S.CERAMIC ECJ0EB1E102K T
C492 4030017460 S.CERAMIC ECJ0EB1E102K T
C493 4030016930 S.CERAMIC ECJ0EB1A104K T
C494 4030017460 S.CERAMIC ECJ0EB1E102K T
C495 4030017460 S.CERAMIC ECJ0EB1E102K T
C496 4550007060 S.TANTALUM ECSTIAX336R T
C497 4030016790 S.CERAMIC ECJ0EB1C103K T
C498 4030017430 S.CERAMIC ECJ0EC1H101J T
C499 4030017420 S.CERAMIC ECJ0EC1H470J T
C500 4030016930 S.CERAMIC ECJ0EB1A104K B
J401 6510023520 S.CONNECTOR 54104-3692 T
J402 6510023830 S.CONNECTOR SM04B-SRSS-TB T
DS401 5030002630 LCD L3-0048TAY-2 B
DS402 5040002420 S.LED SML-310MT T86 B
DS403 5040002420 S.LED SML-310MT T86 B
DS404 5040002960 S.LED SML-A12MT T86 B
DS405 5040002960 S.LED SML-A12MT T86 B
DS406 5040002670 S.LED CL-165HR/YG B
MC401 7700002480 MICROPHONE SKB-2746 LPC B
S401 2260002840 SWITCH SKHLLFA010 T
SP401 2510001092 SPEAKER 036D0801B <FG> T
W401 8900011880 CABLE OPC-1210 (P=0.5 N=36 L=70) T
W402 7120000470 JUMPER ERDS2T0 T
W403 7120000470 JUMPER ERDS2T0 T
EP401 0910056543 PCB B 6033C
EP402 8930061530 LCD CONTACT SRCN-2681-SP-N-W B
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 2
REF ORDER
DESCRIPTION M.
NO. NO.
A: The scrambler IC is installed type. B: The scrambler IC is not installed type.
C: High-band. D: Low-band. E: Intrinsically safe version.
[MAIN UNIT]
IC1 1110003200 S.IC TA31136FN (EL) B
IC2 1130008560 S.IC TC75S51F (TE85L) T
IC4 1140005990 S.IC MB15A02PFV1-G-BND-ER B
IC5 1110005340 S.IC NJM12902V-TE1 T
IC6 1190000350 S.IC M62363FP-650C T
IC7 1190001860 S.IC EW-460-FT B
IC9 1110005350 S.IC NJM2870F05-TE1 T
IC10 1110006220 S.IC AK2346-E2 T
IC11 1130006220 S.IC TC4W53FU (TE12L) T
IC12 1130007570 S.IC BU4094BCFV-E2 T
IC13 1130008090 S.IC BU4066BCFV-E1 T
IC14 1110004990 S.IC FX214LG/TR
A only B
IC15 1130007990 S.IC TC3W03FU (TE12L)
A only B
Q1 1560000840 S.FET 2SK1829 (TE85R) T
Q2 1580000730 S.FET 3SK293 (TE85L) T
Q3 1580000760 S.FET 3SK299-T1 U73 B
Q4 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) B
Q5 1530000371 S.TRANSISTOR 2SC3356-T1B R25 B
Q7 1560001230 S.FET RD07MVS1 T
Q8 1560001240 S.FET RD01MUS1 T
Q9 1530003310 S.TRANSISTOR 2SC5107-O (TE85R) B
Q10 1530003310 S.TRANSISTOR 2SC5107-O (TE85R) B
Q11 1530003310 S.TRANSISTOR 2SC5107-O (TE85R) B
Q12 1530003310 S.TRANSISTOR 2SC5107-O (TE85R) B
Q13 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q14 1530002920 S.TRANSISTOR 2SC4226-T1 R25 B
Q15 1590001400 S.TRANSISTOR XP1214 (TX) T
Q16 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q17 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) B
Q18 1560000540 S.FET 2SK880-Y (TE85R) T
Q21 1510000920 S.TRANSISTOR 2SA1577 T106 Q B
Q22 1510000920 S.TRANSISTOR 2SA1577 T106 Q B
Q23 1520000450 S.TRANSISTOR 2SB1132 T100 Q B
Q24 1590001190 S.TRANSISTOR XP6501-(TX) .AB B
Q25 1590000720 S.TRANSISTOR DTA144EUA T106 B
Q26 1590003320 S.FET TPC6103 (TE85L) T
Q27 1590000720 S.TRANSISTOR DTA144EUA T106
A only B
Q29 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q34 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) B
D1 1790001670 S.DIODE RB706F-40T106 T
D2 1750000580 S.DIODE 1SV307 (TPH3) B
D3 1750000710 S.VARICAP HVC350BTRF T
D4 1750000710 S.VARICAP HVC350BTRF T
D5 1790001260 S.DIODE MA2S077-(TX) B
D6 1790001240 S.DIODE MA2S728-(TX) T
D7 1750000710 S.VARICAP HVC350BTRF T
D8 1750000710 S.VARICAP HVC350BTRF T
D9 1750000710 S.VARICAP HVC350BTRF T
D10 1750000710 S.VARICAP HVC350BTRF T
D12 1790001250 S.DIODE MA2S111-(TX) B
D14 1790001260 S.DIODE MA2S077-(TX) B
D15 1790001260 S.DIODE MA2S077-(TX) B
D16 1750000710 S.VARICAP HVC350BTRF B
D17 1750000710 S.VARICAP HVC350BTRF B
D18 1720000570 S.VARICAP MA368 (TX) B
D21 1750000710 S.VARICAP HVC350BTRF B
D22 1750000710 S.VARICAP HVC350BTRF B
D25 1790001250 S.DIODE MA2S111-(TX) T
D37 1790001250 S.DIODE MA2S111-(TX) B
D38 1790001250 S.DIODE MA2S111-(TX) T
D39 1790001670 S.DIODE RB706F-40T106 T
FI1 2030000150 S.MONOLITH FL-335 (46.350 MHz) B
FI2 2020001840 CERAMIC ALFYM450F=K T
FI3 2040001440 S.LC NFE31PT152Z1E9L B
X1 6070000190
S.DISCRIMINATOR CDBCB450KCAY24-R0 T
X2 6050011710 S.XTAL CR-763 (15.3 MHz) B
X3 6050011560 S.XTAL CR-746 (4.000 MHz)
A only B
X4 6050011730 S.XTAL CR-765 (3.6864 MHz) B
L1 6200008700 S.COIL 0.30-0.9-6TR 17.5N B
L2 6200008240 S.COIL 0.30-0.9-5TL 14N B
L3 6200009470 S.COIL 0.40-0.9-2TL B
L4 6200009470 S.COIL 0.40-0.9-2TL B
L5 6200010850 S.COIL LQW18AN22NG00D B
L7 6200007690 S.COIL LQW2BHN18NJ01L
C T
6200007700 S.COIL LQW2BHN22NJ01L
D T
L8 6200007690 S.COIL LQW2BHN18NJ01L
C T
6200007700 S.COIL LQW2BHN22NJ01L
D T
REF ORDER
DESCRIPTION M.
NO. NO.
