Icom IC-F50 Service Manual

[MAIN UNIT][MAIN UNIT]
L9 6200007680 S.COIL LQW2BHN12NJ01L B
L11 6200007230 S.COIL LQW2BHN15NJ01L
D B
6200007680 S.COIL LQW2BHN12NJ01L C B
L12 6200005720 S.COIL ELJRE 33NG-F B
L13 6200003350 S.COIL ELJNC R27K-F B
L15 6200002850 S.COIL NL 252018T-R82J B
L17 6200008240 S.COIL 0.30-0.9-5TL 14N B
L19 6200005650 S.COIL ELJRE 8N2Z-F
C B
6200005670 S.COIL ELJRE 12NG-F D B
L20 6200005680 S.COIL ELJRE 15NG-F
C B
6200005690 S.COIL ELJRE 18NG-F
D B
L21 6200005720 S.COIL ELJRE 33NG-F B
L22 6200005700 S.COIL ELJRE 22NG-F B
L23 6200002790 S.COIL ELJFC R82M-F T
L25 6200008510 S.COIL 0.30-0.9-4TR 10.5N B
L26 6200008490 S.COIL 0.30-0.9-3TR 7.5N B
L27 6200004950 S.COIL NL 252018T-1R8J T
L28 6200002710 S.COIL ELJFC 1R8K-F T
L29 6200004660 S.COIL MLF1608A 1R8K-T T
L30 6200007720 S.COIL LQW2BHN33NJ01L T
L32 6200005690 S.COIL ELJRE 18NG-F T
L33 6200004480 S.COIL MLF1608D R82K-T B
L35 6200003540 S.COIL MLF1608D R22K-T B
L38 6200005710 S.COIL ELJRE 27NG-F B
L40 6200002850 S.COIL NL 252018T-R82J T
L41 6200005720 S.COIL ELJRE 33NG-F B
L42 6200004950 S.COIL NL 252018T-1R8J T
L43 6200002710 S.COIL ELJFC 1R8K-F T
L44 6200009110 S.COIL 0.30-0.9-2TR 4.1N B
L45 6200008700 S.COIL 0.30-0.9-6TR 17.5N B
R1 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) B
R2 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R3 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) T
R4 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R5 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R6 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R7 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ) T
R8 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) T
R9 7030008280 S.RESISTOR ERJ2GEJ 271 X (270 Ω) T
R10 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R11 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R12 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) T
R13 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R14 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R15 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R16 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) T
R17 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) B
R18 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R19 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ) T
R20 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R21 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) T
R22 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R23 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) T
R25 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R29 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω) B
R30 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R31 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R32 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R33 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω) B
R34 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) B
R35 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R36 7030005030 S.RESISTOR ERJ2GEJ 152 X (1.5 kΩ) T
R37 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) B
R38 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R39 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) B
R40 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω) B
R43 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) B
R44 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R45 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) B
R46 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) B
R50 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R51 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R52 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R53 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) T
R54 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) T
R55 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R57 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
D T
7030008280 S.RESISTOR ERJ2GEJ 271 X (270 Ω) C T
R58 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) T
R59 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R61 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) B
R62 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) B
R65 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R66 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ) B
R67 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
R68 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R69 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R70 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R71 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R73 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R74 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R75 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) B
R76 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R77 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R78 7030005010 S.RESISTOR ERJ2GEJ 681 X (680 Ω)
C T
7030008370 S.RESISTOR ERJ2GEJ 561 X (560 Ω) D T
R79 7030006020 S.RESISTOR RR0510P-682-D (6.8 kΩ) B
R80 7030005010 S.RESISTOR ERJ2GEJ 681 X (680 Ω)
D T
7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) C T
R81 7030009320 S.RESISTOR ERJ2GEJ 4R7 X (4.7 Ω) B
R83 7030006020 S.RESISTOR RR0510P-682-D (6.8 kΩ) B
R84 7030006020 S.RESISTOR RR0510P-682-D (6.8 kΩ) B
R85 7030006020 S.RESISTOR RR0510P-682-D (6.8 kΩ) B
R86 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R87 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) T
R89 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R90 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) T
R92 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ) T
R93 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R94 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) B
R95 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R96 7030008410 S.RESISTOR ERJ2GEJ 392 X (3.9 kΩ)
D T
7030009140 S.RESISTOR ERJ2GEJ 272 X (2.7 kΩ)
C T
R97 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R98 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ) B
R100 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) B
R101 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R102 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) B
R103 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R103 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ) T
R104 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) T
R105 7030005230 S.RESISTOR ERJ2GEJ 334 X (330 kΩ) T
R106 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ) T
R107 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R108 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R109 7030005580 S.RESISTOR ERJ2GEJ 560 X (56 Ω) T
R111 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R113 7030006610 S.RESISTOR ERJ2GEJ 394 X (390 kΩ) T
R114 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R115 7030007570 S.RESISTOR ERJ2GEJ 122X (1.2 kΩ) B
R116 7030007060 S.RESISTOR ERJ2GEJ 684X (680 kΩ) B
R117 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R118 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R119 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R120 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) T
R121 7030008010 S.RESISTOR ERJ2GEJ 123 X (12 kΩ) T
R122 7030006610 S.RESISTOR ERJ2GEJ 394 X (390 kΩ) T
R123 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ) T
R124 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) T
R125 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R126 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) T
R127 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) T
R128 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) T
R129 7030005840 S.RESISTOR RR0510R-473-D (47 kΩ) B
R130 7030006000 S.RESISTOR RR0510P-222-D (2.2 kΩ) B
R131 7030006000 S.RESISTOR RR0510P-222-D (2.2 kΩ) B
R132 7030005840 S.RESISTOR RR0510R-473-D (47 kΩ) B
R133 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) T
R133 7030008290 S.RESISTOR ERJ2GEJ 183 X (18 kΩ) T
R134 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) T
R135 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ) T
R139 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
B only B
R141 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ) T
R144 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
A only B
R145 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
A only B
R147 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R148 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) B
R151 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ) T
R152 7030008310 S.RESISTOR ERJ2GEJ 564 X (560 kΩ) T
R153 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ) T
R154 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ) T
R155 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R157 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R161 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R162 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R163 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R164 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R165 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R166 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ) B
R167 7030005700 S.RESISTOR ERJ2GEJ 274 X (270 kΩ) T
R168 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R169 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
6 - 3
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
A: The scrambler IC is installed type. B: The scrambler IC is not installed type.
C: High-band. D: Low-band. E: Intrinsically safe version.
