Icom IC-F50 Service Manual

[VR UNIT]
R601 7210003130 VARIABLE TP76N97N-13F-10KA-2497 T
W601 8900012340 CABLE OPC-1260 T
EP601 0910056532 PCB B 6034B
D701 1790001810 S.VARISTOR AVR-M1005C080MTABB B
D702 1790001810 S.VARISTOR AVR-M1005C080MTABB B
D703 1790001810 S.VARISTOR AVR-M1005C080MTABB B
D704 1790001810 S.VARISTOR AVR-M1005C080MTABB T
D705 1790001810 S.VARISTOR AVR-M1005C080MTABB B
R701 7410001130 S.ARRAY EXB28V102JX T
C701 4030017460 S.CERAMIC ECJ0EB1E102K B
C702 4030017460 S.CERAMIC ECJ0EB1E102K B
C703 4030017460 S.CERAMIC ECJ0EB1E102K B
C704 4030017460 S.CERAMIC ECJ0EB1E102K B
EP701 6910012350 S.BEAD MMZ1608Y 102BT B
EP702 6910012350 S.BEAD MMZ1608Y 102BT B
EP703 6910012350 S.BEAD MMZ1608Y 102BT B
EP704 6910012350 S.BEAD MMZ1608Y 102BT B
EP705 6910012350 S.BEAD MMZ1608Y 102BT B
EP706 0910056523 PCB B 6035C
J1 6910015630 CONNECTOR 2682 ANT CONNECTOR
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 6
REF ORDER
DESCRIPTION M.
NO. NO.
A: The scrambler IC is installed type. B: The scrambler IC is not installed type.
C: High-band. D: Low-band. E: Intrinsically safe version.
REF ORDER
DESCRIPTION M.
NO. NO.
[CHASSIS UNIT]
REF ORDER
DESCRIPTION M.
NO. NO.
[CONNECTOR UNIT]
