Icom IC-F50 Service Manual

[MAIN UNIT][MAIN UNIT]
C143 4030017460 S.CERAMIC ECJ0EB1E102K T
C144 4030017420 S.CERAMIC ECJ0EC1H470J T
C145 4030017420 S.CERAMIC ECJ0EC1H470J T
C146 4550000270 S.TANTALUM TEESVA 1E 474M8L T
C147 4550000460 S.TANTALUM TEESVA 1C 105M8L T
C148 4550006250 S.TANTALUM TEESVA 1A 106M8L B
C149 4030017460 S.CERAMIC ECJ0EB1E102K T
C150 4030017490 S.CERAMIC C1608 JB 1A 105K-T T
C151 4030016930 S.CERAMIC ECJ0EB1A104K B
C152 4030017420 S.CERAMIC ECJ0EC1H470J B
C153 4030017420 S.CERAMIC ECJ0EC1H470J B
C154 4030017420 S.CERAMIC ECJ0EC1H470J B
C155 4030017420 S.CERAMIC ECJ0EC1H470J T
C156 4030017460 S.CERAMIC ECJ0EB1E102K B
C157 4030017620 S.CERAMIC ECJ0EC1H100C B
C158 4030016930 S.CERAMIC ECJ0EB1A104K B
C159 4030017460 S.CERAMIC ECJ0EB1E102K B
C161 4030017620 S.CERAMIC ECJ0EC1H100C B
C162 4030017500 S.CERAMIC ECJ0EC1H560J B
C163 4030017570 S.CERAMIC ECJ0EC1H040B B
C164 4030017590 S.CERAMIC ECJ0EC1H070C B
C165 4030016790 S.CERAMIC ECJ0EB1C103K B
C166 4030017360 S.CERAMIC ECJ0EC1H030B B
C167 4030016930 S.CERAMIC ECJ0EB1A104K B
C168 4030016930 S.CERAMIC ECJ0EB1A104K B
C169 4030016930 S.CERAMIC ECJ0EB1A104K B
C170 4030016930 S.CERAMIC ECJ0EB1A104K T
C171 4030018560 S.CERAMIC C2012 JB 1A 475K-T T
C172 4030017460 S.CERAMIC ECJ0EB1E102K T
C173 4030017460 S.CERAMIC ECJ0EB1E102K T
C180 4030016930 S.CERAMIC ECJ0EB1A104K B
C188 4030017460 S.CERAMIC ECJ0EB1E102K B
C202 4030016930 S.CERAMIC ECJ0EB1A104K B
C203 4030017460 S.CERAMIC ECJ0EB1E102K B
C205 4030017380 S.CERAMIC ECJ0EC1H050B T
C206 4030017590 S.CERAMIC ECJ0EC1H070C T
C208 4030017590 S.CERAMIC ECJ0EC1H070C T
C209 4030017460 S.CERAMIC ECJ0EB1E102K T
C211 4030018560 S.CERAMIC C2012 JB 1A 475K-T B
C213 4030016930 S.CERAMIC ECJ0EB1A104K T
C220 4030016970 S.CERAMIC ECJ0EB1C223K B
C221 4030016940 S.CERAMIC ECJ0EB1A393K T
C222 4030016790 S.CERAMIC ECJ0EB1C103K T
C223 4030016930 S.CERAMIC ECJ0EB1A104K T
C224 4550006480 S.TANTALUM TEESVA 1C 475M8L B
C225 4030017730 S.CERAMIC ECJ0EB1E471K T
C226 4030017460 S.CERAMIC ECJ0EB1E102K B
C227 4030016790 S.CERAMIC ECJ0EB1C103K B
C228 4030017460 S.CERAMIC ECJ0EB1E102K B
C229 4030016930 S.CERAMIC ECJ0EB1A104K T
C230 4030017460 S.CERAMIC ECJ0EB1E102K T
C231 4030016790 S.CERAMIC ECJ0EB1C103K B
C232 4030016790 S.CERAMIC ECJ0EB1C103K B
C233 4550006350 S.TANTALUM TEESVB2 1A 226M8L B
C234 4030017330 S.CERAMIC ECJ0EF1C104Z B
C235 4030016790 S.CERAMIC ECJ0EB1C103K B
C236 4510004630 S.ELECTROLYTIC ECEV1CA100SR T
C237 4030016790 S.CERAMIC ECJ0EB1C103K T
C238 4550006480 S.TANTALUM TEESVA 1C 475M8L B
C239 4030017330 S.CERAMIC ECJ0EF1C104Z T
C240 4030017460 S.CERAMIC ECJ0EB1E102K B
C241 4030017460 S.CERAMIC ECJ0EB1E102K T
C242 4030017460 S.CERAMIC ECJ0EB1E102K B
C243 4030017420 S.CERAMIC ECJ0EC1H470J B
C244 4030017420 S.CERAMIC ECJ0EC1H470J B
C251 4030017420 S.CERAMIC ECJ0EC1H470J T
C252 4030017910 S.CERAMIC ECJ0EB1H152K T
C253 4030017710 S.CERAMIC ECJ0EC1H181J T
C254 4030017750 S.CERAMIC ECJ0EB1E122K T
C255 4030016930 S.CERAMIC ECJ0EB1A104K B
C256 4030017760 S.CERAMIC ECJ0EB1H222K T
C257 4030016930 S.CERAMIC ECJ0EB1A104K T
C258 4030016930 S.CERAMIC ECJ0EB1A104K T
C259 4030017400 S.CERAMIC ECJ0EC1H220J B
C260 4030017400 S.CERAMIC ECJ0EC1H220J B
C261 4550000460 S.TANTALUM TEESVA 1C 105M8L B
C262 4550000460 S.TANTALUM TEESVA 1C 105M8L B
C263 4030017460 S.CERAMIC ECJ0EB1E102K T
C264 4550006350 S.TANTALUM TEESVB2 1A 226M8L B
C265 4030017460 S.CERAMIC ECJ0EB1E102K T
C266 4030017760 S.CERAMIC ECJ0EB1H222K T
C267 4030017460 S.CERAMIC ECJ0EB1E102K B
C271 4030016930 S.CERAMIC ECJ0EB1A104K T
C273 4030016930 S.CERAMIC ECJ0EB1A104K
A only B
C274 4030016930 S.CERAMIC ECJ0EB1A104K
A only B
C275 4030017490 S.CERAMIC C1608 JB 1A 105K-T
A only B
C276 4030017490 S.CERAMIC C1608 JB 1A 105K-T
A only B
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
C277 4030017490 S.CERAMIC C1608 JB 1A 105K-T A only B
C279 4030017650 S.CERAMIC ECJ0EC1H270J
A only B
C280 4030017650 S.CERAMIC ECJ0EC1H270J
A only B
C281 4030016930 S.CERAMIC ECJ0EB1A104K T
C287 4030016930 S.CERAMIC ECJ0EB1A104K B
C288 4030016930 S.CERAMIC ECJ0EB1A104K
A only B
C289 4030016930 S.CERAMIC ECJ0EB1A104K
A only B
C290 4030016930 S.CERAMIC ECJ0EB1A104K T
C291 4030017420 S.CERAMIC ECJ0EC1H470J B
C292 4030017460 S.CERAMIC ECJ0EB1E102K B
C293 4030017460 S.CERAMIC ECJ0EB1E102K T
C294 4030017460 S.CERAMIC ECJ0EB1E102K B
C295 4030017460 S.CERAMIC ECJ0EB1E102K T
C296 4030017460 S.CERAMIC ECJ0EB1E102K T
C297 4030017460 S.CERAMIC ECJ0EB1E102K T
C298 4030017460 S.CERAMIC ECJ0EB1E102K T
C299 4030017460 S.CERAMIC ECJ0EB1E102K T
C300 4030017460 S.CERAMIC ECJ0EB1E102K T
C301 4030017460 S.CERAMIC ECJ0EB1E102K T
C302 4030017620 S.CERAMIC ECJ0EC1H100C B
C303 4030017460 S.CERAMIC ECJ0EB1E102K B
C304 4030016930 S.CERAMIC ECJ0EB1A104K
A only T
C305 4030016930 S.CERAMIC ECJ0EB1A104K T
C333 4030017420 S.CERAMIC ECJ0EC1H470J T
C339 4030017350 S.CERAMIC ECJ0EC1H020B
D T
4030017530 S.CERAMIC ECJ0EC1H0R5B
C T
C363 4030017580 S.CERAMIC ECJ0EC1H060C B
C364 4030017580 S.CERAMIC ECJ0EC1H060C B
C365 4030009350 S.CERAMIC C1608 CH 1H 3R5B-T
D B
4030009520 S.CERAMIC C1608 CH 1H 020B-T
C B
C366 4030017460 S.CERAMIC ECJ0EB1E102K T
C367 4030009910 S.CERAMIC C1608 CH 1H 040B-T
C B
4030009920 S.CERAMIC C1608 CH 1H 050B-T
D B
C368 4030017420 S.CERAMIC ECJ0EC1H470J T
C369 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C370 4030017460 S.CERAMIC ECJ0EB1E102K B
C371 4030017460 S.CERAMIC ECJ0EB1E102K T
C372 4030017590 S.CERAMIC ECJ0EC1H070C
C B
4030017600 S.CERAMIC ECJ0EC1H080C
D B
C373 4030017460 S.CERAMIC ECJ0EB1E102K T
C374 4550006650 S.TANTALUM ECST1CY685R B
C375 4550006250 S.TANTALUM TEESVA 1A 106M8L T
J1 6510023520 S.CONNECTOR 54104-3692 T
F1 5210000830 S.FUSE ERBFE3R00U Other T
5210000900 S.FUSE 0434003.NRP
E T
S1 2260002750 S.SWITCH EVQP7M01K T
EP1 6910015370 S.BEAD ACZ1005Y-102-T T
EP2 0910056842 PCB B 6059B
EP3 6910015370 S.BEAD ACZ1005Y-102-T B
EP4 6910015600 S.BEAD ACZ1005Y-241 (240 Ω) T
EP5 6910015600 S.BEAD ACZ1005Y-241 (240 Ω) T
6 - 5
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
A: The scrambler IC is installed type. B: The scrambler IC is not installed type.
C: High-band. D: Low-band. E: Intrinsically safe version.
