2 - 2
• MAIN-A UNIT
(TOP VIEW)
IF IC
(IC1)
LPF
(Q39)
PLL IC
(IC4)
CPU5 LINE REGULATOR
(IC10)
RIPPLE FILTER
(Q17)
VCO SWITCH
(Q15)
POWER SWITCH
(Q23)
+8 REGULATOR
(IC9)
LOCK VOLATGE BUFFER
(Q18)
WIDE/NARROW
PHASE SHIFTER SWITCH
(Q5)
R8 REGULATOR
(Q30)
POWER SWITCH
(Q24)
APC AMP
(IC2)
WIDE/NARROW
2ND IF FILTER SWITCH
(Q40)
1ST IF FILTER
(FI1)
