Icom IC-F50 Service Manual

[MAIN UNIT][MAIN UNIT]
R170 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) B
R173 7030008400 S.RESISTOR ERJ2GEJ 182 X (1.8 kΩ) T
R180 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R181 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R182 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R183 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ) T
R184 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) B
R185 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) T
R186 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) B
R190 7510001730 S.THEMISTOR ERTJOEP 473J B
R191 7030010080 S.RESISTOR ERJ2RHD 104 X (100 kΩ) B
R192 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R193 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ) T
R194 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R195 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
A only T
R206 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ) T
R207 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ) T
R235 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) B
R337 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) B
R338 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R339 7030003860 S.RESISTOR ERJ3GE JPW V T
C1 4030006990 S.CERAMIC C1608 CH 1H 080D-T
C B
4030007000 S.CERAMIC C1608 CH 1H 090D-T
D B
C2 4030009520 S.CERAMIC C1608 CH 1H 020B-T
D B
4030009560 S.CERAMIC C1608 CH 1H R75B-T
C B
C3 4030006980 S.CERAMIC C1608 CH 1H 070D-T
C B
4030006990 S.CERAMIC C1608 CH 1H 080D-T
D B
C4 4030009550 S.CERAMIC C1608 CH 1H 2R5B-T B
C5 4030009530 S.CERAMIC C1608 CH 1H 030B-T
C B
4030009920 S.CERAMIC C1608 CH 1H 050B-T
D B
C6 4030017460 S.CERAMIC ECJ0EB1E102K B
C7 4030017460 S.CERAMIC ECJ0EB1E102K B
C8 4030009910 S.CERAMIC C1608 CH 1H 040B-T
C only B
C9 4030009510 S.CERAMIC C1608 CH 1H 010B-T
C B
4030009910 S.CERAMIC C1608 CH 1H 040B-T
D B
C10 4030017460 S.CERAMIC ECJ0EB1E102K B
C11 4030011770 S.CERAMIC C1608 CH 1H 060B-T
C only B
C12 4030007020 S.CERAMIC C1608 CH 1H 120J-T
D only B
C13 4030007050 S.CERAMIC C1608 CH 1H 220J-T
D B
4030007040 S.CERAMIC C1608 CH 1H 180J-T
C B
C14 4030017360 S.CERAMIC ECJ0EC1H030B
C B
4030017580 S.CERAMIC ECJ0EC1H060C
D B
C15 4030017460 S.CERAMIC ECJ0EB1E102K T
C16 4030007050 S.CERAMIC C1608 CH 1H 220J-T
C B
4030009650 S.CERAMIC C1608 CH 1H 240J-T
D B
C17 4030017510 S.CERAMIC ECJ0EC1H680J T
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C19 4030017460 S.CERAMIC ECJ0EB1E102K B
C20 4030017590 S.CERAMIC ECJ0EC1H070C T
C21 4030017400 S.CERAMIC ECJ0EC1H220J
C T
4030017410 S.CERAMIC ECJ0EC1H240J
D T
C22 4030017610 S.CERAMIC ECJ0EC1H090C T
C23 4030017350 S.CERAMIC ECJ0EC1H020B T
C24 4030017400 S.CERAMIC ECJ0EC1H220J
C T
4030017410 S.CERAMIC ECJ0EC1H240J
D T
C25 4030017610 S.CERAMIC ECJ0EC1H090C T
C27 4030017460 S.CERAMIC ECJ0EB1E102K T
C28 4030017460 S.CERAMIC ECJ0EB1E102K B
C30 4030017590 S.CERAMIC ECJ0EC1H070C T
C32 4030017460 S.CERAMIC ECJ0EB1E102K T
C33 4030017460 S.CERAMIC ECJ0EB1E102K T
C34 4030017420 S.CERAMIC ECJ0EC1H470J T
C35 4030016930 S.CERAMIC ECJ0EB1A104K T
C36 4030017460 S.CERAMIC ECJ0EB1E102K B
C37 4030017460 S.CERAMIC ECJ0EB1E102K B
C38 4030017460 S.CERAMIC ECJ0EB1E102K B
C39 4030017620 S.CERAMIC ECJ0EC1H100C
C T
4030017630 S.CERAMIC ECJ0EC1H120J
D T
C40 4030017520 S.CERAMIC ECJ0EC1H0R3B T
C41 4030017380 S.CERAMIC ECJ0EC1H050B B
C42 4030017460 S.CERAMIC ECJ0EB1E102K T
C43 4030017460 S.CERAMIC ECJ0EB1E102K T
C44 4030017340 S.CERAMIC ECJ0EC1H010B
D B
4030017550 S.CERAMIC ECJ0EC1H1R5B
C B
C45 4030017620 S.CERAMIC ECJ0EC1H100C
C T
4030017630 S.CERAMIC ECJ0EC1H120J
D T
C46 4030017460 S.CERAMIC ECJ0EB1E102K T
C48 4030017400 S.CERAMIC ECJ0EC1H220J B
C49 4030017380 S.CERAMIC ECJ0EC1H050B B
C50 4030017460 S.CERAMIC ECJ0EB1E102K B
C51 4030017460 S.CERAMIC ECJ0EB1E102K B
C52 4030017420 S.CERAMIC ECJ0EC1H470J B
C53 4030016790 S.CERAMIC ECJ0EB1C103K B
C54 4030017460 S.CERAMIC ECJ0EB1E102K B
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
C56 4030017400 S.CERAMIC ECJ0EC1H220J B
C57 4030017460 S.CERAMIC ECJ0EB1E102K B
C58 4030017460 S.CERAMIC ECJ0EB1E102K B
C59 4030017460 S.CERAMIC ECJ0EB1E102K B
C60 4030017460 S.CERAMIC ECJ0EB1E102K B
C61 4030017430 S.CERAMIC ECJ0EC1H101J B
C62 4030017680 S.CERAMIC ECJ0EC1H820J B
C63 4030017420 S.CERAMIC ECJ0EC1H470J B
C65 4030017460 S.CERAMIC ECJ0EB1E102K B
C66 4030017460 S.CERAMIC ECJ0EB1E102K B
C67 4030017460 S.CERAMIC ECJ0EB1E102K B
C69 4030017730 S.CERAMIC ECJ0EB1E471K B
C70 4030017730 S.CERAMIC ECJ0EB1E471K B
C71 4030016930 S.CERAMIC ECJ0EB1A104K B
C72 4030017420 S.CERAMIC ECJ0EC1H470J B
C73 4030017460 S.CERAMIC ECJ0EB1E102K T
C74 4030017460 S.CERAMIC ECJ0EB1E102K T
C75 4550006050 S.TANTALUM TEESVA 0J 106M8L B
C76 4030016790 S.CERAMIC ECJ0EB1C103K T
C77 4030017460 S.CERAMIC ECJ0EB1E102K B
C78 4030017460 S.CERAMIC ECJ0EB1E102K T
C79 4030011810 S.CERAMIC C1608 JB 1A 224K-T T
C80 4030017780 S.CERAMIC ECJ0EB1E472K T
C81 4030016790 S.CERAMIC ECJ0EB1C103K T
C82 4030017460 S.CERAMIC ECJ0EB1E102K B
C83 4030017390 S.CERAMIC ECJ0EC1H180C
C T
4030017670 S.CERAMIC ECJ0EC1H390J
D T
C84 4030017460 S.CERAMIC ECJ0EB1E102K T
C86 4030017400 S.CERAMIC ECJ0EC1H220J
C T
4030017650 S.CERAMIC ECJ0EC1H270J
D T
C88 4030017460 S.CERAMIC ECJ0EB1E102K T
C91 4030017730 S.CERAMIC ECJ0EB1E471K T
C92 4030017630 S.CERAMIC ECJ0EC1H120J T
C93 4030017600 S.CERAMIC ECJ0EC1H080C
C B
4030017620 S.CERAMIC ECJ0EC1H100C
D B
C97 4030017460 S.CERAMIC ECJ0EB1E102K B
C98 4030017620 S.CERAMIC ECJ0EC1H100C B
C99 4030017460 S.CERAMIC ECJ0EB1E102K B
C100 4030017620 S.CERAMIC ECJ0EC1H100C T
C102 4030017380 S.CERAMIC ECJ0EC1H050B B
C103 4030017350 S.CERAMIC ECJ0EC1H020B B
C104 4030017460 S.CERAMIC ECJ0EB1E102K B
C105 4030017460 S.CERAMIC ECJ0EB1E102K B
C106 4030017420 S.CERAMIC ECJ0EC1H470J T
C107 4030017460 S.CERAMIC ECJ0EB1E102K T
C108 4030016790 S.CERAMIC ECJ0EB1C103K B
C109 4030017460 S.CERAMIC ECJ0EB1E102K T
C110 4030017730 S.CERAMIC ECJ0EB1E471K T
C111 4030017420 S.CERAMIC ECJ0EC1H470J T
C112 4030017460 S.CERAMIC ECJ0EB1E102K B
C113 4030017520 S.CERAMIC ECJ0EC1H0R3B B
C114 4030017380 S.CERAMIC ECJ0EC1H050B
C B
4030017630 S.CERAMIC ECJ0EC1H120J
D B
C115 4030017570 S.CERAMIC ECJ0EC1H040B
C B
4030017620 S.CERAMIC ECJ0EC1H100C
D B
C116 4030017460 S.CERAMIC ECJ0EB1E102K B
C117 4030017730 S.CERAMIC ECJ0EB1E471K B
C118 4030017530 S.CERAMIC ECJ0EC1H0R5B B
C119 4030016790 S.CERAMIC ECJ0EB1C103K B
C120 4030017730 S.CERAMIC ECJ0EB1E471K B
C121 4030017380 S.CERAMIC ECJ0EC1H050B
C B
4030017600 S.CERAMIC ECJ0EC1H080C
D B
C122 4030017570 S.CERAMIC ECJ0EC1H040B
C B
4030017630 S.CERAMIC ECJ0EC1H120J
D B
C123 4030017630 S.CERAMIC ECJ0EC1H120J
D B
4030017640 S.CERAMIC ECJ0EC1H150J
C B
C124 4030017380 S.CERAMIC ECJ0EC1H050B
C B
4030017620 S.CERAMIC ECJ0EC1H100C
D B
C126 4030017390 S.CERAMIC ECJ0EC1H180J
D B
4030017640 S.CERAMIC ECJ0EC1H150J
C B
C127 4030017580 S.CERAMIC ECJ0EC1H060C
C B
4030017610 S.CERAMIC ECJ0EC1H090C
D B
C129 4030017530 S.CERAMIC ECJ0EC1H0R5B B
C130 4030016950 S.CERAMIC ECJ0EB1A473K T
C132 4030017460 S.CERAMIC ECJ0EB1E102K T
C133 4030017630 S.CERAMIC ECJ0EC1H120J
C B
4030017640 S.CERAMIC ECJ0EC1H150J
D B
C134 4030017630 S.CERAMIC ECJ0EC1H120J
C B
4030017640 S.CERAMIC ECJ0EC1H150J
D B
C135 4030017460 S.CERAMIC ECJ0EB1E102K B
C136 4030016930 S.CERAMIC ECJ0EB1A104K B
C137 4030016790 S.CERAMIC ECJ0EB1C103K B
C138 4030017460 S.CERAMIC ECJ0EB1E102K T
C139 4030016930 S.CERAMIC ECJ0EB1A104K T
C140 4030016930 S.CERAMIC ECJ0EB1A104K B
C141 4030017460 S.CERAMIC ECJ0EB1E102K B
6 - 4
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
A: The scrambler IC is installed type. B: The scrambler IC is not installed type.
C: High-band. D: Low-band. E: Intrinsically safe version.
