6 - 8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[DSP UNIT] (IC-F80DT/DS only)
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[DSP UNIT] (IC-F80DT/DS only)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[FUSE BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R64 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 5.3/11.6
R65 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 25.7/27.1
R66 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 7.3/19.2
R67 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 22/27.3
R68 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 20.8/29.1
R70 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 9.1/10.2
R71 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 8.2/10.2
R72 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 7.3/10.2
R73 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 6.4/9.2
R74 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 5.5/9.2
R75 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 9.3/12.4
R76 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 8.4/12.4
R77 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 7.5/12.9
R78 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 6.6/12.7
R79 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 5.7/12
R80 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 20.7/35.9
R82 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 3.5/17.2
R83 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 2.1/38.6
R85 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 4.3/38.8
R86 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 12.1/20.3
R87 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 10.7/18.5
R88 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 9.8/19.8
R89 7030010040 S.RES ERJ2GE-JPW T 3.3/37.4
R90 7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) T 22/28.9
R91 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 23.4/25.7
R92 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 23.5/24.8
R93 7030010040 S.RES ERJ2GE-JPW T 22.2/24
R94 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 7.8/19.8
R95 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 17.1/19.6
R96 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 1.6/11.8
R97 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 1.9/18.6
C1 4550007070 S.TAN TEESVP 1A 475M8R B 1.2/15.3
C2 4550007070 S.TAN TEESVP 1A 475M8R B 2/27.6
C3 4550007070 S.TAN TEESVP 1A 475M8R T 23/4.9
C4 4030017420 S.CER ECJ0EC1H470J B 22.7/1.7
C5 4030016930 S.CER ECJ0EB1A104K B 1.3/17.3
C6 4030016930 S.CER ECJ0EB1A104K B 4.6/27.4
C7 4030016930 S.CER ECJ0EB1A104K T 21.5/7.7
C8 4030016930 S.CER ECJ0EB1A104K B 23.7/5.6
C9 4030017420 S.CER ECJ0EC1H470J B 9.1/8
C10 4550006250 S.TAN TEESVA 1A 106M8L B 23.5/3.3
C11 4030017460 S.CER ECJ0EB1E102K B 5.9/23.4
C12 4030017460 S.CER ECJ0EB1E102K B 4.9/35.2
C13 4030017460 S.CER ECJ0EB1E102K T 24.5/10
C14 4550007030 S.TAN TEESVP 0J 106M8R B 4.9/21.3
C15 4550007030 S.TAN TEESVP 0J 106M8R B 2.9/35.6
C16 4550007030 S.TAN TEESVP 0J 106M8R T 22.4/10.8
C17 4550006250 S.TAN TEESVA 1A 106M8L B 14.8/9.5
C18 4030016930 S.CER ECJ0EB1A104K B 16.4/12.7
C19 4030016930 S.CER ECJ0EB1A104K B 16.4/11.5
C20 4030017420 S.CER ECJ0EC1H470J T 17.5/9.7
C21 4550006250 S.TAN TEESVA 1A 106M8L B 11.8/13
C22 4030016930 S.CER ECJ0EB1A104K B 12.4/16.8
C23 4030017680 S.CER ECJ0EC1H820J B 13.2/9
C24 4030017730 S.CER ECJ0EB1E471K T 18.4/9.7
C25 4030017420 S.CER ECJ0EC1H470J T 20.2/11.3
C26 4030016930 S.CER ECJ0EB1A104K T 14/14.3
C27 4030017590 S.CER ECJ0EC1H070C B 14.6/13.9
C28 4030016930 S.CER ECJ0EB1A104K B 20.9/19.4
C30 4030017450 S.CER ECJ0EB1E271K T 19.3/14.7
C31 4030017420 S.CER ECJ0EC1H470J T 4.9/13.2
C32 4030016930 S.CER ECJ0EB1A104K B 19.6/18.6
C33 4030016790 S.CER ECJ0EB1C103K T 12.4/14.6
C35 4030017420 S.CER ECJ0EC1H470J B 3.1/7.2
C36 4030017420 S.CER ECJ0EC1H470J B 4.3/7.5
C38 4030017420 S.CER ECJ0EC1H470J B 3/11.3
C39 4030017760 S.CER ECJ0EB1H222K B 19.6/20.4
C40 4030017420 S.CER ECJ0EC1H470J B 7.8/9.9
C41 4030017420 S.CER ECJ0EC1H470J T 12.9/9.3
C42 4030017420 S.CER ECJ0EC1H470J T 3.2/8.8
C43 4030017460 S.CER ECJ0EB1E102K B 16.5/39.7
C44 4030017420 S.CER ECJ0EC1H470J T 7.6/8.7
C45 4030017420 S.CER ECJ0EC1H470J B 3.9/8.7
C46 4030017420 S.CER ECJ0EC1H470J T 3.4/6.4
C47 4030017460 S.CER ECJ0EB1E102K B 18.6/26.9
C48 4030017460 S.CER ECJ0EB1E102K B 19.4/34.7
C49 4030017420 S.CER ECJ0EC1H470J T 3.4/5.5
C50 4030017420 S.CER ECJ0EC1H470J T 2.4/3.7
C51 4030017420 S.CER ECJ0EC1H470J B 15.1/5.1
C52 4030016930 S.CER ECJ0EB1A104K B 17.1/19.6
C53 4030017460 S.CER ECJ0EB1E102K B 19.4/33.3
C54 4030016930 S.CER ECJ0EB1A104K T 20.2/12.9
C55 4550007030 S.TAN TEESVP 0J 106M8R T 14.8/15.7
C56 4030017460 S.CER ECJ0EB1E102K T 18.3/20.9
C57 4030017460 S.CER ECJ0EB1E102K B 14.8/22.6
C58 4030016930 S.CER ECJ0EB1A104K T 12.5/17.4
C59 4030017460 S.CER ECJ0EB1E102K T 21.8/32.1
C60 4030017760 S.CER ECJ0EB1H222K T 22.1/14.9
C62 4030017460 S.CER ECJ0EB1E102K B 13.9/22.4
C63 4030016930 S.CER ECJ0EB1A104K T 19.9/20
C64 4030017460 S.CER ECJ0EB1E102K T 23/14
C65 4030016930 S.CER ECJ0EB1A104K T 18.9/17.6
C66 4550007030 S.TAN TEESVP 0J 106M8R T 22.4/12.6
C67 4030017490 S.CER C1608 JB 1A 105K-T T 20/17.2
C68 4030017460 S.CER ECJ0EB1E102K T 1.2/26.5
C69 4030017460 S.CER ECJ0EB1E102K T 1.6/38.1
C70 4030017490 S.CER C1608 JB 1A 105K-T T 20.9/37.9
C71 4030017460 S.CER ECJ0EB1E102K T 19.2/37.5
C72 4030016930 S.CER ECJ0EB1A104K B 24.7/19.3
C73 4030016930 S.CER ECJ0EB1A104K T 25.7/38.9
C74 4030017620 S.CER ECJ0EC1H100C T 23.3/32.1
C75 4030016930 S.CER ECJ0EB1A104K T 24.5/32.6
C76 4030017460 S.CER ECJ0EB1E102K B 4.9/18.8
C77 4030017460 S.CER ECJ0EB1E102K T 24.8/27.1
C78 4030017460 S.CER ECJ0EB1E102K B 9.4/21.8
C79 4030017460 S.CER ECJ0EB1E102K T 18.9/38.7
C80 4030017460 S.CER ECJ0EB1E102K T 9.3/21.3
C81 4030017460 S.CER ECJ0EB1E102K T 10.3/13.3
C82 4550007070 S.TAN TEESVP 1A 475M8R T 2.8/21.9
C83 4030016790 S.CER ECJ0EB1C103K B 17.4/39.7
C84 4030016930 S.CER ECJ0EB1A104K T 4.9/21.5
C85 4030016930 S.CER ECJ0EB1A104K T 2.5/23.3
C86 4030017460 S.CER ECJ0EB1E102K B 1.2/37.9
C88 4030017730 S.CER ECJ0EB1E471K B 1.4/23.1
C89 4030017490 S.CER C1608 JB 1A 105K-T B 2.9/21.9
C90 4030017730 S.CER ECJ0EB1E471K B 1.5/24.8
C91 4030017730 S.CER ECJ0EB1E471K B 4.8/4.9
C92 4030016930 S.CER ECJ0EB1A104K T 21.8/30.5
C93 4030017640 S.CER ECJ0EC1H150J T 23.3/27.5
C94 4030016930 S.CER ECJ0EB1A104K T 22.2/25.6
J1 6510018440 S.CNR AXN430C330P T 13.2/4.3
L1 6200006190 S.COL BLM21PG300SN1D T 7.5/6.5
C1 4030017460 S.CER ECJ0EB1E102K T 10.5/2.9
J1 6910016860 CNR IMSA-9230B-1-02H12-PT1
R1 7210003200 VAR TP76N937N-16.5F-10KA-2803
DS1 5040003170 LED UW3804X
S1 2250000500 ECR TP70TF5164S-20F-2803
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
L1 6200008330 S.COL 0.45-1.4-4TL 15N [L] T 3.9/10.4
6200009360 S.COL 0.45-1.4-3TL 11N [H] T 3.9/10.4
C1 4030006980 S.CER C1608 CH 1H 070D-T [L] T 2.6/13
4030009520 S.CER C1608 CH 1H 020B-T [H] T 2.6/13
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
J1 6910015860 CNR IMSA-6277S-02A-G
J2 6910016780 CNR ANT CONNECTOR-105
W1 8900013740 CBL OPC-1429
[CHASSIS PARTS]
[VR BOARD]
[ANT BOARD]
[L]=Low band, [H]=High band
To Next Page
